Dirt Dog Rear Blades | 50 Series | Working Width 72" & 84" inches | Horsepower 40-50 HP | For Tractor
Dirt Dog Rear Blades | 50 Series | Working Width 72" & 84" inches | Horsepower 40-50 HP | For Tractor
Regular price
$1,573.00
Regular price
Sale price
$1,573.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Dirt Dog Rear Blades | 50 Series | Working Width 72" & 84" inches | Horsepower 40-50 HP | For Tractor
Included Options:
DESCRIPTION
The 50 series blade takes ease of operation to the next level. Simple manual adjustments allow you to offset, angle and tilt quickly and easily.Fix drainage issues, grade the land, clear snow, and more. A simple, versatile tool that’s long been a staple of tractor owners for good reason. EASE OF OPERATION + HEAVY DUTY = MORE WORK DONE IN LESS TIME
Whether you’re scraping soil or snow, a rear blade is a staple in the tractor world as it’s inexpensive, doesn’t have any complex parts, and can do more than one type of task. Compatible with any Cat I 3-Pt or Quick Hitch this attachment is very quick to set up and get to work.
Key Features
- Quick Hitch Compatibility: Built for Category I systems, allowing fast and secure attachment to tractors for ease of use.
- Enhanced Durability: Equipped with a double strap hitch, ensuring added strength and long-lasting performance.
- Versatile Angle Adjustment: Offers 5 forward angles and 3 reverse angles (30° forward, 15° reverse), delivering maximum flexibility for various tasks.
- Improved Grading Control: Includes 3 tilt angle adjustments with a 15° pin tilt, enabling better adaptability on uneven terrain.
- Offset Adjustment: Allows up to 16" offset adjustment to the left or right, making it easy to work around obstacles.
- Flexible Moldboard Sizes: Available in 6 ft and 7 ft sizes to meet diverse grading needs and provide suitable coverage.
- Optional Skid Shoe Kit: Helps prevent excessive digging, ensuring controlled and efficient operation.
- Robust Construction: Features heavy-duty build quality with a reinforced moldboard and cutting edge for reliable performance.
- Durable Cutting Edge: Comes with a 1/2" × 6" bolt-on, reversible cutting edge for extended usability and reduced wear.
- Optimal Weight: Weighs 403 lbs (6 ft) and 430 lbs (7 ft), adding stability during operations.
- Power Compatibility: Suitable for tractors with up to 40 horsepower.
- Proudly Made in the USA: Ensuring quality craftsmanship and reliability.
Detailed Specifications
| Feature | 5006 | 5007 |
|---|---|---|
| Overall Height | 38" | 38" |
| Overall Width | 6 ft | 7 ft |
| Overall Depth | 44 1/2" | 44 1/2" |
| Weight | 403 lbs | 430 lbs |
| Moldboard Height | 15 1/2" | 15 1/2" |
| Tilt Adjustment | 15° | 15° |
| Offset Adjustment | 16" | 16" |
| Angle Adjustment (F-R) | 30° – 15° | 30° – 15° |
| Adjustment Method | Manual | Manual |
| King Pin | 1 1/4" Grade 8 | 1 1/4" Grade 8 |
| Horsepower (2WD-4WD) | 50-40 HP | 50-40 HP |
| Lower Pitch Pin Height | 18 1/2" | 18 1/2" |
