Abyss® | Marine Lithium Battery | Model AB-12V100-DP | 1500 CCA / 100Ah | Group 24 | Dual Purpose Cranking & Deep Cycle | Bluetooth BMS | Built-In Heating | IP65 Waterproof

Abyss® | Marine Lithium Battery | Model AB-12V100-DP | 1500 CCA / 100Ah | Group 24 | Dual Purpose Cranking & Deep Cycle | Bluetooth BMS | Built-In Heating | IP65 Waterproof

$1,099.99
$1,099.99
Sale Sold out
Customizable
Fast
24/7 Support
  • Provides peak CCA of 1500A, perfect for starting large motors, generators, and powering high-load devices.
  • Dual-purpose functionality for cranking and deep-cycle applications, including fish finders, GPS systems, and electric downriggers.
  • Compact Group 24 design, weighing only 25.4 lbs, ideal for trolling boats, RVs, trucks, and automobiles.
  • Built-in heating ensures reliable performance in cold weather.
  • Enhanced durability with a robust internal structure to resist vibration and impact.
View full details

Product Description

Abyss® | Marine Lithium Battery | Model AB-12V100-DP | 1500 CCA / 100Ah | Group 24 | Dual Purpose Cranking & Deep Cycle | Bluetooth BMS | Built-In Heating | IP65 Waterproof



DESCRIPTION

Never cut your day short again due to weak or unreliable battery power. Whether you’re chasing big fish offshore, powering up your RV, or cruising in your watercraft, the Abyss® 12V 100Ah Dual Purpose Lithium Marine Battery is designed to deliver uncompromising performance when it matters most.

Engineered with high-output 1500 CCA for rapid cranking and sustained deep-cycle capabilities, this Group 24 LiFePO4 battery is ideal for starting motors and powering modern marine electronics simultaneously without voltage drop or disruption.

From early mornings in sub-zero temperatures to sun-soaked weekends at the lake, this rugged battery features built-in internal heating, advanced Bluetooth® monitoring, and military-grade cell construction to ensure dependable performance in any environment.

Replace outdated AGM or lead-acid batteries and experience the lighter, smarter, and safer marine battery trusted by professional anglers, boaters, and overland adventurers alike.

Key Features

  • High Starting Power 1500 CCA Peak Cranking Current Starts outboards, generators, and high-load motors with ease, even in cold weather.
  • Dual Purpose for Cranking & Deep Cycle Use Ideal for both engine ignition and continuous power draw perfect for boats, RVs, and trolling motors.
  • Built-in Heating System for Cold Weather Readiness Automatically activates during charging in freezing temps no external heater or gear required.
  • Smart Bluetooth® Battery Monitoring Use the Abyss® App to view voltage, state of charge, temperature, cycles, and more in real-time.
  • Compact Group 24 Case Only 25.4 lbs Easy to install in tight compartments and lighter than comparable lead-acid batteries.
  • Marine-Grade Durability IP65 waterproof, flame-retardant ABS housing, and vibration-resistant internal structure.
  • Advanced Battery Management System (BMS) Protects against overcharge, over-discharge, thermal spikes, and short circuits with automatic fault recovery.
  • Long-Lasting Power & Sustainability Up to 3000 cycles at 100% DOD and 6000 cycles at 80% DOD, with high charge/discharge efficiency.

Detailed Specifications

Category Details
Battery Type Lithium Iron Phosphate (LiFePO₄)
Nominal Voltage 12.8V
Capacity 100Ah
Peak Cranking Current 1500 CCA (800A for 300ms)
Battery Group Size Group 24
Weight 25.4 lbs (11.3 kg)
Physical Dimensions 10.2" x 6.69" x 8.18" (260 x 170 x 208 mm)
Bluetooth Monitoring Yes – iOS & Android compatible
Built-in Heating System Yes – Activates automatically during cold-weather charging
Cycle Life 3000 @ 100% DOD / 6000 @ 80% DOD
Parallel Connection Up to 6 units
Series Connection Up to 4 units
Charge Voltage 14.4 ± 0.2V
Standard Charge Current 24A
Fast Charge Current 60A
Max Alternator Support 150A
Max Continuous Discharge 120A
Discharge Cut-Off Voltage 10V
Operating Temp (Charge) 32°F to 131°F (0°C to 55°C)
Operating Temp (Discharge) -4°F to 140°F (-20°C to 60°C)
Storage Temp Range 23°F to 113°F (-5°C to 45°C)
Water Resistance Rating IP65
Terminal Type M8 x 1.25"
Case Material Flame-retardant ABS plastic
Certifications UL1642, IEC62619, IEC62133, ROHS, UN38.3
Safety Protections Overcharge, over-discharge, short circuit, temp control



Manuals & Documents

ABYSS BATTERY® USER MANUAL

LITHIUM CHARGER USER MANUAL

DC-DC CHARGER USER MANUAL

REEL BATTERY USER MANUAL

BLUETOOTH® APP QUICK GUIDE
