SPECIFICATIONS
These features have made Rockland choppers famous: heavy-duty box frame, doubler plates at all critical stress areas
- Massive axle bearings, frame over axle design for maximum clearance, hinged drawbar for transportation needs
- Heavy-duty swivel hitch. Whether it be a single drum unit or a multi-drum model
- Specify a Rockland RC Rolling Chopper for years of dependable, trouble-free chopping.
- Multi-drum models have two extra blades on the rear drum to prevent
tracking. - Multi-drum arrangements are recommended for chopping and killing light to medium growth.
- These robust machines are designed for land clearing and vegetation management.
C-6/10"
- Cutting Width: 72 inches (1829 mm)
- Overall Width: 88
- Drum Diameter: 36
- Blade Size: 3/4x6
- Number Of Blades: 10
- Welded Blade Weight (Empty/Full): 4700 / 7700
- Reversible Blade Weight (Empty/Full): 5200 / 8200
C-7/10,20"
- Cutting Width: 84 inches (2134 mm)
- Overall Width: 104
- Drum Diameter: 48
- Blade Size: 3/4x6
- Number Of Blades: 10
- Welded Blade Weight (Empty/Full): 8100 / 14800
- Reversible Blade Weight (Empty/Full): 9300 / 15500
C-8/25"
- Cutting Width: 96 inches (2438 mm)
- Overall Width: 120
- Drum Diameter: 60
- Blade Size: 1x10
- Number Of Blades: 12
- Welded Blade Weight (Empty/Full): 12100 / 21800
- Reversible Blade Weight (Empty/Full): 14400 / 22190
C-10/25,30"
- Cutting Width: 120 inches (3048 mm)
- Overall Width: 144
- Drum Diameter: 60
- Blade Size: 1x10
- Number Of Blades: 12
- Welded Blade Weight (Empty/Full): 14600 / 28300
- Reversible Blade Weight (Empty/Full): 17200 / 29700
C-12/30,40"
- Cutting Width: 144 inches (3658 mm)
- Overall Width: 168
- Drum Diameter: 60
- Blade Size: 1x10
- Number Of Blades: 12
- Welded Blade Weight (Empty/Full): 17400 / 34300
- Reversible Blade Weight (Empty/Full): 20600 / 36100
C-14/40,50"
- Cutting Width: 168 inches (4267 mm)
- Overall Width: 192
- Drum Diameter: 60
- Blade Size: 1x10
- Number Of Blades: 12
- Welded Blade Weight (Empty/Full): 20000 / 38500
- Reversible Blade Weight (Empty/Full): 23800 / 40400
C-16/50&up
- Cutting Width: 192 inches (4877 mm) and beyond
- Overall Width: 216
- Drum Diameter: 72
- Blade Size: 1x10
- Number Of Blades: 12
- Welded Blade Weight (Empty/Full): 33600 / 62100
- Reversible Blade Weight (Empty/Full): 41200 / 68700
Recommended Horsepower
-
-
Single Drum Models:
- C-6/10: Tractor Drawbar HP Required 35-50
- C-7/10,20: Tractor Drawbar HP Required 50-75
- C-8/25: Tractor Drawbar HP Required 100-130
- And so on for other models.
-
Tandem Drum Models:
- C-10/25,30: Tractor Drawbar HP Required 185 Up
- C-12/30,40: Tractor Drawbar HP Required 230 Up
- And so forth.
-
Triple Drum Models:
- C-14/40,50: Tractor Drawbar HP Required 270 Up
- And any additional models.
-
Single Drum Models:
Tandem C-26"(Multi-Drum RC)
- Cutting Width: 72
- Overall Width: 96
- Drum Diameter: 36
- Blade Size: 3/4x6
- Number Of Blades: 22
- Weight Empty (Std/Rev): 9100 / 10100
-
Weight Full (Std/Rev): 13500 / 14500
Dual CD-26"(Multi-Drum RC)
- Cutting Width: 132
- Overall Width: 156
- Drum Diameter: 36
- Blade Size: 3/4x6
- Number Of Blades: 20
- Weight Empty (Std/Rev): 9085 / 10085
- Weight Full (Std/Rev): 13465 / 14500
Triple C-36"(Multi-Drum RC)
- Cutting Width: 192
- Overall Width: 216
- Drum Diameter: 36
- Blade Size: 3/4x6
- Number Of Blades: 30
- Weight Empty (Std/Rev): 14650 / 16150
- Weight Full (Std/Rev): 21250 / 22750
Tandem C-27"(Multi-Drum RC)
- Cutting Width: 84
- Overall Width: 108
- Drum Diameter: 48
- Blade Size: 3/4x6
- Number Of Blades: 22
- Weight Empty (Std/Rev): 14900 / 16300
- Weight Full (Std/Rev): 22800 / 24200
Dual CD-27"(Multi-Drum RC)
- Cutting Width: 156
- Overall Width: 180
- Drum Diameter: 48
- Blade Size: 3/4x6
- Number Of Blades: 20
- Weight Empty (Std/Rev): 14870 / 16270
- Weight Full (Std/Rev): 22770 / 24170
Triple C-37"(Multi-Drum RC)
- Cutting Width: 228
- Overall Width: 252
- Drum Diameter: 48
- Blade Size: 3/4x6
- Number Of Blades: 30
- Weight Empty (Std/Rev): 16300 / 24000
- Weight Full (Std/Rev): 33750 / 35850
Tendum C-28"(Multi-Drum RC)
- Cutting Width: 96
- Overall Width: 120
- Drum Diameter: 60
- Blade Size: 1x10
- Number Of Blades: 26
- Weight Empty (Std/Rev): 20600 / 22600
- Weight Full (Std/Rev): 37890 / 39890
Dual CD-28"(Multi-Drum RC)
- Cutting Width: 180
- Overall Width: 204
- Drum Diameter: 60
- Blade Size: 1x10
- Number Of Blades: 24
- Weight Empty (Std/Rev): 20545 / 22565
- Weight Full (Std/Rev): 37845 / 39845
Triple C-38"(Multi-Drum RC)
- Cutting Width: 264
- Overall Width: 288
- Drum Diameter: 60
- Blade Size: 1x10
- Number Of Blades: 36
- Weight Empty (Std/Rev): 29750 / 32750
- Weight Full (Std/Rev): 55685/ 58685
Tendum C-210"(Multi-Drum RC)
- Cutting Width: 120
- Overall Width: 144
- Drum Diameter: 60
- Blade Size: 1x10
- Number Of Blades: 26
- Weight Empty (Std/Rev): 27900 / 30700
- Weight Full (Std/Rev): 54985 / 57785
Double CD-210"(Multi-Drum RC)
- Cutting Width: 228
- Overall Width: 252
- Drum Diameter: 60
- Blade Size: 1x10
- Number Of Blades: 24
- Weight Empty (Std/Rev): 27850 / 30650
- Weight Full (Std/Rev): 54935 / 57735
