Top Dog Attachments Dual Side Flow Bucket - Light Material | Width: 97” | Capacity: 46 to 55.2 cu. ft | For Skid Steers
Top Dog Attachments Dual Side Flow Bucket - Light Material | Width: 97” | Capacity: 46 to 55.2 cu. ft | For Skid Steers
Regular price
$12,417.14
Regular price
Sale price
$12,417.14
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Top Dog Attachments Dual Side Flow Bucket - Light Material | Width: 97” | Capacity: 46 to 55.2 cu. ft | For Skid Steers
DESCRIPTION
The Top Dog Dual Side Flow Light Material Bucket is an innovative attachment designed to efficiently handle and spread light materials such as sawdust, mulch, and silage. With dual discharge openings, adjustable belt speeds, and a beater bar to prevent clogging, this bucket enhances material distribution, making it ideal for agricultural and industrial use.
Key Features
- Dual-Side Discharge – Allows material to be scooped and discharged through two openings for efficient spreading.
- Convertible Design – Can function as a bucket when rotated and lowered.
- Adjustable Belt Speeds – Dual control valves provide precision control over belt speed and direction.
- Beater Bar – Prevents material buildup, ensuring smooth operation.
- Heavy-Duty Construction – Built for durability with reinforced materials.
- American Made – Manufactured in the USA for reliable performance.
Detailed Specifications
| Feature | Specification |
|---|---|
| Overall Width | 97” |
| Overall Height | 44” |
| Overall Depth | 52” |
| Struck Capacity | 46 cu. ft |
| Heaped Capacity | 55.2 cu. ft |
| Belt Motors | 4.9 cu. in – Dual Motors |
| Beater Bar Motor | 18.6 cu. in |
| Flow GPM | 15-20 GPM |
| Belt Speed | Adjustable (Dual Control Valves) |
| Belt Thickness | 5/16” thick |
| Belt Style Options | 2-Ply Asphalt or Chevron V Style |
| Hydraulic Couplers | Flat Face |
| Hydraulic Hoses | 1/2” PSI Min/Max: 2,500 |
| Bearings | 1” Pillow Block (2) |
| Cutting Edge | 5/8” x 6 |
| Mounting Plate | 5/16” thick |
| Pivot Points | Equipped with Grease Zerks |
| Tensioners | Manually Adjustable (4 locations) |
| Bucket Thickness | 3/16” thick |
| Wear Bars | 3/8” thick |
| Weight | 1,350 lbs |
