Product Description
DJI Zenmuse P1 | Full-Frame 45MP Photogrammetry Camera | For DJI Matrice 300
DESCRIPTION
THE NEW BENCHMARK FOR AERIAL SURVEYING
The Zenmuse P1 integrates a full-frame sensor with interchangeable fixed-focus lenses on a 3-axis stabilized gimbal. Designed for photogrammetry flight missions, it takes efficiency and accuracy to a whole new level.
- Accuracy without GCPs - 3 cm horizontally / 5 cm vertically
- High Efficiency - 3 km2 covered in a single flight
- 45 MP Full-frame Sensor
- 3-axis Stabilized Gimbal - Smart Oblique Capture
- Global Mechanical Shutter - Shutter Speed 1/2000 Seconds
- TimeSync 2.0 - synchronization at the microsecond level
YOUR GO-TO TOOL FOR AERIAL PHOTOGRAMMETRY
- EXTRAORDINARY EFFICIENCY: The P1 includes a full-frame, low-noise high-sensitivity sensor that can take a photo every 0.7 s during the flight, and covering 3 km2 [2] in a single flight.
- REMARKABLE ACCURACY: Equipped with a global mechanical shutter and the all-new TimeSync 2.0 system, which synchronizes time across modules at the microsecond level, the Zenmuse P1 lets users capture centimeter-accurate data combined with the real-time position and orientation compensation technology.
- ROBUST VERSATILITY: Create 2D, 3D, and detailed models thanks to the integrated 3-axis gimbal that can be outfitted with 24/35/50mm lenses and the Smart Oblique Capture feature.
EFFICIENCY TO COVER IT ALL
FULL-FRAME CAMERA
- 45MP Full-frame Sensor
- 4.4μm Pixel Size
- Low-noise, high sensitivity imaging extends daily operational time
- Take a photo every 0.7 s during the flight
- TimeSync 2.0 aligns the camera, flight controller, RTK module, and gimbal at the microsecond level
FLEXIBILITY TO CAPTURE IT ALL
MULTIPLE FIXED-FOCUS LENS OPTIONS
- Global Mechanical Shutter, Shutter Speed 1/2000 Seconds
- Sends the median exposure pulse in microseconds
- Supports 24/35/50mm lenses with DJI DL mounts
WORK SMART, WORK FAST
SMART OBLIQUE CAPTURE
Cover 7.5 km2 in a single workday with the P1. Elevate the efficiency of your oblique photography mission using Smart Oblique Capture, where the gimbal automatically rotates to take photos at the different angles needed. Only photos essential to the reconstruction will be taken at the edge of the flight area, increasing the efficiency of post processing by 20% to 50%
SMART DATA MANAGEMENT
Your mission data management - streamlined.
Mission result files are automatically associated with the Mission Name and Mission Time.
A centralized storage location for photos, GNSS data, and TimeStamps.MRK files.
The image metadata contains the camera’s intrinsic and extrinsic parameters and the status of RTK.
FIELDWORK REPORT
Verify data quality immediately post-flight by checking the position data and number of the images acquired, as well as RTK status and positioning accuracy.
A MISSION MODE FOR ANY SCENARIO
2D Orthomosaic Mission 3D Oblique Mission Detailed Modeling Mission Real-time Mapping Mission Generate orthomosaics without GCPs using the P1, perfect for medium to large-area operations.Key Features
- Global Mechanical Shutter: Achieve 1/2000 second shutter speed for precise data capture without distortion.
- Smart Data Management: Automatically organizes mission data with timestamps, GNSS data, and camera parameters.
- Mission Versatility: Supports 2D, 3D, and detailed modeling missions for various industries.
- Fieldwork Reports: Instantly verify data quality post-flight, including RTK status and positioning accuracy.
- Integrated Workflow: Seamlessly connects with DJI Terra for streamlined data processing.
Detailed Specification
Camera Specifications
| Attribute | Details |
|---|---|
| Sensor | 45MP Full-Frame CMOS |
| Pixel Size | 4.4 μm |
| Shutter | Global Mechanical, 1/2000 sec |
| Capture Speed | 1 photo every 0.7 seconds |
| Lens Options | 24mm, 35mm, 50mm (fixed-focus) |
Gimbal Specifications
| Attribute | Details |
|---|---|
| Stabilization | 3-Axis Stabilized |
| Controllable Range | Pan: ±320°, Tilt: -90° to +30° |
Performance Specifications
| Attribute | Details |
|---|---|
| Accuracy (Without GCPs) | 3 cm horizontal, 5 cm vertical |
| Area Coverage (Single Flight) | 3 km² |
| Smart Oblique Capture | Supports efficiency improvement |
Compatibility
| Attribute | Details |
|---|---|
| Compatible Drone | DJI Matrice 300 RTK |
In Package
- 1x Gimbal and Camera
- 1x DJI DL 35mm Lens
- 1x MicroSD Card (16GB)
- 1x SD Card (128GB)
- 1x Storage Case
- 1x Camera Body Cap
- 1x Lens Rear Cap
- 1x Lens Cleaning Cloth
- 1x Lens Cap
- 1x DJI Terra Activation Code
Ideal Applications
- Topographic Mapping: Achieve 1:500 scale accuracy without GCPs.
- Cadastral Surveying: Quickly generate accurate 3D models.
- Disaster Management: Real-time aerial overviews for emergency response.
- Natural Resource Management: Analyze forests and water bodies with precision.
