Wallenstein 3PT Hitch Wood Chipper | Model BX Series | Engine Horsepower 12-120 HP | Rated RPM 540 - 1000 | For Tractors
Wallenstein 3PT Hitch Wood Chipper | Model BX Series | Engine Horsepower 12-120 HP | Rated RPM 540 - 1000 | For Tractors
Regular price
$22,290.00
Regular price
Sale price
$22,290.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Wallenstein 3PT Hitch Wood Chipper | Model BX Series | Engine Horsepower 12-120 HP | Rated RPM 540 - 1000 | For Tractors
DESCRIPTION
The Wallenstein BX102RPI 10" Chipper is designed for heavy-duty chipping needs, ideal for farms, landscaping businesses, and forest maintenance. Powered by a PTO, this chipper efficiently processes branches and brush up to 10" in diameter with its hydraulic feed system. Equipped with a P3 Pulse for precise feeding control, the BX102RPI ensures optimal, continuous chipping at maximum capacity.
With the added convenience of a winch and lift, this chipper is built to handle large volumes of wood efficiently and quickly. The robust construction and advanced feed control provide a seamless chipping experience, making it a reliable choice for high-volume operations.
Key Features
- PTO Powered: Efficient power transfer directly from your tractor’s PTO ensures maximum efficiency.
- Hydraulic Feed: Control-fed hopper provides consistent and smooth chipping with minimal effort.
- High Capacity: Capable of handling branches up to 10" in diameter, making it perfect for heavy-duty tasks.
- P3 Pulse Technology: Advanced feed control system optimizes processing speed and efficiency.
- Integrated Winch: Easily maneuver and position heavy wood pieces with the built-in winch.
- Adjustable Lift: Allows for versatile chipping angles to accommodate different tasks and preferences.
- Durable Build: Sturdy construction ensures reliability and longevity, even under heavy use.
- Compact Transport: Foldable hopper design makes transportation and storage easy and convenient.
- Efficient Operation: Designed to reduce downtime with a smooth and consistent feed rate.
- Heavy-Duty Rotor: Enhances chipping efficiency and durability for more effective wood processing.
Detailed Specifications
| Specification | BXM42 | BX36S | BX52S | BX72S | BX102S | BX52RI | BX72RI | BX102RI | BX102RPI | BX52R | BX72R | BX102R |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Chipping Capacity | .... | 3.5" (9 cm) | 5" (13 cm) | 7" (18 cm) | 10" (25 cm) | 5" (13 cm) | 7" (18 cm) | 10" (25 cm) | 10" (25 cm) | 5" (13 cm) | 7" (18 cm) | 10" (25 cm) |
| Chipper Type | ... | Disc | Disc | Disc | Disc | Disc | Disc | Disc | Disc | Disc | Disc | Disc |
| Feed System | Gravity | Gravity | Gravity | Gravity | Gravity | Dual Hydraulic Roller Feed | Dual Hydraulic Roller Feed | Dual Hydraulic Roller Feed | Dual Hydraulic Roller Feed | Dual Hydraulic Roller Feed | Dual Hydraulic Roller Feed | Dual Hydraulic Roller Feed |
| Engine HP Range | ... | 12 - 30 | 22 - 55 | 50 - 85 | 80 - 120 | 30 - 55 | 45 - 85 | 75 - 120 | 75 - 120 | 40 - 55 | 50 - 85 | 80 - 120 |
| On-Board Intelligence | n/a | n/a | n/a | n/a | n/a | P3 Pulse™ | P3 Pulse™ | P3 Pulse™ | P3 Pulse™ | n/a | n/a | n/a |
| Recommended Hydraulic Flow | 25 gpm (95 lpm) | ... | ... | ... | ... | ... | ... | ... | ... | ... | ... | ... |
| Chipper Hopper Opening | 20" x 20" (51 cm x 51 cm) | 13" x 20" (34 cm x 51 cm) | 20" x 20" (51 cm x 51 cm) | 22" x 25" (56 cm x 64 cm) | 25" x 26" (63 cm x 65 cm) | 35" x 30" (89 cm x 76 cm) | 26” x 35” (66 cm x 89 cm) | 30" x 42" (76 cm x 107 cm) | 30" x 42" (76 cm x 107 cm) | 35" x 30" (89 cm x 76 cm) | 26” x 35” (66 cm x 89 cm) | 30" x 42" (76 cm x 107 cm) |
| Chipper Rotor Opening | 4" x 10" (10 cm x 25 cm) | 3.5" x 9" (9 cm x 23 cm) | 5" x 10" (13 cm x 26 cm) | 7" x 12" (17 cm x 30 cm) | 10" x 15" (25 cm x 38 cm) | 5" x 10" (13 cm x 26 cm) | 7" x 12" (18 cm x 31 cm) | 10" x 17" (25 cm x 43 cm) | 10" x 17" (25 cm x 43 cm) | 5" x 10" (13 cm x 26 cm) | 7" x 12" (18 cm x 31 cm) | 10" x 17" (25 cm x 43 cm) |
| Number of Chipper Knives | 2 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
| Rotor Diameter | 25" (64 cm) | 25" (64 cm) | 25" (64 cm) | 28" (71 cm) | 36" (91 cm) | 25" (63 cm) | 28” (71 cm) | 36” (92 cm) | 36” (92 cm) | 25" (63 cm) | 28” (71 cm) | 36” (92 cm) |
| Rotor Weight | 74 lbs (34 kg) | 96 lbs (44 kg) | 125 lbs (57 kg) | 175 lbs (79 kg) | 400 lbs (181 kg) | 125 lbs (57 kg) | 185 lbs (84 kg) | 425 lbs (193 kg) | 425 lbs (193 kg) | 125 lbs (57 kg) | 185 lbs (84 kg) | 425 lbs (193 kg) |
| Discharge Chute Height | 72" (183 cm) | 60" (152 cm) | 66" (168 cm) | 82" (208 cm) | 89" (226 cm) | 74" (188 cm) | 90” (228 cm) | 100" (253 cm) | 100" (253 cm) | 74" (188 cm) | 90” (228 cm) | 100" (253 cm) |
| Discharge Chute Rotation | 360° | 360° | 360° | 360° | 360° | 360° | 360° | 360° | 360° | 360° | 360° | 360° |
| Drive System | Hydraulic | PTO Direct Drive | PTO Direct Drive | PTO Direct Drive | PTO Direct Drive | PTO Direct Drive | PTO Direct Drive | PTO Direct Drive | PTO Direct Drive | PTO Direct Drive | PTO Direct Drive | PTO Direct Drive |
| Rated RPM | 1000 | 540 - 1000 | 540 - 1000 | 540 - 1000 | 540 - 1000 | 540 - 1000 | 540 - 1000 | 540 - 1000 | 540 - 1000 | 540 - 1000 | 540 - 1000 | 540 - 1000 |
| Includes Hydraulic Hoses and Couplers | Yes | ... | ... | ... | ... | ... | ... | ... | ... | ... | ... | ... |
| Total Weight | 740 lbs (336 kg) | 395 lbs (179 kg) | 505 lbs (229 kg) | 728 lbs (330 kg) | 1143 lbs (519 kg) | 845 lbs (384 kg) | 1300 lbs (590 kg) | 1950 lbs (885 kg) | 2100 lbs (953 kg) | 845 lbs (384 kg) | 1300 lbs (590 kg) | 1950 lbs (885 kg) |
| Dimensions (LxWxH) | 80" x 57" x 72" (203 cm x 145 cm x 183 cm) | ... | ... | ... | ... | ... | ... | ... | ... | ... | ... | ... |
| Dimensions Open (LxWxH) | ... | 55" x 45" x 60" (140 cm x 114 cm x 152 cm) | 61" x 64" x 66" (155 cm x 163 cm x 168 cm) | 64" x 70" x 82" (163 cm x 178 cm x 208 cm) | 71" x 71" x 89" (180 cm x 180 cm x 226 cm) | 80" x 67" x 74" (204 cm x 171 cm x 188 cm) | 108" x 64" x 90" (275 cm x 163 cm x 228 cm) | 108" x 85" x 100" (273 cm x 215 cm x 253 cm) | 108" x 85" x 100" (273 cm x 215 cm x 253 cm) | 80" x 67" x 74" (204 cm x 171 cm x 188 cm) | 108" x 64" x 90" (275 cm x 163 cm x 229 cm) | 108" x 85" x 100" (273 cm x 215 cm x 253 cm) |
| Dimensions Folded (LxWxH) | ... | n/a | 43" x 42" x 66" (109 cm x 107 cm x 168 cm) | 48" x 42" x 82" (122 cm x 132 cm x 208 cm) | 61" x 58" x 89" (155 cm x 147 cm x 226 cm) | 62" x 61" x 74" (158 cm x 155 cm x 188 cm) | 83" x 56" x 90" (211 cm x 143 cm x 228 cm) | 85" x 71" x 100" (215 cm x 180 cm x 253 cm) | 85" x 71" x 100" (215 cm x 180 cm x 253 cm) | 62" x 61" x 74" (158 cm x 155 cm x 188 cm) | 83" x 56" x 90" (211 cm x 143 cm x 229 cm) | 85" x 71" x 100" (215 cm x 180 cm x 253 cm) |
| Mounting System | Universal Skidsteer Mounting Plate | Cat I, iMatch™ & Quick Hitch Compatible | Cat I, iMatch™ & Quick Hitch Compatible | Cat I iMatch™ & Quick Hitch Compatible, Cat II | Cat II, iMatch™ & Quick Hitch Compatible | Cat I, iMatch™ & Quick Hitch Compatible | Cat I iMatch™ & Quick Hitch Compatible, Cat II | Cat II, iMatch™ & Quick Hitch Compatible | Cat II, iMatch™ & Quick Hitch Compatible | Cat I, iMatch™ & Quick Hitch Compatible | Cat I, iMatch™ & Quick Hitch Compatible | Cat II, iMatch™ & Quick Hitch Compatible |
| PTO Height | ... | 13" - 19" (34 cm - 42 cm) | 13" - 19" (34 cm - 42 cm) | 19" (42 cm) | 23" (58 cm) | 22" - 27" (55 cm - 69 cm) | 26" (66 cm) | 34" (86 cm) | 34" (86 cm) | 22" - 27" (55 cm - 69 cm) | 26" (66 cm) | 34" (86 cm) |
HOST MACHINES
BX102RPI
| JOHN DEERE 5090M |  |
| JOHN DEERE 5100E |  |
| JOHN DEERE 5100M |  |
| JOHN DEERE 5115M |  |
| JOHN DEERE 5125M |  |
BX102RI
| JOHN DEERE 5090M | |
| JOHN DEERE 5100E | |
| JOHN DEERE 5100M | |
| JOHN DEERE 5115M | |
| JOHN DEERE 5125M | |
BX102R
| JOHN DEERE 5090M | |
| JOHN DEERE 5100E | |
| JOHN DEERE 5100M | |
| JOHN DEERE 5115M | |
| JOHN DEERE 5125M | |
BX72RI
| JOHN DEERE 4052HD |  |
| JOHN DEERE 4052M |  |
| JOHN DEERE 4052R |  |
| JOHN DEERE 4066M |  |
| JOHN DEERE 4066MHD |  |
| JOHN DEERE 4066R |  |
| JOHN DEERE 5045E |  |
| JOHN DEERE 5055E |  |
| JOHN DEERE 5065E |  |
| JOHN DEERE 5075E |  |
| JOHN DEERE 5075M |  |
BX72R
| JOHN DEERE 4052HD | |
| JOHN DEERE 4052M | |
| JOHN DEERE 4052R | |
| JOHN DEERE 4066M | |
| JOHN DEERE 4066MHD | |
| JOHN DEERE 4066R | |
| JOHN DEERE 5045E | |
| JOHN DEERE 5055E | |
| JOHN DEERE 5065E | |
| JOHN DEERE 5075E | |
| JOHN DEERE 5075M | |
BX52RI
| JOHN DEERE 2032R |  |
| JOHN DEERE 2038R |  |
| JOHN DEERE 3038E |  |
| JOHN DEERE 3039R |  |
| JOHN DEERE 3043D |  |
| JOHN DEERE 3046R |  |
| JOHN DEERE 4044M |  |
| JOHN DEERE 4044R |  |
| JOHN DEERE 4052HD | |
| JOHN DEERE 4052M | |
| JOHN DEERE 4052R | |
| KUBOTA LX3310HSD |  |
| KUBOTA LX3310HSDC |  |
BX102S
| JOHN DEERE 5090M | |
| JOHN DEERE 5100E | |
| JOHN DEERE 5100M | |
| JOHN DEERE 5115M | |
| JOHN DEERE 5125M | |
BX52R
| JOHN DEERE 3043D | |
| JOHN DEERE 3046R | |
| JOHN DEERE 4044M | |
| JOHN DEERE 4044R | |
| JOHN DEERE 4052HD | |
| JOHN DEERE 4052M | |
| JOHN DEERE 4052R | |
BX72S
| JOHN DEERE 4052HD | |
| JOHN DEERE 4052M | |
| JOHN DEERE 4052R | |
| JOHN DEERE 4066M | |
| JOHN DEERE 4066MHD | |
| JOHN DEERE 4066R | |
| JOHN DEERE 5045E | |
| JOHN DEERE 5055E | |
| JOHN DEERE 5065E | |
| JOHN DEERE 5075E | |
| JOHN DEERE 5075M | |
BX52S
| JOHN DEERE 1025R |  |
| JOHN DEERE 1026R |  |
| JOHN DEERE 2025R |  |
| JOHN DEERE 2032R | |
| JOHN DEERE 2038R | |
| JOHN DEERE 3025D |  |
| JOHN DEERE 3025E |  |
| JOHN DEERE 3032E |  |
| JOHN DEERE 3033R |  |
| JOHN DEERE 3035D |  |
| JOHN DEERE 3038E | |
| JOHN DEERE 3039R | |
| JOHN DEERE 3043D | |
| JOHN DEERE 3046R | |
| JOHN DEERE 4044M | |
| JOHN DEERE 4044R | |
| JOHN DEERE 4052HD | |
| JOHN DEERE 4052M | |
| JOHN DEERE 4052R | |
| KUBOTA BX23S |  |
| KUBOTA BX2380 |  |
| KUBOTA BX2680 |  |
| KUBOTA LX3310HSD | |
| KUBOTA LX3310HSDC | |
| KUBOTA LX2610HSDC |  |
BX36S
| OHN DEERE 1025R | |
| JOHN DEERE 2025R | |
| JOHN DEERE 2032R | |
| KUBOTA BX23S | |
| KUBOTA BX2380 | |
| KUBOTA BX2680 | |
| KUBOTA LX2610HSDC | |
In Package
- BX102RPI Chipper
- Hydraulic feed system
- Integrated winch
- Adjustable lift system
- Operator’s manual
Available Options
- Extended chute for high-volume disposal
- Additional feed control settings
- Replacement rotor and blades
