Inspired Flight IF1200A Heavy-Lift Hexacopter Drone
Inspired Flight IF1200A Heavy-Lift Hexacopter Drone
Regular price
$34,000.00
Regular price
Sale price
$34,000.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Inspired Flight IF1200A Heavy-Lift Hexacopter Drone
DESCRIPTION
The IF1200A is Inspired Flight’s most powerful and versatile UAS platform—engineered specifically for the world’s most demanding missions. Whether you're conducting utility inspections, precise LiDAR mapping, aerial photogrammetry, or rapid emergency response, this heavy-lift aircraft is built to deliver repeatable, reliable performance across the most critical workflows.
Designed with end-user flexibility in mind, the IF1200A supports a wide range of payloads and configurations with an open interface, allowing seamless integration into virtually any operational environment. From government agencies to enterprise field teams, this aircraft is a workhorse capable of transforming complex aerial missions into efficient, cost-effective operations.
Key Features
-
Heavy-Lift Capability: Supports payloads up to 19.1 lbs (8.66 kg), accommodating advanced sensors and equipment with ease.
-
Optimized Flight Time: 23 to 43 minutes of flight duration depending on payload configuration — ideal for extended missions without compromise.
-
Mission Versatility: Designed for a broad range of high-stakes applications, including: Powerline & utility inspections, High-resolution LiDAR mapping, Aerial photogrammetry, Emergency & disaster response, Government and public safety operations.
-
Robust Build Quality: Engineered for field reliability in the most demanding environments — rugged, durable, and ready for deployment.
-
Open Payload Interface: Flexible integration options for custom payloads and mission-specific sensors.
- Efficiency-Driven Design: Improve operational workflow and reduce mission time with repeatable and easy-to-deploy configurations.
Detailed Specifications
Performance
| Parameter | Metric | Imperial |
|---|---|---|
| Max Ascent Speed | 5 m/s | 16 ft/s |
| Max Descent Speed | 2.5 m/s | 8.2 ft/s |
| Max Air Speed | 25 m/s | 56 mph |
| Max Wind Resistance | 12 m/s (gusts up to 15 m/s) | 23 knots (gusts up to 29 knots) |
| Max Tilt Angle | 30° | — |
| Max Angular Velocity | Tilt: 300°/s, Yaw: 45°/s | — |
| Operating Temperature | -20°C to 45°C | -4°F to 113°F |
| Operating Humidity | 10% to 95% | — |
| Service Ceiling (w/ Payload) | 3.9 km @ 4kg, 2.2 km @ 8.7kg | 12,800 ft @ 8.8 lbs, 7,200 ft @ 19.1 lbs |
Physical Dimensions
| Component | Metric | Imperial |
|---|---|---|
| Diagonal Size | 1,025 mm | 40.4 inches |
| Unfolded Size (WxLxH) | 165.5 × 154 × 76.5 cm | 65.1 × 60.6 × 30.2 inches |
| Folded Size (WxLxH) | 47.5 × 49.5 × 47 cm | 18.7 × 19.5 × 18.5 inches |
| Empty Weight (no batteries) | 7.8 kg | 17.2 lbs |
| Weight with Batteries | 16.3 kg | 35.9 lbs |
| Max Gross Takeoff Weight | 25 kg | 55 lbs |
| Max Payload Capacity | 8.7 kg | 19.1 lbs |
| Transport Case Size (WxLxH) | 64.8 × 64.8 × 58.4 cm | 25.5 × 25.5 × 23.0 inches |
| Transport Case Weight | 29 kg | 64 lbs |
Flight Stack & Power
| Component | Specification |
|---|---|
| Flight Controller | CubePilot Cube Blue H7 with Triple Redundant IMUs |
| GNSS / Compass | Dual CubePilot Here3 M8P |
| Payload Power Rails | 12s Battery Voltage: 5v, 12v/15v, 18v, 44.4v |
| Payload Interface | IF1200A Universal Payload Interface |
| Operating Software | Copter by Ardupilot |
Flight Modes
| Mode | Description |
|---|---|
| Position Hold | Maintains position and altitude; allows manual repositioning |
| Loiter | Holds GPS position and altitude for precision control |
| Auto | Executes pre-programmed waypoint missions |
| RTL (Return to Launch) | Automatically returns to launch point and lands |
| Land | Automatically lands while maintaining horizontal position |
| Altitude Hold | Holds altitude only; activated as failsafe when GPS is lost |
