MDE Machinery | Tree Shear with Buncher | Model Koala 300R & STS-400R | Cutting Capacity 12" Inches | For 6.5-23 Tons Excavators

MDE Machinery | Tree Shear with Buncher | Model Koala 300R & STS-400R | Cutting Capacity 12" Inches | For 6.5-23 Tons Excavators

Regular price $31,231.20
Regular price Sale price $31,231.20
Sale Sold out
Customizable
Fast
24/7 Support
  • 360-Degree Rotation – Both models feature full rotation capabilities, allowing precise control and maneuverability for efficient tree cutting and handling. The STS-400R offers electric-controlled rotation for seamless operation from the cab.
  • High Cutting Capacity – The Koala 300R handles trees up to 12 inches in diameter, while the STS-400R cuts trees up to 16 inches, making them suitable for various forestry and land-clearing applications.
  • Hydraulic Power & Efficiency
    Equipped with a powerful hydraulic ram for a secure grip and precise cutting. Operates with 250–350 bar pressure and 21–31 GPM flow, delivering high efficiency for heavy-duty operations.
  • Bolt-On Hitch – Enables quick and easy attachment to various excavators: Compatible with 6.5 - 23-ton excavators (13,000–46,000 lbs). Suitable for 15 - 28.5-ton excavators (30,000–57,000 lbs).
View full details

Product Description

MDE Machinery | Tree Shear with Buncher | Model Koala 300R & STS-400R | Cutting Capacity 12" Inches | For 6.5-23 Tons Excavators

DESCRIPTION

Discover unparalleled efficiency and precision with the MDE MACHINERY KOALA 300R and STS-400R, advanced tree shear attachments that redefine forestry and land management. Designed to handle demanding tasks, these attachments are equipped with powerful hydraulic systems, cutting-edge features, and durable construction, ensuring superior performance in any environment.

The Koala 300R, built for mid-range excavators, is perfect for clearing forestry land, agricultural hedges, and landscaping tasks. Its 12-inch cutting capacity and 360-degree rotation offer exceptional versatility and precision. With a full Hardox® steel chassis, replaceable blade, and bolt-on hitch, it provides reliability and easy compatibility with various excavators.

Meanwhile, the STS-400R, designed for larger excavators, is ideal for high-output tree harvesting and heavy-duty operations. Featuring a 16-inch cutting capacity and grab-and-cut system, it ensures safety and efficiency in even the toughest forestry projects. Its electric-powered rotation switch and optional collection system further enhance functionality, making it the ultimate solution for professional operators.

Key Features

MDE MACHINERY KOALA 300R:

  • 360-Degree Rotation: Enables seamless maneuvering for precise tree handling.
  • Cutting Capacity: Capable of cutting trees up to 12 inches in diameter.
  • Durable Construction: Made with 12mm Hardox® steel for unmatched strength and wear resistance.
  • Hydraulic Power: Equipped with a powerful hydraulic ram for secure gripping and effective cutting.
  • Replaceable Blade: Reduces downtime, ensuring consistent performance.
  • Bolt-On Hitch: Allows quick attachment to various excavators (6.5 - 23 Tons ).
  • Compact Design: Lightweight (860 lbs) and compact for efficient operation.

MDE MACHINERY STS-400R:

  • 360-Degree Electric Rotation: Controlled via cab switch for easy operation.
  • Cutting Capacity: Handles trees up to 16 inches in diameter.
  • Grab & Cut System: Ensures tree stability and safe removal in high-risk areas.
  • Heavy-Duty Hardox® Steel Build: Crafted for long-lasting performance in tough conditions.
  • Hydraulic Efficiency: Operates with 250–350 bar pressure and a flow of 21–31 GPM.
  • Bolt-On Hitch: Allows quick attachment to various excavators (15 - 28.5 Tons
  • Removable Blade: Simplifies maintenance and maximizes uptime.
  • Optional Collection System: Speeds up bunching of smaller trees for efficient harvesting.

Host Machines KOALA 300R

Name Photo (if available)
BOBCAT E145 BOBCAT E145
BOBCAT E165 BOBCAT E165
BOBCAT E85 BOBCAT E85
BOBCAT E88 BOBCAT E88
CASE CX130D CASE CX130D
CASE CX145D CASE CX145D
CASE CX160D CASE CX160D
CASE CX210D CASE CX210D
CASE CX245D SR CASE CX245D SR
CASE CX250D CASE CX250D
CASE CX60C CASE CX60C
CASE CX75C SR CASE CX75C SR
CASE CX80C CASE CX80C
CATERPILLAR 306 CATERPILLAR 306
CATERPILLAR 308 CATERPILLAR 308
CATERPILLAR 309 CATERPILLAR 309
CATERPILLAR 310 CATERPILLAR 310
CATERPILLAR M314 CATERPILLAR M314
CATERPILLER 307 CATERPILLER 307
DOOSAN DX140LC-5 DOOSAN DX140LC-5
DOOSAN DX140LCR-5 DOOSAN DX140LCR-5
DOOSAN DX170LC-5 DOOSAN DX170LC-5
DOOSAN DX180LC-5 DOOSAN DX180LC-5
DOOSAN DX62R-3 DOOSAN DX62R-3
DOOSAN DX63-3 DOOSAN DX63-3
DOOSAN DX85R-3 DOOSAN DX85R-3
HITACHI ZX130-6 HITACHI ZX130-6
HITACHI ZX160LC-6 HITACHI ZX160LC-6
HITACHI ZX180LC-6 HITACHI ZX180LC-6
HITACHI ZX60USB-5 HITACHI ZX60USB-5
HYUNDAI HX85A HYUNDAI HX85A
HYUNDAI R60CR-9A HYUNDAI R60CR-9A
HYUNDAI R80CR-9A HYUNDAI R80CR-9A
JOHN DEERE 130G JOHN DEERE 130G
JOHN DEERE 135G JOHN DEERE 135G
JOHN DEERE 160G LC JOHN DEERE 160G LC
JOHN DEERE 190G W JOHN DEERE 190G W
JOHN DEERE 200G JOHN DEERE 200G
JOHN DEERE 60 P JOHN DEERE 60 P
JOHN DEERE 60G JOHN DEERE 60G
JOHN DEERE 75 P JOHN DEERE 75 P
JOHN DEERE 75G JOHN DEERE 75G
JOHN DEERE 85G JOHN DEERE 85G
KOBELCO SK140SRLC-7 KOBELCO SK140SRLC-7
KOBELCO SK75SR-7 KOBELCO SK75SR-7
KOBELCO SK85SC-7 KOBELCO SK85SC-7
KOMATSU PC130-11 KOMATSU PC130-11
KOMATSU PC138USLC-11 KOMATSU PC138USLC-11
KOMATSU PC170LC-11 KOMATSU PC170LC-11
KOMATSU PC78US-11 KOMATSU PC78US-11
KOMATSU PC88US-11 KOMATSU PC88US-11
KUBOTA KX080 KUBOTA KX080
NEW HOLLAND E60C NEW HOLLAND E60C
SANY SY135U SANY SY135U
SANY SY155U SANY SY155U
SANY SY60U SANY SY60U
SANY SY75C SANY SY75C
SANY SY80U SANY SY80U
SANY SY95C SANY SY95C
TAKEUCHI TB2150 TAKEUCHI TB2150
TAKEUCHI TB280FR TAKEUCHI TB280FR
TAKEUCHI TB290 TAKEUCHI TB290
TAKEUCHI TB370 TAKEUCHI TB370
VOLVO EC140E VOLVO EC140E
VOLVO EC160E VOLVO EC160E
VOLVO EC60E VOLVO EC60E
VOLVO ECR145C VOLVO ECR145C
VOLVO ECR58 VOLVO ECR58
VOLVO ECR88D VOLVO ECR88D
WACKER NEUSON ET90 WACKER NEUSON ET90
WACKER NUESON ET145 WACKER NUESON ET145
WACKER NUESON ET65 WACKER NUESON ET65
YANMAR SV100-2A YANMAR SV100-2A
YANMAR VIO 80-1A YANMAR VIO 80-1A



Host Machines STS-400R

Name Photo (if available)
BOBCAT E145 BOBCAT E145
BOBCAT E165 BOBCAT E165
CASE CX160D CASE CX160D
CASE CX210D CASE CX210D
CASE CX245D SR CASE CX245D SR
CASE CX250D CASE CX250D
CASE CX300D CASE CX300D
CATERPILLAR 320 CATERPILLAR 320
CATERPILLAR 320 GC CATERPILLAR 320 GC
CATERPILLAR 323 CATERPILLAR 323
CATERPILLAR M314 CATERPILLAR M314
DOOSAN DX140LC-5 DOOSAN DX140LC-5
DOOSAN DX140LCR-5 DOOSAN DX140LCR-5
DOOSAN DX170LC-5 DOOSAN DX170LC-5
DOOSAN DX180LC-5 DOOSAN DX180LC-5
DOOSAN DX225LC-5 DOOSAN DX225LC-5
DOOSAN DX235LCR-5 DOOSAN DX235LCR-5
DOOSAN DX255LC-5 DOOSAN DX255LC-5
HITACHI ZX160LC-6 HITACHI ZX160LC-6
HITACHI ZX180LC-6 HITACHI ZX180LC-6
HITACHI ZX210-6 HITACHI ZX210-6
HITACHI ZX250LC-6 HITACHI ZX250LC-6
JOHN DEERE 135G JOHN DEERE 135G
JOHN DEERE 160G LC JOHN DEERE 160G LC
JOHN DEERE 190G W JOHN DEERE 190G W
JOHN DEERE 200G JOHN DEERE 200G
JOHN DEERE 210G LC JOHN DEERE 210G LC
JOHN DEERE 245G LC JOHN DEERE 245G LC
JOHN DEERE 250G LC JOHN DEERE 250G LC
KOBELCO SK140SRLC-7 KOBELCO SK140SRLC-7
KOBELCO SK230SRLC-5 KOBELCO SK230SRLC-5
KOBELCO SK270SRLC-5 KOBELCO SK270SRLC-5
KOMATSU PC138USLC-11 KOMATSU PC138USLC-11
KOMATSU PC170LC-11 KOMATSU PC170LC-11
KOMATSU PC210LC-11 KOMATSU PC210LC-11
KOMATSU PC238USLC-11 KOMATSU PC238USLC-11
KOMATSU PC240LC-11 KOMATSU PC240LC-11
SANY SY135U SANY SY135U
SANY SY155U SANY SY155U
SANY SY215C SANY SY215C
SANY SY225C SANY SY225C
SANY SY265C SANY SY265C
TAKEUCHI TB2150 TAKEUCHI TB2150
VOLVO EC140E VOLVO EC140E
VOLVO EC160E VOLVO EC160E
VOLVO EC220E VOLVO EC220E
VOLVO ECR145C VOLVO ECR145C
WACKER NUESON ET145 WACKER NUESON ET145



Detailed Specifications

Feature MDE KOALA 300R MDE STS-400R
Excavator Size 6.5 - 23 Tons 15 - 28.5 Tons
Cutting Capacity 12 inches 16 inches
Weight 860 lbs 3,500 lbs
Hydraulic Flow 18.49 GPM - 26.4 GPM 21 GPM - 31 GPM
Oil Pressure 3,625 PSI - 4,351 PSI 250 bar - 350 bar
Width 37.4 inches N/A
Height 22.22 inches N/A
Rotation 360 degrees Electric-controlled 360 degrees
Material 12mm Hardox® Steel High-strength Hardox® Steel
Special Feature Replaceable blade, bolt-on hitch Grab & cut system, optional collection system
Ideal Application Forestry clearing, agricultural tasks High-output tree harvesting
