Wallenstein 3-PT Hitch Backhoe | Model GX-920XT | Hydraulic Flow 5 GPM | Extended Digging Depth | For Tractors & Skid Steer
Wallenstein 3-PT Hitch Backhoe | Model GX-920XT | Hydraulic Flow 5 GPM | Extended Digging Depth | For Tractors & Skid Steer
Regular price
$16,425.00
Regular price
Sale price
$16,425.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Wallenstein 3-PT Hitch Backhoe | Model GX-920XT | Hydraulic Flow 5 GPM | Extended Digging Depth | For Tractors & Skid Steer
DESCRIPTION
The Wallenstein GX920XT Backhoe Attachment offers powerful digging capabilities for tractors and skidsteers, with a maximum digging depth of 11'4" when extended. This backhoe is designed to be a versatile and essential tool for various agricultural, landscaping, and construction tasks. Equipped with a 12" bucket, PTO pump kit, and 3-point mount, the GX920XT provides exceptional reach and digging force, ideal for users who need both depth and power in their work.
With hydraulic-driven functionality, the GX920XT is suited for tractors ranging from 50-100 HP and skidsteers with a 45-100 HP range. This model includes a flow divider and features 180° bucket rotation and swing arc for maximum maneuverability, ensuring efficient operation even in challenging work environments.
Key Features
- Extended Digging Depth: Capable of reaching depths up to 11'4", this feature allows for deep and efficient excavations, making it suitable for various heavy-duty digging tasks.
- High Power Compatibility: Designed to work seamlessly with 50-100 HP tractors and 45-100 HP skidsteers, ensuring versatile and robust performance across different machinery.
- Optimal Hydraulic Flow: Requires only 5 gpm for efficient operation, making it energy-efficient while maintaining high performance.
- Versatile Mounting Options: Equipped with multiple mounting options, including a skidsteer universal plate and a 3-point mount, allowing for flexible and easy attachment to various equipment.
- Exceptional Bucket Digging Force: Provides an impressive bucket digging force of 3925 lbs, ensuring powerful and efficient digging capabilities.
- Flow Divider: This feature ensures optimal hydraulic distribution, enhancing the overall performance and efficiency of the backhoe attachment.
- Compact and Convenient Transport: The foldable design allows for easy and compact transport, making it convenient to move the equipment between job sites.
- Wide Stabilizer Spread: With a stabilizer width of 89 inches, this feature provides sturdy and reliable operation, preventing tipping and ensuring safe usage.
- Durable Cylinders: Built with robust 3" and 2.5" diameter cylinders, these ensure long-lasting durability and reliable performance under demanding conditions.
- Extended Reach: Offers an extended reach of 164 inches from the swing post, providing ample coverage and flexibility for various digging applications.
| Feature | Description |
|---|---|
| Point Hitch Mount | Turn your tractor into a backhoe with the simple 3-point hitch mount. Utilizes tractor’s draw bar for increased rigidity. |
| Curved Boom | Protects backhoe from unnecessary damage and prevents ground from falling back into the hole. |
| Dual Swing Cylinders | Provides strong, consistent movement throughout the entire 180-degree range. |
| Greaseable Pins | Maintenance is easy with greaseable pins on all pivot points. |
| Hardened Steel Bushings | To reduce wear, hardened steel bushings are installed on all the main pivot points. |
| Hydraulic Stabilizers | Easy to use hydraulic stabilizers help to prevent tipping. |
| Replaceable Teeth | Pin-on bucket teeth allow for quick replacement of worn or damaged teeth. |
| Skidsteer Mount | The universal quick attach plate connects easily to most skidsteers. |
| Subframe Mounting | Allows your tractor to safely handle the stresses developed by digging with a backhoe attachment. |
| Swing Cushioning | Hydraulic cushioning gracefully brings the boom to a controlled stop when swung to the extreme ends. |
Detailed Specifications
| Specification | Description |
|---|---|
| Machine Size | 45-100 HP |
| Attachment Size | 11'4" Dig Depth |
| Digging Depth | 9'4" (Standard), 11'4" (Extended) |
| Reach from Swing Post | 141" (Standard), 164" (Extended) |
| Hydraulic Flow Requirement | 5 gpm |
| Bucket Rotation | 180° |
| Swing Arc | 180° |
| Dipper Boom Digging Force | 2200 lbs |
| Bucket Digging Force | 3925 lbs |
| Boom Lift Capacity | 580 lbs |
| Operating Pressure | 2250 psi |
| Mounting Options | Subframe, Skidsteer Universal Plate, PT300 (Cat I), PT322 (Cat II) |
| Total Weight | 980 lbs |
| Transport Dimensions (LxWxH) | 81" x 43" x 92" |
In Package
- Wallenstein GX920XT Backhoe Attachment
- 12" Bucket
- PTO Pump Kit
- Flow Divider
- User Manual and Safety Guide
Available Options
- Subframe Mounting
- Skidsteer Universal Plate Compatibility
- PT300 and PT322 3-Point Hitch Mount Options
