Product Description
Wallenstein 3-Point Log Splitter | Model WX Series | Split Force 20-31 Tons | Horsepower 35+ HP | For Tractor
DESCRIPTION
Heavy-Duty Log Splitters for Agricultural Use
The Wallenstein WX Series offers a range of 3-point hitch log splitters compatible with tractors, designed to deliver robust performance with models ranging from 20 to 31 tons of split force. Ideal for agricultural and heavy-duty applications, these log splitters offer reliable wood splitting power in both horizontal and vertical orientations, making them versatile for various job requirements.
Efficient and Flexible Tractor-Mounted Log Splitters
With split openings from 24” up to 48” and quick cycle times, these splitters are perfect for tasks that demand high productivity and ease of use. Each unit is built with premium construction materials, and each model is compatible with Category I and iMatch™ Quick Hitch systems, ensuring secure mounting and efficient operation with compatible tractors (minimum 35 HP).
Key Features
- High Split Force: Ranges from 20 to 31 tons, suitable for various wood types.
- Cycle Efficiency: Fast average cycle times for high productivity.
- Adjustable Orientation: Models available in horizontal, vertical, or combo orientations.
- Quick Hitch Compatible: Cat I and iMatch™ Quick Hitch compatible for ease of attachment.
- Robust Construction: Durable construction and components ensure long service life.
- High Wedge Height: 9” or 10” wedge height for effective splitting.
- Easy Mounting: Direct attachment to tractor 3-point hitch.
- Hydraulic Flow Requirements: Models adapted to various flow rates from 10 gpm to 16 gpm.
- Powerful Cylinder Diameter: Up to 5” on heavy-duty models for increased split force.
- Versatile Use: Suitable for agricultural and forestry applications.
| Image | Feature | Description |
|
Cat I iMatch Quick Hitch Compatible |
Easily attach to your tractor without leaving your seat. |
|
|
Direct Pressure |
Full splitting force is always applied because the cylinder is directly inline with the log, powering through the toughest wood with ease. |
|
|
Grip-Strip Stop Block |
Engineered to support an enhanced split action |
|
|
Hands Free Return |
Switched to reverse, the wedge returns to the start position hands free and then automatically clicks back to neutral. |
|
|
Wide Wedge |
Wide wedge spreads and pops the log in a short distance, reducing cycle time. |
Detailed Specifications
| Specification | WX310 | WX320 | WX330 | WX350 | WX360 | WX370 |
|---|---|---|---|---|---|---|
| Split Force | 20 Ton | 25 Ton | 25 Ton | 20 Ton | 31 Ton | 20 Ton |
| Cylinder | 4" (10 cm) | 4.5" (11 cm) | 4.5" (11 cm) | 4" (10 cm) | 5" (13 cm) | 4" (10 cm) |
| Split Opening | 24" (61 cm) | 36" (91 cm) | 48" (122 cm) | 24" (61 cm) | 24" (61 cm) | 24" (61 cm) |
| Orientation | Horizontal | Horizontal | Horizontal | Vertical | Vertical | Horizontal / Vertical |
| Dimensions | 70"x28"x24" | 96"x30"x24" | 120"x30"x24" | 70"x28"x18" | 70"x28"x26" | 86"x30"x30" |
| Total Weight | 215 lbs (98 kg) | 375 lbs (170 kg) | 425 lbs (193 kg) | 220 lbs (100 kg) | 320 lbs (146 kg) | 290 lbs (132 kg) |
| Wedge Height | 9" (23 cm) | 10" (25 cm) | 10" (25 cm) | 9" (23 cm) | 10" (25 cm) | 10" (25 cm) |
| Average Cycle | 6.62 sec | 11.43 sec | 15.24 sec | 6.62 sec | 9.73 sec | 6.62 sec |
| Full Cycle | 13.24 sec | 22.86 sec | 30.48 sec | 13.24 sec | 19.47 sec | 13.24 sec |
| Hydraulic Flow | 10 gpm (38 lpm) | 13 gpm (50 lpm) | 13 gpm (50 lpm) | 10 gpm (38 lpm) | 16 gpm (61 lpm) | 10 gpm (38 lpm) |
| Min Tractor HP | 35 | 35 | 35 | 35 | 35 | 35 |
