DJI FPV Combo

• Immersive Flight Experience ^[1]
• 4K/60fps Super-Wide 150° FOV ^[2]
• 10km HD Low-Latency Video Transmission ^[3]
• Brand-New S Mode
• Emergency Brake and Hover ^[4]

es let users of any level fly, and the ultra-intuitive DJI Motion Controller provides stunningly intuitive control. ^[6]

Specifications

Camera Sensor

1/2.3” CMOS
Effective pixels: 12 million

Lens

FOV: 150°
35mm Format Equivalent: 14.66 mm
Aperture: f/2.8
Focus Mode: Fixed Focus
Focus Range: 0.6 m to ∞

ISO

100-12800

Shutter Speed

1/50-1/8000 s

Still Photography Modes

Single shot

Max Image Size

3840×2160

Photo Format

JPEG

Video Resolution

4K: 3840×2160 at 50/60fps
FHD: 1920×1080 at 50/60/100/120fps

Video Formats

MP4/MOV (H.264/MPEG-4 AVC, H.265/HEVC）

Max Video Bitrate

120 Mbps

Color Profile

Standard, D-Cinelike

RockSteady EIS

Available

Distortion Correction

Available

Supported File Formats

exFAT (recommended)
FAT32

Gimbal

Mechanical Range

Tilt: -65° to 70°

Controllable Range

Tilt: -50° to 58°

Stabilization

Single-axis (tilt), electronic roll axis

Max Control Speed

60°/s

Angular Vibration Range

±0.01° (N mode)

Electronic Roll Axis

Available (can stabilize footage when the aircraft is tilted at angles of up to 10°)

Aircraft

Takeoff Weight

Approx. 795 g

Dimensions

255×312×127 mm (with propellers)
178×232×127 mm (without propellers)

Diagonal Distance

245 mm

Max Ascent Speed

M mode: No limit
S mode: 15 m/s
N mode: 8 m/s

Max Descent Speed

M mode: No limit
S mode: 10 m/s
N mode: 7 m/s

Max Speed

140 kph; M mode: 39 m/s (27 m/s in Mainland China)
S mode: 27 m/s
N mode: 15 m/s

Max Acceleration

0-100 kph: 2 s (in ideal conditions while flying in M mode)

Max Service Ceiling Above Sea Level

6,000 m

Max Flight Time

Approx. 20 mins (measured while flying at 40 kph in windless conditions)

Max Hover Time

Approx. 16 mins (measured when flying in windless conditions)

Max Flight Distance

16.8 km (measured while flying in windless conditions)

Max Wind Speed Resistance

39-49 kph (25-31 mph)

Operating Temperature

-10° to 40° C (14° to 104° F)

Transmitter Power (EIRP)

2.400-2.4835 GHz
FCC: ≤ 31.5dBm
CE: ≤ 20 dBm
SRRC: ≤ 20 dBm
MIC: ≤ 20 dBm

5.725-5.850 Ghz
FCC: ≤ 31.5 dBm
CE: ≤ 14 dBm
SRRC: ≤ 25.5 dBm

Number of Antennas

Four

GNSS

GPS+GLONASS+GALILEO

Hovering Accuracy Range

Vertical:
±0.1 m (with Vision Positioning)
±0.5 m (with GPS positioning)

Horizontal:
±0.3 m (with Vision Positioning)
±1.5 m (with GPS positioning)

Supported SD Cards

microSD (up to 256 GB)

Internal Storage

N/A

Sensing System

Forward

Precision Measurement Range: 0.5-18 m
Obstacle Sensing: Available in N mode only
FOV: 56° (horizontal), 71° (vertical)

Downward (dual vision sensors + ToF)

ToF Effective Sensing Height: 10 m
Hovering Range: 0.5-15 m
Vision Sensor Hovering Range: 0.5-30 m

Downward Auxillary Light

Single LED

Operating Environment

Refers to non-reflective, discernible surfaces
Diffuse reflectivity >20% (e.g. walls, trees, people)
Adequate lighting conditions (lux >15 in normal indoor lighting conditions)

Charger

Input

100-240 V, 50/60 Hz, 1.8 A

Output

Battery charging interface:
25.2 V ± 0.1 V
3.57 A ± 0.1 A (high current)
1 A ± 0.2 A (low current)

USB Port:
5V/2A (×2)

Rated Power

86 W

Intelligent Flight Battery

Battery Capacity

2000 mAh

Voltage

22.2 V

Max Charging Voltage

25.2 V

Battery Type

LiPo 6S

Energy

44.4 Wh@0.5C

Discharge Rate

Standard: 10C

Weight

295 g

Charging Temperature

5° to 40° C (41° to 104° F)

Max Charging Power

90 W

Video Transmission

Operating Frequency

2.400-2.4835 GHz
5.725-5.850 GHz

Communication Bandwidth

40 MHz (Max.)

Live View Mode

Low-Latency Mode: 810p/120fps ≤ 28ms
High-Quality Mode: 810p/60fps ≤ 40ms

Max Video Bitrate

50 Mbps

Transmission Range

10 km (FCC), 6 km (CE), 6 km (SRRC), 6 km (MIC)

Audio Transmission Support

Yes

DJI FPV Goggles V2

Weight

Approx. 420 g (headband and antennas included)

Dimensions

184×122×110 mm (antennas excluded)
202×126×110 mm (antennas included)

Screen Size

2-inches (×2)

Screen Refresh Rate

144 Hz

Communication Frequency ^[1]

2.400-2.4835 GHz
5.725-5.850 GHz

Transmitter Power (EIRP)

2.400-2.4835 GHz
FCC: ≤ 28.5 dBm
CE: ≤ 20 dBm
SRRC: ≤ 20 dBm
MIC: ≤ 20 dBm

5.725-5.850 GHz
FCC: ≤ 31.5 dBm
CE: ≤ 14 dBm
SRRC: ≤ 19 dBm

Communication Bandwidth

40 MHz (Max.)

Live View Mode

Low-Latency Mode: 810p/120fps ≤ 28ms*
High-Quality Mode: 810p/60fps ≤ 40ms*
* A 150° FOV is available when shooting at 50 or 100 fps. For other frame rates, the FOV will be 142°.

Max Video Bitrate

50 Mbps

Transmission Range ^[2]

10 km (FCC), 6 km (CE), 6 km (SRRC), 6 km (MIC)

Video Format

MOV(Video format: H.264)

Supported Video and Audio Playback Formats

MP4, MOV, MKV (Video format: H.264; Audio format: AAC-LC, AAC-HE, AC-3, MP3）

Operating Temperature

0° to 40° C (32° to 104° F)

Power Input

Dedicated DJI Goggles batteries

FOV

FOV: 30° to 54°; Image size: 50-100%

Interpupillary Distance Range

58-70 mm

Supported microSD Cards

microSD (up to 256 GB)

DJI FPV Goggles Battery

Capacity

1800 mAh

Voltage

9 V (Max.)

Type

LiPo 2S

Energy

18 Wh

Charging Temperature

0° to 45° C (32° to 113° F)

Max Charging Power

10 W

Battery Life

Approx. 110 minutes (measured in an environment of 25°C at maximum brightness level)

DJI FPV Remote Controller 2

Operating Frequency

2.400-2.4835 GHz
5.725-5.850 GHz

Transmitter Power (EIRP)

2.400-2.4835 GHz
FCC: ≤ 28.5 dBm
CE: ≤ 20 dBm
SRRC: ≤ 20 dBm
MIC: ≤ 20 dBm

5.725-5.850 GHz
FCC: ≤ 31.5 dBm
CE: ≤ 14 dBm
SRRC: ≤ 19 dBm

Max. Transmission Distance

10 km (FCC), 6 km (CE), 6 km (SRRC), 6 km (MIC)

Dimensions

190×140×51 mm

Weight

346 g

Battery Life

Approx. 9 hours

Charging Time

2.5 hours

Motion Controller

Model

FC7BMC

Weight

167 g

Operating Frequency Range

2.400-2.4835 GHz; 5.725-5.850 GHz

Max Transmission Distance (unobstructed, free of interference)

10 km (FCC), 6 km (CE/SRRC/MIC)

Transmitter Power (EIRP)

2.4 GHz: ≤28.5 dBm (FCC), ≤20 dBm (CE/ SRRC/MIC)
5.8 GHz: ≤31.5 dBm (FCC), ≤19 dBm (SRRC), ≤14 dBm (CE)

Operating Temperature Range

-10° to 40° C (14° to 104° F)

Battery Life

300 minutes

microSD card

Supported microSD cards

Max 256 GBUHS-I Speed Grade 3

Recommended microSD cards

SanDisk High Endurance U3 V30 64GB microSDXC
SanDisk Extreme PRO U3 V30 A2 64GB microSDXC
SanDisk Extreme U3 V30 A2 64GB microSDXC
SanDisk Extreme U3 V30 A2 128GB microSDXC
SanDisk Extreme U3 V30 A2 256GB microSDXC
Lexar 667x V30 128GB microSDXC
Lexar High Endurance 128GB U3 V30 microSDXC
Samsung EVO U3 (Yellow) 64GB microSDXC
Samsung EVO Plus U3 (Red) 64GB microSDXC
Samsung EVO Plus U3 256GB microSDXC
Netac 256GB U3 A1 microSDXC

Footnotes

Footnotes

1. Due to local policy and regulation restrictions, the 5.8 GHz frequency band is currently banned in certain countries, including but not limited to Japan, Russia, Israel, Ukraine, and Kazakhstan. Please use the 2.4 GHz frequency band when operating in these locations. Always check local rules and regulations before use, as they may change over time.

   2. Maximum flight range specification is a proxy for radio link strength and resilience, not aircraft battery capability. It only refers to the maximum, one-way flight distance. Data was measured in an open environment without interference. Please pay attention to the return prompt on the DJI Fly app during actual flight. Refer to the following applicable standard in different countries and regions:
   FCC: United States, Australia, Canada, Hong Kong, Taiwan, Chile, Colombia, Puerto Rico, and other regions;
   SRRC: Mainland China;
   CE: UK, Russia, France, Germany, Portugal, Spain, Switzerland, Macau, New Zealand, UAE, and other regions;
   MIC: Japan.

In The Box

• DJI FPV Drone × 1
• DJI FPV Intelligent Flight Battery × 1
• DJI FPV Propellers (Pair) × 4
• DJI FPV Gimbal Protector × 1
• DJI FPV Top Shell × 1
• DJI FPV Remote Controller 2 × 1
• Spare Control Sticks (Pair) × 1
• DJI FPV Goggles V2 × 1
• DJI FPV Goggles Antenna (Dual Band) × 4
• DJI FPV Goggles Battery × 1
• DJI FPV Goggles Power Cable (USB-C) × 1
• DJI FPV Goggles Headband × 1
• DJI FPV Goggles Foam Padding × 1
• DJI FPV AC Power Adapter × 1
• DJI FPV AC Power Cable × 1
• USB-C Data Cable × 1
• USB-C OTG Cable × 1
