MK Martin Axis Tool Arm 3PT Hitch Model AXIS4 / AXIS5-6 | 30-80HP For Tractor
MK Martin Axis Tool Arm 3PT Hitch Model AXIS4 / AXIS5-6 | 30-80HP For Tractor
Regular price
$7,872.00
Regular price
Sale price
$7,872.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
MK Martin Axis Tool Arm 3PT Hitch Model AXIS4 / AXIS5-6 | 30-80HP For Tractor
DESCRIPTION
AXIS5-6 Axis Tool Arm MUST ADD A ROTARY CUTTER TO COMPLETE UNIT
The Axis is the ideal tool for safely mowing around ponds, ditches, and fence lines. The offset design of the Axis Tool Arm provides the necessary clearance to keep both the tractor and the operator out of harms way from low hanging branches, or possibly rolling the tractor down an incline. To ensure both operator and equipment safety, the Axis is equipped with sheer bolt protection on a break away link should the arm strike an unforeseen object with too much force. *CUTTING ANGLE CYL. EXT. 55 DEGREES *CUTTING ANGLE CYL. RET. 90 DEGREES *OFFSET 60" *TRACTOR REMOTES REQUIRED 2 *PROTECTION SHEAR BOLT *MINIMUM TRACTOR WEIGHT 2900LBS *MAXIMUM TOOL WEIGHT 480LBS
Key Features
- Powerful Versatility: Compatible with tractors from 30-80 HP, designed for mowing hard-to-reach areas like ponds, ditches, and fence lines.
- Heavy-Duty Build: Weighs 751 lbs (AXIS4) to 900 lbs (AXIS5-6), supporting maximum tool weights of up to 480 lbs and 800 lbs, respectively, for enhanced durability.
- Flexible Offset Reach: Provides a 60" offset (AXIS4) and 84" (AXIS5-6), ensuring the tractor and operator stay safe from low branches and steep inclines.
- Safety Focused: Equipped with shear bolt protection for break-away safety in case of high-force impacts, ensuring both operator and equipment protection.
- Hydraulic Tool Adjustability: Features hydraulic tool lift and rotation, allowing easy tool adjustment for precise mowing angles along varied terrain.
|
HYDRAULIC TOOL LIFT The Axis Tool Arm hydraulically pivots on your 3PH raising and lowering the tool as needed. With the Axis fully raised the mower can be folded in to provide safe road travel (image below).
|
|
HYDRAULIC TOOL ROTATION To provide the best results when mowing along ditches or around ponds the tool carrier is hydraulically adjustable allowing the mower to be adjusted to match the grade.
|
|
STABILIZER ARM TO CUTTER Various attachment bracket are supplied with the Axis Toolbar to attach the Stabilizer Bar to the cutter. All four adaptors are included.
|
|
TRANSPORT LOCK
|
|
RETRACTABLE WEIGHT BAR
|
Detailed Specifications
AXIS4 and AXIS5-6
| Feature | AXIS4 |
|---|---|
| Part # | AXIS4 |
| Weight (LBS.) | 751 |
| Offset | 60" |
| 3PH Mount | CAT. 1 |
| Minimum Tractor Weight | 2,900 lbs |
| Maximum Tool Weight (LBS.) | 480 |
| Rotary Cutter Requirement | 4' (min. 30 HP) |
| Cutting Angle (Cylinder Extended) | 55° |
| Cutting Angle (Cylinder Retracted) | 90° |
| Tractor Remotes Required | 2 |
| Protection | Shear Bolt |
| Feature | AXIS5-6 |
|---|---|
| Part # | AXIS5-6 |
| Weight (LBS.) | 900 |
| Offset | 84" |
| 3PH Mount | CAT. 1 & 2 |
| Minimum Tractor Weight | 5,800 lbs |
| Maximum Tool Weight (LBS.) | 800 |
| Rotary Cutter Requirement | 5' (min. 60 HP) / 6' (min. 80 HP) |
| Cutting Angle (Cylinder Extended) | 55° |
| Cutting Angle (Cylinder Retracted) | 90° |
| Tractor Remotes Required | 2 |
| Protection | Shear Bolt |
In Package
- Hydraulic Tool Lift: For smooth vertical adjustments to match terrain.
- Hydraulic Tool Rotation: Ensures precise alignment for varied mowing conditions.
- Stabilizer Arm to Cutter Brackets: Includes four adaptors for attaching the stabilizer bar to the rotary cutter.
- Transport Lock: Secures the arm during transport for safety.
- Retractable Weight Bar: Improves balance and stability when in use.
