Amped Outdoors Trolling Motor Lithium Battery System (LiFePO4 Batteries in Parallel) | Nominal Voltage 36V | Nominal Capacity 100Ah
Amped Outdoors Trolling Motor Lithium Battery System (LiFePO4 Batteries in Parallel) | Nominal Voltage 36V | Nominal Capacity 100Ah
Regular price
$2,199.98
Regular price
Sale price
$2,199.98
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Amped Outdoors Trolling Motor Lithium Battery System (LiFePO4 Batteries in Parallel) | Nominal Voltage 36V | Nominal Capacity 100Ah
Description
Replace your heavy AGM trolling motor batteries with this two 36v 50Ah LiFePO4 group size 31 Batteries. At only 76.6lbs you are eliminating weight and saving space form your traditional 3 battery systems. Includes Amped Outdoors 36v 10A on board waterproof charger!
Our active heating function will allow your compatible charger to heat the battery when it's below freezing and begin charging once it reaches 32° f. The heated function will continue to heat the battery until it is up to approximately 50° f and then it will accept full charge rate.
Compatible chargers below:
- Amped Outdoors 36V 10A Charger (included)
Key Features
- Weight Reduction: Two 36V 50Ah LiFePO4 batteries weighing only 76.6lbs replace traditional 3 battery systems, saving weight and space.
- Active Heating Function: Heats the battery when below freezing and charges once it reaches 32°F. Heating continues until approximately 50°F before accepting the full charge rate.
- Included Charger: Comes with Amped Outdoors 36V 10A onboard waterproof charger.
- High Usable Capacity: 100Ah nominal capacity, with an actual capacity of 110Ah.
- Durable and Reliable: Marine-grade materials and design ensure performance in tough conditions.
- Short Circuit Protection: 220A short circuit protection for added safety.
- Long Life Cycle: Offers 2000+ life cycles, ensuring long-lasting performance.
- Terminal Type: 8MM bolts for secure connections.
Detailed Specifications
| Specification | Details |
|---|---|
| Nominal Voltage | 36V |
| Nominal Capacity | 100Ah |
| Actual Capacity | 110Ah |
| Discharge Cut-Off | 30V |
| Charge Cut-Off | 43.8V |
| Charge Current | 50A Max |
| Cont. Discharge | 100A |
| Peak Discharge | 160A |
| Charge Temperature | 0℃ – 45℃ |
| Discharge Temperature | -20℃ – 60℃ |
| Short Circuit Protection | 220A |
| Charge Method | CC/CV |
| Life Cycle | 2000+ |
| Terminal Type | 8MM Bolts |
| Warranty | 10 Years |
| Weight | 38.3lbs / 17.37kg (Each Battery) |
| Dimensions | L: 12.9" x W: 6.77" x H: 8.66" (Group size 31 each) |
| Charger Specs | 36V 10A Charger for Amped Outdoors batteries only; for use with single or batteries wired in parallel. Includes quick connect cable for charging purposes only. |
| Charger Dimensions | L: 6.5" x W: 9.64" x H: 3.9" |
