MDE MACHINERY

MDE Machinery Log & Debris Grapple with Saw | Model SX1650SAW/WD | Opening Width 64.9" Inches | Chain Bar 35" Inches | For 18-37.5 Tons Excavators

MDE Machinery Log & Debris Grapple with Saw | Model SX1650SAW/WD | Opening Width 64.9" Inches | Chain Bar 35" Inches | For 18-37.5 Tons Excavators

Regular price $63,509.60
Regular price Sale price $63,509.60
Sale Sold out
Customizable
Fast
24/7 Support
  • Heavy-Duty Construction: Made from 100% Swedish Hardox steel for maximum durability and wear resistance.
  • 360-Degree Worm Drive Rotation: Ensures smooth and precise material handling from any angle.
  • Powerful Hydraulic Saw: Equipped with a 35-inch chain bar capable of cutting logs up to 27 inches in diameter.
  • Wide Grapple Opening: 64.9-inch maximum opening width for gripping large materials securely.
  • Designed for excavators ranging from 18-37.5 Tons (36,000 to 75,000 lbs).
View full details

Product Description

MDE Machinery Log & Debris Grapple with Saw | Model SX1650SAW/WD | Opening Width 64.9" Inches | Chain Bar 35" Inches | For 18-37.5 Tons Excavators

DESCRIPTION

The MDE Machinery SX1650SAW/WD is a high-performance excavator attachment designed for superior handling of logs, debris, and heavy materials. Engineered with 100% Swedish Hardox steel, this grapple ensures maximum durability and strength, making it the ideal solution for forestry, construction, and land-clearing applications.

With a 360-degree worm drive rotation, the SX1650SAW/WD provides exceptional maneuverability, allowing operators to position and cut logs with precision. Its powerful grapple and integrated saw system allow seamless material processing, increasing efficiency and reducing manual labor. Designed for excavators ranging from 18-35 Tons (36,000 to 75,000 lbs), this attachment is built to handle the toughest jobs with ease.

Key Features

  • Heavy-Duty Construction: Made from 100% Swedish Hardox steel for maximum durability and wear resistance.
  • 360-Degree Worm Drive Rotation: Ensures smooth and precise material handling from any angle.
  • Powerful Hydraulic Saw: Equipped with a 35-inch chain bar capable of cutting logs up to 27 inches in diameter.
  • Wide Grapple Opening: 64.9 inch maximum opening width for gripping large materials securely.
  • Designed for excavators ranging from 18-37.5 Tons (36,000 to 75,000 lbs).
  • Fixed Position Design: Provides stable and reliable performance in demanding job sites.
  • Easy-to-Use Control System: Comes with a plug-and-play wiring harness, momentary joystick buttons, and a simple three-line hydraulic system.
  • Mount and Pins Included: Ready for installation without additional hardware purchases.
Name Photo (if available)
BOBCAT E165 BOBCAT E165
CASE CX160D CASE CX160D
CASE CX210D CASE CX210D
CASE CX245D SR CASE CX245D SR
CASE CX250D CASE CX250D
CASE CX300D CASE CX300D
CASE CX350D CASE CX350D
CATERPILLAR 320 CATERPILLAR 320
CATERPILLAR 320 GC CATERPILLAR 320 GC
CATERPILLAR 323 CATERPILLAR 323
CATERPILLAR 330 CATERPILLAR 330
CATERPILLAR M314 CATERPILLAR M314
DOOSAN DX170LC-5 DOOSAN DX170LC-5
DOOSAN DX180LC-5 DOOSAN DX180LC-5
DOOSAN DX225LC-5 DOOSAN DX225LC-5
DOOSAN DX235LCR-5 DOOSAN DX235LCR-5
DOOSAN DX255LC-5 DOOSAN DX255LC-5
DOOSAN DX300LC-5 DOOSAN DX300LC-5
HITACHI ZX160LC-6 HITACHI ZX160LC-6
HITACHI ZX180LC-6 HITACHI ZX180LC-6
HITACHI ZX210-6 HITACHI ZX210-6
HITACHI ZX250LC-6 HITACHI ZX250LC-6
JOHN DEERE 160G LC JOHN DEERE 160G LC
JOHN DEERE 190G W JOHN DEERE 190G W
JOHN DEERE 200G JOHN DEERE 200G
JOHN DEERE 210G LC JOHN DEERE 210G LC
JOHN DEERE 245G LC JOHN DEERE 245G LC
JOHN DEERE 250G LC JOHN DEERE 250G LC
JOHN DEERE 300G LC JOHN DEERE 300G LC
JOHN DEERE 345G LC JOHN DEERE 345G LC
KOBELCO SK230SRLC-5 KOBELCO SK230SRLC-5
KOBELCO SK270SRLC-5 KOBELCO SK270SRLC-5
KOMATSU PC138USLC-11 KOMATSU PC138USLC-11
KOMATSU PC170LC-11 KOMATSU PC170LC-11
KOMATSU PC210LC-11 KOMATSU PC210LC-11
KOMATSU PC238USLC-11 KOMATSU PC238USLC-11
KOMAT SU PC240LC-11 KOMATSU PC240LC-11
KOMATSU PC290LCi-11 KOMATSU PC290LCi-11
SANY SY215C SANY SY215C
SANY SY225C SANY SY225C
SANY SY265C SANY SY265C
VOLVO EC160E VOLVO EC160E
VOLVO EC220E VOLVO EC220E
VOLVO ECR145C VOLVO ECR145C
VOLVO ECR235E VOLVO ECR235E



Detailed Specifications

Feature Specification
Model SX1650SAW/WD
Excavator Compatibility 18 - 37.5 Ton (36,000 - 75,000 lbs)
Material 100% Swedish Hardox Steel
Width 38.1"
Height 48.42"
Teeth Thickness 1.57"
Grapple Opening 64.9"
Grapple Closing 4.72"
Weight 2,100 lbs
Cutting Diameter 27"
Chain Bar Length 35"
