HLA Attachments Power Tine Pallet Fork 7500# Less Mount | Model 48", 54", 60" Pallet Fork | 48"-54"-60" Fork Length | For Loader

HLA Attachments Power Tine Pallet Fork 7500# Less Mount | Model 48", 54", 60" Pallet Fork | 48"-54"-60" Fork Length | For Loader

$5,886.00
$5,886.00
Sale Sold out
Customizable
Fast
24/7 Support
  • Mount Selection Required: Choose the appropriate loader mount from a variety of compatible options for easy attachment.
  • Hydraulic Sliding Tines: Designed for smooth operation, the tines slide equally in and out, ideal for handling root balls and large, clamped loads.
  • Heavy Duty 7500# Rating: Built with strength to handle tough loads, rated for up to 7500 lbs.
  • Multiple Sizes Available: Available in 48", 54", and 60" sizes to suit different needs and equipment sizes.
  • Rugged Construction: The robust design ensures long-lasting durability, with the 60" model weighing approx. 865 lbs, 54" weighing approx. 840 lbs, and 48" weighing approx. 810 lbs.
View full details

Product Description

HLA Attachments Power Tine Pallet Fork 7500# Less Mount | Model 48", 54", 60" Pallet Fork | 48"-54"-60" Fork Length | For Loader



DESCRIPTION

Upgrade your material handling with the robust HLA Power Tine Pallet Forks designed for unmatched strength, precision, and versatility. Whether you’re lifting heavy pallets, clamping root balls, or maneuvering bulky items, these forks offer a rugged 7,500-pound rated capacity combined with hydraulic sliding tines for smooth, synchronized movement.

The hydraulic sliding tines move equally in and out, delivering excellent clamping ability that’s ideal for landscaping, construction, farming, and industrial applications. Available in 48", 54", and 60" widths, these forks adapt seamlessly to your loader, giving you the flexibility to handle a variety of loads safely and efficiently.

Please note, the Power Tine Pallet Forks are sold less mount, allowing you to select the perfect loader mount option to fit your machine. Choose from a wide range of compatible mounts including John Deere, Kubota, Westendorf, Bush Hog, and more.

Durable, reliable, and easy to operate, the HLA Power Tine Pallet Forks deliver performance that you can count on every job, every day.

Key Features

  • Hydraulic Sliding Tines for Precision Clamping Move tines equally in and out to securely grip materials like root balls and bulky loads with ease.
  • Heavy-Duty 7,500 lb Rated Capacity Built tough for demanding outdoor, farming, and industrial work environments.
  • Multiple Width Options (48", 54", 60") Choose the size that fits your specific lifting needs and loader compatibility.
  • Mount Selection Flexibility Sold less mount so you can pick from a variety of loader mounts including John Deere, Kubota, Westendorf, Bush Hog, and others.
  • Rugged Construction & Reliable Performance Engineered for durability and long-term use, reducing downtime on the job site.
  • Versatile Use Cases Perfect for agriculture, landscaping, construction, and material handling applications.
  • Easy Installation Compatible with multiple loader models for quick and secure mounting.

Detailed Specifications

Specification 48" Power Tine Pallet Fork 54" Power Tine Pallet Fork 60" Power Tine Pallet Fork
Model Number HDN7548 HDN7554 HDN7560
Fork Width 48 inches 54 inches 60 inches
Rated Capacity 7,500 lbs 7,500 lbs 7,500 lbs
Hydraulic Sliding Tines Yes Yes Yes
Tine Movement Equal synchronized sliding Equal synchronized sliding Equal synchronized sliding
Weight Approx. 810 lbs Approx. 840 lbs Approx. 865 lbs
Mount Included No (sold less mount) No (sold less mount) No (sold less mount)
Compatible Loader Mounts John Deere, Kubota, Westendorf, Bush Hog, and more John Deere, Kubota, Westendorf, Bush Hog, and more John Deere, Kubota, Westendorf, Bush Hog, and more
Ideal For Clamping root balls, pallets, heavy loads Clamping root balls, pallets, heavy loads Clamping root balls, pallets, heavy loads
Manufacturer HLA Attachments HLA Attachments HLA Attachments



Manuals & Documents

POWER TINE FORKS MANUAL

LOADER MOUNTS
