Werk-Brau Tree Shear | R-Series TSR8SSL To TSR12-5SSL | Cutting 8 To 12.5" | 10 To 30 GPM | 1.3 To 21 Tons | Skid Steer, Loader & Telehandler

Werk-Brau Tree Shear | R-Series TSR8SSL To TSR12-5SSL | Cutting 8 To 12.5" | 10 To 30 GPM | 1.3 To 21 Tons | Skid Steer, Loader & Telehandler

Regular price $1.00
Regular price Sale price $1.00
Sale Sold out
Machine Compatibility
Customizable
Fast
24/7 Support
  • Pricing Unavailable, Request Quote
  • Cutting Diameter: 8–12.5" for Tree Shearing.
  • Machine Capacity: 1.3–21 Tons Skid Steers.
  • Operating Pressure: 2,900–4,350 PSI Hydraulic.
  • Attachment Weight: 507–1,874 Lbs.
  • For Skid Steers, Telehandlers, Forestry Applications.
View full details

How To Request A Quote

***Online pricing not available, Please request a quote:***

How To Get A Quote:

Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!

Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!

Product Description

Werk-Brau Tree Shear | R-Series TSR8SSL To TSR12-5SSL | Cutting 8 To 12.5" | 10 To 30 GPM | 1.3 To 21 Tons | Skid Steer, Loader & Telehandler

DESCRIPTION

The Werk-Brau R-Series Tree Shear is a high-performance attachment designed for skid steers and telehandlers performing forestry, tree removal, land clearing, vegetation management, and debris-handling applications. Available in TSR8SSL, TSR10SSL, and TSR12-5SSL models, the R-Series provides cutting diameters from 8 to 12.5 inches for different machine and material requirements. Built with durable Hardox® steel, each tree shear combines powerful cutting with gripping, collecting, and material-handling capabilities. The integrated eBoost® hydraulic system is engineered to increase operating speed while maintaining cutting performance and can operate with reduced oil demand. A 360° rotation system provides greater positioning flexibility and control when working around trees and obstacles. With model-specific machine capacities, hydraulic pressure requirements, and optional collector compatibility, the R-Series offers a versatile solution for professional forestry and vegetation-management operations.

Key Features

  • High-Speed Tree Shearing The R-Series is engineered for efficient cutting of trees, branches, heavy vegetation, and woody debris, helping professional operators complete demanding clearing and forestry tasks productively.
  • Three Model Options Choose from TSR8SSL, TSR10SSL, or TSR12-5SSL models with 8-inch, 10-inch, or 12.5-inch cutting capacities to match different skid steer and telehandler applications.
  • 360° Full Rotation Integrated 360° rotation expands working angles and provides greater positioning flexibility when cutting, grasping, and handling trees in confined or demanding work areas.
  • eBoost® Hydraulic Technology The integrated eBoost® system is designed to operate with reduced oil demand while increasing operating speed without sacrificing intended cutting power.
  • Hardox® Steel Construction Built from durable Hardox® steel, the tree shear is designed for demanding professional applications and challenging environmental conditions.
  • Multi-Function Tree Attachment Combines cutting, grasping, collecting, and handling capabilities, allowing operators to perform multiple vegetation-management tasks with one attachment.
  • Skid Steer Compatible Designed specifically for compatible skid steers, with model options supporting different machine capacities and hydraulic requirements.
  • Telehandler Compatible The SSL-series tree shears can also be used with compatible telehandlers, expanding application flexibility across forestry and land-clearing operations.
  • 8–12.5 Inch Cutting Range Multiple cutting capacities provide a choice between compact and higher-capacity configurations for different tree and vegetation requirements.
  • Efficient Hydraulic Performance The eBoost® hydraulic system is designed to help improve operating speed and hydraulic efficiency while maintaining the required cutting performance.
  • Improved Timber Control Faster attachment movements can help operators maintain better control over timber and cut vegetation during cutting and material-handling operations.
  • High-Pressure Hydraulic Design The models are engineered for demanding hydraulic applications, with specified operating-pressure ranges extending up to 4,350 psi.
  • Optional Collector Available An optional collector can be added to compatible R-Series configurations to support more efficient collection and handling of cut vegetation.
  • Flexible Coupling Options The R-Series supports common couplings, with custom coupling configurations available according to the customer's machine type.
  • Professional Forestry Application Suitable for tree services, forestry, logging, land clearing, highway maintenance, landscaping, and vegetation management applications.

Detailed Specifications

Specification TSR8SSL TSR10SSL
Brand Werk-Brau Werk-Brau
Product Series R-Series R-Series
Model TSR8SSL TSR10SSL
Attachment Type Tree Shear Tree Shear
Base Machine Skid Steer / Telehandler Skid Steer / Telehandler
Machine Capacity 1.3–2.5 tons 3–6 tons
Machine Lift Capacity 992 lb 1,984 lb
Attachment Weight 507 lb 694 lb
Cutting Diameter 8 in 10 in
Overall Height 15.7 in 19.2 in
Operating Pressure 2,900–4,350 psi 3,625–4,350 psi
Hydraulic System eBoost® eBoost®
Opening 23.6 in 27.1 in
Buffer Plate Height 12.2 in 15.3 in
Rotation 360° 360°
Construction Material Hardox® steel Hardox® steel
Hydraulic Efficiency Technology eBoost® eBoost®
Optional Collector Available Available
Coupling Common / Custom Common / Custom


Specification TSR12-5SSL
Brand Werk-Brau
Product Series R-Series
Model TSR12-5SSL
Attachment Type Tree Shear
Base Machine Skid Steer / Telehandler
Machine Capacity 6–21 tons
Machine Lift Capacity 2,870 lb
Attachment Weight 1,874 lb
Cutting Diameter 12.5 in
Overall Height 23.6 in
Operating Pressure 3,625–4,350 psi
Hydraulic System eBoost®
Opening 33 in
Buffer Plate Height 19.8 in
Rotation 360°
Construction Material Hardox® steel
Hydraulic Efficiency Technology eBoost®
Optional Collector Available
Coupling Common / Custom
