Description
Premier Attachments offers a versatile range of Backhoe Earth Auger Drives designed for optimal performance in tough and variable drilling conditions. With two types available—Heavy Duty High Flow and 2-Speed High Flow—these auger drives are engineered to maximize torque, speed, and efficiency for a variety of applications. Perfect for professionals in construction, agriculture, and landscaping, our auger drives are built to handle the most challenging environments, ensuring reliable and consistent operation.
Product Variants:
-
Heavy Duty High Flow Earth Auger Drives
- Built to handle the toughest drilling conditions with hydraulic flows ranging from 25 GPM to 60 GPM.
- Capable of delivering torque outputs between 3,624 ft. lbs. and 35,297 ft. lbs.
- No Drain Line Required: Simplifies installation and maintenance.
- Versatile Mounting Options: Compatible with pin-on buckets, OEM couplers, aftermarket couplers, and custom mounts.
- Cradle Function Available: Keeps the auger drive and bit secure during transportation between holes.
- Output Shaft Options: Available in 2", 2-1/2", and 3" hexagon, and 4" square.
-
2-Speed High Flow & Standard Flow Earth Auger Drives
- Designed for variable conditions where a balance between torque and speed is essential.
- Features Shift-on-Demand Technology: Automatically adjusts from high torque/low RPM to low torque/high RPM based on digging conditions.
- Built for high performance in both soft and hard soil conditions.
Features
- High Torque Capability: Optimized for even the toughest drilling conditions, ensuring powerful and effective operation.
- Adaptable Output Shafts: Available in 2", 2-1/2", and 3" hexagon, and 4" square for compatibility with various auger bits.
- Extended Warranty Options: Backed by a comprehensive 2, 3, and 5-year warranty, depending on the model.
- Mounting Flexibility: Supports a range of mounting brackets and cradles to accommodate different machines and applications.
Specifications
Heavy Duty High Flow Auger Drives
Model/Item # | Max Auger Diameter | GPM Range | Max Torque | Output Shaft Options | Warranty |
---|---|---|---|---|---|
H045PD | 48" | 25-40 GPM | 5,798 ft. lbs. | 2" Hex & 2-1/2" Hex | 5 Years |
H055PD | 48" | 35-50 GPM | 7,325 ft. lbs. | 2" Hex & 2-1/2" Hex | 5 Years |
H065PD | 48" | 30-55 GPM | 9,156 ft. lbs. | 2" Hex & 2-1/2" Hex | 3 Years |
H075PD | 48" | 40-60 GPM | 12,790 ft. lbs. | 2-1/2" Hex | 3 Years |
H085PD | 48" | 40-60 GPM | 12,539 ft. lbs. | 2-1/2" Hex | 3 Years |
H095PD | 48" | 45-60 GPM | 17,941 ft. lbs. | 2-1/2" Hex | 2 Years |
2-Speed High Flow Auger Drives
Model/Item # | Speed Type | GPM Range | Max Torque | Output Shaft Options | Warranty |
---|---|---|---|---|---|
H206PD | High/Low Speed | 25-35 GPM | 6,065 ft. lbs. | 2" Hex | 2 Years |
H215PD | High/Low Speed | 30-50 GPM | 14,211 ft. lbs. | 2-1/2" Hex | 2 Years |
2-Speed Standard Flow Auger Drives - 2 Year Warranty
Model/Item # | GPM Range | Output Shaft Options | Max Auger Diameter | Weight | Price (US $) |
---|---|---|---|---|---|
H203PD | 13-18 GPM | 2” Hex or 2-1/2” Hex | 30” | 225 lbs | $6,749.00 |
H204PD | 15-20 GPM | 2” Hex or 2-1/2” Hex | 36” | 230 lbs | $6,749.00 |
H205PD | 17-21 GPM | 2” Hex or 2-1/2” Hex | 48” | 235 lbs | $6,749.00 |
H208PD | 19-25 GPM | 2” Hex or 2-1/2” Hex | 48” | 240 lbs | $6,749.00 |
Upgrade your backhoe's digging efficiency with Premier Attachments' robust and reliable Backhoe Earth Auger Drives. Built to withstand the rigors of heavy-duty applications, our auger drives ensure you have the power and precision needed to get the job done. Order now and take advantage of our industry-leading warranties and versatile mounting options!
