Product Description
Horst Wagons 4WS Swather Draper Header Carrier | Model SHCF36 & SHCF45 | Top Rail Wheelbase 36' & 45' | Horsepower 80 HP | For Tractor
DESCRIPTION
The Horst Wagons 36' and 45' 4WS Swather Draper Header Carriers are engineered for superior maneuverability and safe transport of combine headers in challenging agricultural conditions. Their advanced four-wheel steering system enables precise tracking behind the tractor, reducing transport risks and improving handling on uneven or narrow routes. The SHCF36 model features a 36-foot top rail suitable for headers up to 35 feet, while the SHCF45 extends support to headers as large as 45 feet, accommodating a wide range of equipment sizes. Both models come equipped with adjustable top rails for customizable fit, double spring balancers that absorb shocks and reduce header stress during transit, and tool-free universal mount brackets designed for quick, flexible installation. Built with tapered roller bearings and heavy-duty tie rod ends, these carriers maintain stability and durability over prolonged use, even under heavy loads. Designed for tractors with 80 HP, they are compatible exclusively with Agco, Challenger, Hesston, MacDon, and Massey Ferguson headers, ensuring optimal integration. Ideal for professional agricultural operations, these carriers combine precision engineering and robust construction to optimize header handling, transport safety, and operational efficiency across diverse farming environments.
Key Features
- Four-Wheel Steering: Ensures perfect cornering and precise tracking behind the towing vehicle.
- Models: SHCF36 (36′ top rail) & SHCF45 (46′ top rail) — 4‑Wheel Steer Swather Draper Head Transports.
- Compatibility: Accepts Agco, Challenger, Hesston, MacDon & Massey Ferguson swather draper heads.
- Recommended Tractor Power: ~80 HP or more for safe towing and control of loaded carrier.
- Adjustable Top Rail: Customizable to fit different header sizes for secure transport.
- Tool-Free Mounts: Includes 2 universal swather mount brackets with pivoting head supports for easy operation.
- Heavy-Duty Tie Rods: Reduces sway for reliable and stable trailering.
- Safety Chain: Added for secure transportation on uneven terrains.
- Double Spring Balancer: Provides additional stability during operation.
- Notched Rail Design: Simplifies header placement and secures load.
- Auto-Locking Hitch: Adjustable length hitch for effortless hook-up.
- Tapered Bearings: On kingpins for smooth and sway-free performance.
- Durable Tires: 20.5x8-10 (F Range) tires on 10x6x6 rims provide excellent load support.
Detailed Specifications
| Attribute | SHCF36 | SHCF45 |
|---|---|---|
| Brand | Horst Wagons | Horst Wagons |
| Model | SHCF36 | SHCF45 |
| Type | 4‑Wheel Steer Swather Draper Head Transport | 4‑Wheel Steer Swather Draper Head Transport |
| Top Rail Length | 36′ | 46′ |
| Maximum Head Size | 35′ | 45′ |
| Wheelbase | 30′ | 30′ |
| Bridged Top Rail | Standard | Standard |
| Maximum Rated Gross Capacity | 6,600 lb. | 6,600 lb. |
| Tongue Length (Adjustable) | 11′ 4″ – 14′ 4″ | 11′ 4″ – 14′ 4″ |
| Safety Chain | Standard | Standard |
| Steering | 4‑wheel steer | 4‑wheel steer |
| Bearings on King Pins | Tapered roller | Tapered roller |
| Universal Mount Brackets | 2 tool‑free with pivoting head supports | 2 tool‑free with pivoting head supports |
| Ratchet Straps | 2 included | 2 included |
| Top Rail Adjustment | Adjustable | Adjustable |
| Double Spring Balancer | Standard | Standard |
| Hitch Type | Length adjustable with auto lock | Length adjustable with auto lock |
| Tire Size | 20.5 × 8‑10 (F Range) | 20.5 × 8‑10 (F Range) |
| Rim Size | 10 × 6 × 6 | 10 × 6 × 6 |
| Horsepower | 80 HP | 80 HP |
| Approximate Weight | 2,675 lb. (less rims & tires) | 2,795 lb. (less rims & tires) |
| Optional Features | LK30 road signal light kit | LK30 road signal light kit |
| Primary Use | Transporting swather draper heads (Agco, Challenger, Hesston, MacDon, Massey Ferguson) | Transporting swather draper heads (Agco, Challenger, Hesston, MacDon, Massey Ferguson) |
