Product Description
NM Attachments General Purpose Bucket | Model GP & LM Series | Widths 1โ6 Yards | Machine Class 50โ150 | Machine Size 10,000โ40,000 lbs | For Wheel Loadersย
DESCRIPTION
The NM Attachments GP & LM Series General Purpose Buckets are precision-engineered for wheel loaders within machine classes 50 to 150, supporting equipment weighing between 10,000 and 40,000 pounds. Designed for robust general-purpose and light material handling applications, these buckets are constructed from premium high-strength steel to withstand rigorous use while maintaining durability. A bolt-on cutting edge enhances longevity by providing an easily replaceable wear surface, minimizing downtime and maintenance costs. Available in capacities from 1 to 6 cubic yards, each bucket size is optimized to meet the performance demands of specific loader classes. Proper mount specification is essential to ensure precise compatibility with OEM couplers, guaranteeing secure attachment and operational safety. These buckets excel at moving a wide range of materials including soil, gravel, mulch, and other bulk goods, delivering consistent performance, strength, and operational efficiency in diverse job site conditions. With a focus on reliability and adaptability, the GP & LM Series stands as a dependable choice for professional operators seeking durable and versatile loading solutions.Key Features
- Model Identification: GP & LM Series GP = General Purpose Bucket; LM = Light Material Bucket. Model codes like 50GP-100 or 150LM-600 indicate loader class and bucket capacity in cubic yards.
- Bucket Capacities: 1 to 6 Yards Available in multiple sizes to suit light, medium, and heavy-duty material handling tasksโfrom compact site work to high-volume bulk loading.
- Bucket Widths: Approx. 72" to 102" Width varies by model and capacity. Smaller buckets (1โ1.5 yd) typically range from 72"โ84", while larger buckets (2.5โ6 yd) may span 96"โ102" or more.
- Bucket Weight Capacity: Up to 6,000 lbs Designed to handle material loads ranging from 2,000 lbs (light material) to 6,000 lbs (dense aggregates), depending on bucket size and loader class.
- Machine Class Range: Class 50โ150 Compatible with wheel loaders from 10,000 to 40,000 lbs operating weight, ensuring proper balance and lift performance.
- Bolt-On Cutting Edge Replaceable edge enhances durability, protects the base lip, and simplifies maintenance or replacement.
- Mount Compatibility: Must specify mount type for proper fit with OEM couplers (e.g., CAT Fusion, ISO, JRB, Volvo, Deere, etc.).
- Rugged Steel Construction: Built for high-impact environments with reinforced side plates, wear strips, and heavy-duty welds.
- Application: Versatility Ideal for construction, landscaping, aggregates, snow removal, waste handling, and bulk material transport.
- OEM Loader: Support Compatible with leading brands including Caterpillar, Deere, Komatsu, Volvo, Case, Hyundai, JCB, SDLG, and more.
Detailed Specifications
50GP-100
| Attribute | Details |
|---|---|
| Model | 50GP-100 |
| Part Number | 50GP-100 / 50GP-BOE |
| Bucket Type | General Purpose |
| Class | Class 50 |
| Machine Size | ~10,000โ12,000 lbs |
| Capacity | 1 Yard |
| Cutting Edge | Bolt-On |
| Mount Required | Yes |
50GP-125
| Attribute | Details |
|---|---|
| Model | 50GP-125 |
| Part Number | 50GP-125 / 50GP-BOE |
| Bucket Type | General Purpose |
| Class | Class 50 |
| Machine Size | ~10,000โ12,000 lbs |
| Capacity | 1.25 Yard |
| Cutting Edge | Bolt-On |
| Mount Required | Yes |
50GP-150
| Attribute | Details |
|---|---|
| Model | 50GP-150 |
| Part Number | 50GP-150 / 50GP-BOE |
| Bucket Type | General Purpose |
| Class | Class 50 |
| Machine Size | ~10,000โ12,000 lbs |
| Capacity | 1.5 Yard |
| Cutting Edge | Bolt-On |
| Mount Required | Yes |
100GP-150
| Attribute | Details |
|---|---|
| Model | 100GP-150 |
| Part Number | 100GP-150 / 100GP-BOE |
| Bucket Type | General Purpose |
| Class | Class 100 |
| Machine Size | ~12,000โ16,000 lbs |
| Capacity | 1.5 Yard |
| Cutting Edge | Bolt-On |
| Mount Required | Yes |
100GP-175
| Attribute | Details |
|---|---|
| Model | 100GP-175 |
| Part Number | 100GP-175 / 100GP-BOE |
| Bucket Type | General Purpose |
| Class | Class 100 |
| Machine Size | ~12,000โ16,000 lbs |
| Capacity | 1.75 Yard |
| Cutting Edge | Bolt-On |
| Mount Required | Yes |
100GP-200
| Attribute | Details |
|---|---|
| Model | 100GP-200 |
| Part Number | 100GP-200 / 100GP-BOE |
| Bucket Type | General Purpose |
| Class | Class 100 |
| Machine Size | ~12,000โ16,000 lbs |
| Capacity | 2 Yard |
| Cutting Edge | Bolt-On |
| Mount Required | Yes |
125GP-200
| Attribute | Details |
|---|---|
| Model | 125GP-200 |
| Part Number | 125GP-200 / 125GP-BOE |
| Bucket Type | General Purpose |
| Class | Class 125 |
| Machine Size | ~16,000โ20,000 lbs |
| Capacity | 2.25 Yard |
| Cutting Edge | Bolt-On |
| Mount Required | Yes |
125GP-225
| Attribute | Details |
|---|---|
| Model | 125GP-225 |
| Part Number | 125GP-225 / 125GP-BOE |
| Bucket Type | General Purpose |
| Class | Class 125 |
| Machine Size | ~16,000โ20,000 lbs |
| Capacity | 2.5 Yard |
| Cutting Edge | Bolt-On |
| Mount Required | Yes |
125GP-250
| Attribute | Details |
|---|---|
| Model | 125GP-250 |
| Part Number | 125GP-250 / 125GP-BOE |
| Bucket Type | General Purpose |
| Class | Class 125 |
| Machine Size | ~16,000โ20,000 lbs |
| Capacity | 2.5 Yard |
| Cutting Edge | Bolt-On |
| Mount Required | Yes |
150GP-200
| Attribute | Details |
|---|---|
| Model | 150GP-200 |
| Part Number | 150GP-200 / 150GP-BOE |
| Bucket Type | General Purpose |
| Class | Class 150 |
| Machine Size | ~20,000โ30,000 lbs |
| Capacity | 2 Yard |
| Cutting Edge | Bolt-On |
| Mount Required | Yes |
150GP-225
| Attribute | Details |
|---|---|
| Model | 150GP-225 |
| Part Number | 150GP-225 / 150GP-BOE |
| Bucket Type | General Purpose |
| Class | Class 150 |
| Machine Size | ~20,000โ30,000 lbs |
| Capacity | 2.25 Yard |
| Cutting Edge | Bolt-On |
| Mount Required | Yes |
150GP-250
| Attribute | Details |
|---|---|
| Model | 150GP-250 |
| Part Number | 150GP-250 / 150GP-BOE |
| Bucket Type | General Purpose |
| Class | Class 150 |
| Machine Size | ~20,000โ30,000 lbs |
| Capacity | 2.5 Yard |
| Cutting Edge | Bolt-On |
| Mount Required | Yes |
150GP-275
| Attribute | Details |
|---|---|
| Model | 150GP-275 |
| Part Number | 150GP-275 / 150GP-BOE |
| Bucket Type | General Purpose |
| Class | Class 150 |
| Machine Size | ~20,000โ30,000 lbs |
| Capacity | 2.75 Yard |
| Cutting Edge | Bolt-On |
| Mount Required | Yes |
150GP-300
| Attribute | Details |
|---|---|
| Model | 150GP-300 |
| Part Number | 150GP-300 / 150GP-BOE |
| Bucket Type | General Purpose |
| Class | Class 150 |
| Machine Size | ~20,000โ30,000 lbs |
| Capacity | 3 Yard |
| Cutting Edge | Bolt-On |
| Mount Required | Yes |
150LM-600
| Attribute | Details |
|---|---|
| Model | 150LM-600 |
| Part Number | 150LM-600 |
| Bucket Type | Light Material |
| Class | Class 150 |
| Machine Size | ~20,000โ30,000 lbs |
| Capacity | 6 Yard |
| Cutting Edge | Bolt-On |
| Mount Required | Yes |
HOST MACHINES
- CATERPILLAR 926M, ย ย
- CATERPILLER 930M, ย ย
2.25 YARD WHEEL LOADER CLASS 150 - CATERPILLAR 926M, ย ย
- CATERPILLER 930M, ย ย
2.5 YARD WHEEL LOADER CLASS 150 - CATERPILLAR 926M, ย ย
- CATERPILLER 930M, ย ย
2.75 YARD WHEEL LOADER CLASS 150 - CATERPILLAR 926M, ย ย
- CATERPILLER 930M, ย ย
3 YARD WHEEL LOADER CLASS 150 - CATERPILLAR 926M, ย ย
- CATERPILLER 930M,
