Product Description
Loflin Fabrication | Compact Tractor Rock Bucket Grapple | 60"-84" Width | 36½" Opening | 25–50 HP | For Tractors
DESCRIPTION
The Loflin Fabrication Compact Tractor Rock Bucket Grapple, a robust and versatile attachment designed specifically for compact tractors operating between 25 to 50 horsepower. This exceptional tool is engineered to handle heavy rocks and debris with ease, making it an ideal choice for agricultural, landscaping, and construction applications.
The Compact Tractor Rock Bucket Grapple features a unique design that allows dirt to fall through, making it perfect for sifting and sorting materials. Constructed from 3/8” thick steel, this grapple bucket is built to withstand the rigors of demanding work environments, ensuring durability and reliable performance.
Equipped with independent grapple tines, this attachment provides superior control when grappling uneven loads, allowing you to tackle a variety of tasks with confidence. The powder-coated finish enhances its longevity, protecting it from wear and tear while maintaining its sleek appearance.
Key Features
- Durable Powder-Coated Finish Shields the grapple against wear, corrosion, and the elements.
- 3⁄8” Thick Steel Construction Built to handle the stress of lifting and transporting dense and irregular materials like rocks and stumps.
- Independent Grapple Tines Grip uneven loads securely for increased versatility and control.
- Optimized Tine Spacing Standard 3⅜” spacing allows effective sifting of dirt and debris wider spacings available by request (no less than 3").
- Large Opening Width (36½") Accommodates bulky or awkward loads with ease.
- Greasable Pins & Hinge Points Simplifies routine maintenance and extends lifespan.
- Jobsite Ready Hydraulic Setup Includes Parker hoses, fittings, and couplers no additional setup needed.
- Quick-Attach Compatible Fits most compact tractors with standard quick-attach systems for seamless integration.
Detailed Specifications
| Specification | Details |
|---|---|
| Brand | Loflin Fabrication |
| Model Name | Compact Tractor Rock Bucket Grapple |
| Type | Rock Bucket Grapple (Double Tine) |
| Working Width Options | 60″, 66″, 72″, 78″, 84″ |
| HP Compatibility | Recommended for 25-50 HP machines |
| Construction Material | 3/8” thick steel |
| Tine Spacing | 3⅜” (wider spacing available, no less than 3″) |
| Grapple Tine Operation | Independent |
| Opening Width | 36½” |
| Pivot Points | Greasable pins |
| Hydraulic Components | Parker brand hoses, fittings, and couplers |
| Finish | Powder coated |
| Special Features | Allows dirt to fall through (sifting capability) |
| Mount Compatibility | Universal Quick Attach |
| Approx. Weights (by width) | 60″: 605 lbs, 66″: 595 lbs, 72″: 645 lbs, 78″: 652 lbs, 84″: 677 lbs |
| Key Benefit | Efficiently handles rocks and debris for compact tractors, with excellent material sifting capabilities and heavy-duty construction. |
Comparison Chart
|
Specs |
031030- 1060 |
031030- 1066 |
031030- 1072 |
|---|---|---|---|
|
Width |
60" |
66" |
72" |
|
Opening Width |
36 ½" |
36 ½" |
36 ½" |
|
Weight (lbs) |
605 |
595 |
645 |
|
Tine Thickness |
3⁄8” Steel |
3⁄8” Steel |
3⁄8” Steel |
|
Tine Spacing |
3⅜" (Wider Available) |
3⅜" (Wider Available) |
3⅜" (Wider Available) |
|
Const- ruction |
Heavy-Duty Welded |
Heavy-Duty Welded |
Heavy-Duty Welded |
|
Recom. HP |
25–50 HP |
25–50 HP |
25–50 HP |
| Specification | 0310301078 | 0310301084 |
|---|---|---|
| Model | 0310301078 | 0310301084 |
| Width | 78" | 84" |
| Opening Width | 36 ½" | 36 ½" |
| Weight (lbs) | 652 | 677 |
| Tine Thickness | 3⁄8” Steel | 3⁄8” Steel |
| Tine Spacing | 3⅜" (Wider Available) | 3⅜" (Wider Available) |
| Construction | Heavy-Duty Welded | Heavy-Duty Welded |
| Recommended HP | 25–50 HP | 25–50 HP |
