Abyss® | Lithium Trolling Motor Battery | Model AB-24V50-BT | Group 24 | Voltage 24V 50Ah | Bluetooth BMS | Built-In Heating | IP65 Waterproof
Abyss® | Lithium Trolling Motor Battery | Model AB-24V50-BT | Group 24 | Voltage 24V 50Ah | Bluetooth BMS | Built-In Heating | IP65 Waterproof
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Abyss® | Lithium Trolling Motor Battery | Model AB-24V50-BT | Group 24 | Voltage 24V 50Ah | Bluetooth BMS | Built-In Heating | IP65 Waterproof
DESCRIPTION
Say goodbye to frequent battery recharges and the anxiety of losing power mid-fishing trip. The Abyss® 24V 50Ah Lithium Trolling Motor Battery is engineered to deliver reliable, long-lasting power for your trolling motor helping you focus on what matters most: the perfect catch.
Designed as a superior replacement for two bulky 12V lead-acid or AGM batteries, this compact and lightweight lithium iron phosphate (LiFePO4) battery frees up valuable storage space and reduces your boat’s overall weight. Whether you’re cruising calm waters or battling strong winds, its steady deep-cycle power ensures you have the endurance needed for multi-day fishing adventures.
Equipped with cutting-edge features like Bluetooth® connectivity, this battery puts real-time monitoring of charge levels, temperature, cycle life, and performance right at your fingertips. Plus, its built-in heating system guarantees optimal operation even in freezing conditions, eliminating the need for external heating accessories.
Certified to meet rigorous UL1642, IEC62619, and IEC62133 standards, the Abyss® battery offers marine-grade safety, unmatched durability, and vibration resistance built tough to thrive in harsh marine environments.
Charge it, set it, and go experience peace of mind and powerful, reliable trolling motor performance every time you hit the water.
Key Features
- Compact & Lightweight Design: Replaces two traditional 12V lead-acid batteries, freeing up storage space and reducing boat weight for better fuel efficiency and easier handling.
- Bluetooth® Smart Connectivity: Monitor battery status, including charge, discharge, temperature, and cycle life, in real time through an intuitive mobile app for iOS and Android.
- Built-In Heating System: Advanced internal heating ensures peak battery performance and reliable starts in cold weather no bulky external heating blankets required.
- Long Cycle Life & Durability: Over 3000 deep discharge cycles with stable performance thanks to premium cylindrical cells and a reinforced internal structure that resists vibration and impact.
- Marine-Grade Safety Certifications: Complies with UL1642, IEC62619, and IEC62133 standards and tested for extreme marine conditions including salt spray, shocks, and temperature extremes.
- Enhanced Heat Dissipation & Safety: Secure cell separation improves heat dispersion and prevents short circuits, ensuring safe, efficient operation under heavy loads.
- Deep Cycle Power for Fishing & Marine Applications: Provides steady, reliable energy for trolling motors, fish finders, and onboard electronics during extended trips.
Detailed Specifications
| Parameter | Specification |
|---|---|
| Battery Type | Lithium Iron Phosphate (LiFePO4) |
| Voltage | 24V |
| Capacity | 50Ah |
| Cycle Life | > 3000 cycles (deep discharge) |
| Certifications | UL1642, IEC62619, IEC62133 |
| Weight | Approx. 25 lbs (11.3 kg) |
| Dimensions | 10.5" x 6.5" x 7.0" (267 x 165 x 178 mm) |
| Operating Charge Temp. | 0°C to 55°C (32°F to 131°F) |
| Operating Discharge Temp. | -20°C to 60°C (-4°F to 140°F) |
| Charge Voltage | 28.8 ± 0.4V |
| Max Continuous Discharge | 50A |
| Peak Discharge Current | 300A (300 ms) |
| Terminal Type | M6 |
| Case Material | High-strength ABS plastic |
| IP Rating | IP65 (Water and dust resistant) |
| Connectivity | Bluetooth® Battery Management System (iOS & Android) |
| Built-in Heating | Yes, for cold-weather optimized performance |
