Wallenstein PTO Powered Manure Spreader | Model MX-130P | Machine Size Up-to 75 HP | Capacity 162.5 Cubic Ft | For Tractor

Product Description

Wallenstein PTO Powered Manure Spreader | Model MX-130P | Machine Size Up-to 75 HP | Capacity 162.5 Cubic Ft | For Tractor

DESCRIPTION

The Wallenstein MX130P Manure Spreader is a robust PTO-powered attachment designed to meet the demands of agricultural settings. With a heaped capacity of 130 bushels (162.5 cu. ft.) and a required horsepower range of 45 to 75, this spreader ensures efficient distribution across large areas. Its durable construction features a rustproof poly floor and a corrosion-resistant Cor-Ten weathering steel box, all powder-coated for long-lasting resilience against harsh outdoor conditions.

Equipped with a reliable chain and sprocket apron drive system, the MX130P offers consistent, even spreading, making it ideal for farms and agricultural fields. Large 11R22.5 retread tires support a substantial load capacity, while the 330 lb tongue weight provides balanced towing, making it a dependable choice for any manure spreading task.

Key Features

• High Capacity: Holds up to 130 bushels (162.5 cu. ft.) heaped, making it ideal for large-scale operations.
• PTO Driven: Compatible with tractors requiring 45-75 HP, providing efficient power transfer for optimal performance.
• Durable Build: Constructed with Cor-Ten weathering steel, offering exceptional rust resistance and long-lasting durability.
• Chain & Sprocket Drive: Ensures reliable apron movement for smooth and consistent operation.
• Powder Coated: Provides added protection against wear and weather, extending the life of the equipment.
• Large Dimensions: With a box size of 130" x 48" x 23" and a total length of 214", it accommodates a substantial amount of material.
• Robust Tires: Equipped with 11R22.5 retread tires, ensuring stability and easy maneuverability on various terrains.
• Consistent Spread: Features 10 paddles for even and uniform distribution of materials.
• Rustproof Floor: The tongue and groove poly floor resists corrosion, enhancing longevity and ease of maintenance.
• Easy Attachment: Designed to fit standard tractor PTO systems, allowing for quick and hassle-free connection.

Beater Speed Control & Clean Out Function		Rope controlled gearbox allows convenient spreader chain control from your tractor.
Easy Access Chain Tensioner		Check and adjust chain tension with ease.
Heavy Duty Bearings		Standard for smooth operation and longer life.
Hydraulic Hose Keeper		Store hose ends safely and cleanly when not in use.
One Piece Cor-Ten Box Side		Provides high corrosion resistance.
One Piece Welded Bed Frame		The trailer tongue, axle assembly and beaters rely on the rigidity of the frame which prevents the box from premature wearing and cracking.
Replaceable Paddles on Bottom Feeder		Swap out worn or damaged paddles and get back to work with the bolt-on design.
Tongue-and-Groove Poly Floor Boards		Easy to clean poly floor boards will not rust or rot.



Detailed Specifications

In Package

• Wallenstein MX130P Manure Spreader
• PTO drive shaft
• Operator's manual and maintenance guide

Available Options

• Hydraulic endgate for controlled material release
• Additional spare paddles and chain replacements
