Lucid Sherpa C1 Cleaning Drone w/ Chemical Spraying Window Payload

Specifications Lucid C1 Cleaning Drone w/ Window Cleaning Payload:

Product Model Lucid Sherpa C1 Cleaning Drone & Window Washing System
Airframe Hexacopter
Max Diagonal Wheelbase 53"
Dimensions Arms unfolded: 53"x53"x24"
Arms folded: 24"x24"x24"
Airframe hardware 316 Stainless, Aluminum
Anti-Collision Lights 6x LED

Propulsion System

Motors  6
Stator Size 70mm
KV 180kv
Max Thrust 12kg/rotor
Max Power 3500W/rotor
Weight 720g
Waterproof Rating IPX7
Max Working Current 80A  (Continuous)   Max Working Voltage 52.2V  Foldable

Spraying System

Inlet Connection Material 304 Stainless
Inlet Connection Type 3/4" Male Cam and Groove Fitting
Max Rated Pressure 1000psi
Plumbing Material 304 Stainless
Nozzle Tip Type Assassin 0 degree #50
Nozzle Tip Flow Rate 6.5 - 7.5 gpm
Max Nozzle Assembly Length 18"

Collision Prevention System

Type RADAR
Model USD1
Obstacle Sensing Range
Obstacle sensing range: 0.5-50m
Field Of View 43x30  IP Rating IP67

FPV Camera

FOV 120 degree
Resolution 1920x1200
Resolution 1080p
Video Transmission Digital

Flight Parameters

Flight Controller Operating Frequency 2.400-2.483GHZ
Total Weight (Excluding battery) 21 lbs
Max Takeoff Weight 55 lbs
Max Thrust-Weight Ratio 2.88
Velocity accuracy 0.05 m/s
Battery Gens Tattu 10000 mah 12s (2x)
Max Operating Speed 20 mph
Max Wind Resistance 18 mph
Max Service Ceiling Above Sea Level 2000 m
Recommended Operating 0 to 40 degrees celcius

Transmitter

Charging Method USB-C

Battery Charger

Model TAA1200
Input Voltage 110-120V
Output Voltage and Current 4~25.2V, 0~38A
Operating Temperature 5~+40 degrees celsius

This package contains:

• 1 Sherpa C1 Cleaning Drone
• 1 Controller
• 1 Straight Nozzle
• 4 batteries 12S
• 1 12S Smart Battery Charger
• 1 Repair Kit
• 1 SKB Hard Travel Case
• 1 battery bags
• 1 Window Payload Attachment
• Drone U Props Online Training
• 1 Year Warranty
• 1 Year Email support
• Lucid Welcome Kit

Specifications Lucid C1 Cleaning Drone:

Product Model Lucid Sherpa C1 Cleaning Drone
Airframe Hexacopter
Max Diagonal Wheelbase 53"
Dimensions Arms unfolded: 53"x53"x24"
Arms folded: 24"x24"x24"
Airframe hardware 316 Stainless, Aluminum
Anti-Collision Lights 6x LED

Propulsion System

Motors  6
Stator Size 70mm
KV 180kv
Max Thrust 12kg/rotor
Max Power 3500W/rotor
Weight 720g
Waterproof Rating IPX7
Max Working Current 80A  (Continuous)   Max Working Voltage 52.2V  Foldable Propellers   Diameter x Pitch 23x8.8in  Weight (Single propeller) 36g

Spraying System

Inlet Connection Material 304 Stainless
Inlet Connection Type 3/4" Male Cam and Groove Fitting
Max Rated Pressure 1000psi
Plumbing Material 304 Stainless
Nozzle Tip Type Assassin 0 degree #50
Nozzle Tip Flow Rate 6.5 - 7.5 gpm
Max Nozzle Assembly Length 18"

Collision Prevention System

Type RADAR
Model USD1
Obstacle Sensing Range
Obstacle sensing range: 0.5-50m
Field Of View 43x30  IP Rating IP67

FPV Camera

FOV 120 degree
Resolution 1920x1200
Resolution 1080p
Video Transmission Digital

Flight Parameters

Flight Controller Operating Frequency 2.400-2.483GHZ
Total Weight (Excluding battery) 21 lbs
Max Takeoff Weight 55 lbs
Battery Gens Tattu 10000 mah 12s (2x)
Max Power Consumption 10000W
Max Operating Speed 20 mph
Max Wind Resistance 18 mph
Max Service Ceiling Above Sea Level 2000 m
Recommended Operating 0 to 40 degrees Celcius

Transmitter

Model SIYI MK15
Screen 5.5inch
Screen Type LCD
Battery Life 8h
Built-in Battery 12000mah
Max Transmission Distance 15KM
Operating System Android

Charging Method USB-C

Battery Charger

Model TAA1200
Input Voltage 110-120V
Output Voltage and Current 4~25.2V, 0~38A
Operating Temperature 5~+40 degrees celsius

This package contains:

• 1 Sherpa C1 Cleaning Drone
• 1 Controller
• 1 Straight Nozzle
• 4 batteries 12S
• 1 12S Smart Battery Charger
• 1 Repair Kit
• 1 SKB Hard Travel Case
• 1 battery bags
• Drone U Props Online Training
• Year Warranty
• Year Email support
• Lucid Welcome Kit
