Wallenstein Log Grapple | Models LXG-210S & LXG-210SB | Grapple Opening 3"-40" inches | Engine Horsepower 12-50 HP | For Mini Skid Steer
Wallenstein Log Grapple | Models LXG-210S & LXG-210SB | Grapple Opening 3"-40" inches | Engine Horsepower 12-50 HP | For Mini Skid Steer
Regular price
$4,610.00
Regular price
Sale price
$4,610.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Wallenstein Log Grapple | Models LXG-210S & LXG-210SB | Grapple Opening 3"-40" inches | Engine Horsepower 12-50 HP | For Mini Skid Steer
DESCRIPTION
The Wallenstein LXG210S and LXG210SB Mini Skidsteer Log Grapples provide optimal hauling strength and maneuverability for tight spaces, making them ideal for landscapers and tree service professionals. Designed for easy "Plug and Play" attachment, these grapples are perfect for navigating narrow passages with a strong, spring-centered grapple that adapts to turns while keeping a steady hold on logs. With a grapple opening range from 3" to 38" and a lift capacity of up to 1000 lbs, they handle various sizes of branches and logs with precision. The LXG210S fits universal attachment plates for select mini skid steer models, including Toro, Vermeer, Ramrod, Boxer, and Ditch Witch, while the LXG210SB is specially designed for Bobcat Mini Skidsteers.
Key Features
- Compact Design: Ideal for tight spaces and narrow passages.
- Spring-Centered Return: Twists when turning and stays steady when holding logs.
- Versatile Grapple: Fits branches and logs from 3" to 38" in diameter.
- Easy Attachment: Compatible with universal plates for designated mini skid steers.
- High Lift Capacity: Handles up to 1000 lbs for efficient material movement.
- Adjustable Positioning: Lateral or in-line positioning for smooth log handling.
- Durable Construction: Built for heavy-duty use in landscaping and forestry.
- Plug and Play: Simple, hassle-free attachment setup.
- Enhanced Maneuverability: Spring return adapts easily to various angles and positions.
- Universal Fit: LXG210S fits Toro, Vermeer, Ramrod, Boxer, and Ditch Witch; LXG210SB fits Bobcat models.
| Image | Feature | Description |
|
Bypass Grapples |
Grapple tines interlink as tight as 3” (7.5 cm), ensuring easy handling of smaller logs and branches. |
|
|
Cantilever Cradle |
Leverage and secure your load with the serrated cradle when lifting logs in-line. |
|
|
Spring Centered Grapple With Locking Positions |
The grapple rotates when turning corners but stays straight when grabbing logs. Features lateral and in-line lock positions. |
Detailed Specifications
| Specification | LXG210S | LXG210SB |
|---|---|---|
| Lift Capacity | 1000 lbs (454 kg) | 1000 lbs (454 kg) |
| Engine HP Range | 12 - 50 | 12 - 50 |
| Recommended Hydraulic Flow | 3 gpm (11 lpm) | 3 gpm (11 lpm) |
| Grapple Opening | 3" - 40" (8 cm - 102 cm) | 3" - 40" (8 cm - 102 cm) |
| Grapple Rotation | 180° | 180° |
| Clamp Force | 9400 lbs (4264 kg) | 9400 lbs (4264 kg) |
| Rotator/Pivot Rating | 6750 lbs (3062 kg) | 6750 lbs (3062 kg) |
| Includes Hydraulic Hoses and Couplers | Yes | Yes |
| Total Weight | 285 lbs (130 kg) | 343 lbs (156 kg) |
| Dimensions (LxWxH) | 47" x 44" x 40" (120 cm x 112 cm x 102 cm) | 47" x 44" x 40" (120 cm x 112 cm x 102 cm) |
| Mounting System | Universal Mini Skidsteer Plate | Mini Skidsteer Plate (Bobcat) |
| Bypass Grapples | Yes | Yes |
| Spring Centered Grapple With Locking Positions | Yes | Yes |
| Choose Your Colour | No | No |
| Cantilever Cradle | Yes | Yes |
| Push Bar | No | No |
HOST MACHINES
