Product Description
Teledyne FLIR Hadron Camera
DESCRIPTION
Radiometric. Zoom. Precision. Made in the USA.
The FLIR VUE TZ20-R is a high-performance thermal zoom payload designed for the DJI Matrice 300 and Matrice 200 V2 series. Powered by dual FLIR Boson® 640×512 sensors, the TZ20-R delivers unmatched thermal zoom capabilities with 4x more radiometric pixels on target than any comparable system. This allows inspectors, first responders, and public safety pilots to measure temperatures and identify critical heat signatures from a safe, remote distance.
With 5x optical zoom, 4x digital zoom, and the ability to toggle between wide (95° HFOV) and narrow (18° HFOV) fields of view, the TZ20-R is ideal for applications ranging from utility and solar inspections to search and rescue, firefighting, and law enforcement operations.
Its plug-and-play design connects via DJI’s Skyport V2.0, integrates seamlessly with the DJI Pilot app, and offers radiometric recording to dual microSD cards, making it a versatile and powerful payload for mission-critical workflows.
Key Features
- Unmatched Thermal Zoom: Dual FLIR Boson sensors provide 5x optical and 4x digital zoom, giving up to 20x effective thermal zoom.
- Radiometric Accuracy: Capture radiometric JPEG, TIFF, CSQ files for accurate temperature measurement and post-processing.
- High Resolution & Thermal Sensitivity: Dual 640 × 512 resolution thermal sensors with 85 mK sensitivity @ f/1.0 deliver crisp, detailed thermal imagery.
- DJI Integration: Fully compatible with DJI Matrice 300 and 200 V2 via Skyport 2.0. Controlled via DJI Pilot app.
- Multiple Viewing Modes: Toggle between 95° wide field of view and 18° narrow field of view, plus intermediate zoom levels (5x, 10x, 20x).
- Weather Resistant: IP44-rated environmental sealing allows operation in demanding outdoor conditions.
- Flexible Storage & Recording: Record thermal stills and video to dual microSD cards (2x64GB included; supports up to 2x256GB).
- Compact and Lightweight: Weighs just 640g, maintaining agility and flight time on supported airframes.
Detailed Specifications
| Category | Specification |
|---|---|
| Sensor Type | Dual FLIR Boson 640 × 512 thermal sensors |
| Pixel Pitch | 12 μm LWIR IR |
| Thermal Sensitivity | < 85 mK @ f/1.0 |
| Zoom | 5x Optical (WFOV/NFOV), 4x Digital, up to 20x Effective |
| Field of View (FOV) | Wide: 95° HFOV (4.9mm EFL) Narrow: 18° HFOV (24mm EFL) |
| Video Streaming | 640 × 512 @ 25 Hz |
| Still Image Capture | Radiometric JPEG, JPEG, TIFF |
| Video Recording | MPEG, Radiometric CSQ, Multipage TIFF (wide & narrow FOV) |
| Gimbal | 3-axis stabilization Pitch: +30° to -120° Yaw: ±320° |
| Power Supply | 13.6V / 2A via Skyport 2.0 |
| Mounting Interface | DJI Skyport 2.0 / X-Port Gimbal Mount |
| Control Interface | DJI Pilot App |
| Compatible Airframes | DJI Matrice 300 RTK DJI Matrice 200 Series V2 |
| Storage | Dual microSD card slots (2x64GB included; supports 2x256GB max) |
| Operating Temperature | -20°C to +60°C (-4°F to 140°F) |
| Environmental Rating | IP44 |
| Weight | 640g |
| Dimensions (Payload Only) | 75 × 70 × 55 mm (2.95 × 2.75 × 2.17 in) |
| Dimensions (With Gimbal) | 128 × 154 × 141 mm (5.04 × 6.06 × 5.55 in) |
