Product Description
Anderson Square Bale Farm Trailer | Model Stack Pro 5400 & 7200 | Maximum Square Bale Capacity 18 & 27 | Horsepower 150-175 HP | For Tractors
DESCRIPTION
The Stackpro series (Stackpro7200 and Stackpro5400) features innovative trailers designed to streamline the collection and stacking of square bales, ensuring maximum efficiency in farm logistics throughout the year. Both models are built to withstand extreme conditions and handle diverse bale types and sizes. While sharing the same durable, high-performance features, the two models differ primarily in size and bale carrying capacity.
These trailers deliver high-speed operation with smooth transitions for effortless transport and stacking. By saving time, labor, and investment costs, they are invaluable tools for farmers and contractors aiming to maximize productivity.
Key Features
- Adjustable heavy-duty self-loading clamp – Capable of handling bales up to 2400 lbs (1100 kg) while preventing damage to twine.
- Durable build – Ensures rapid bale pickup and secure handling.
- Universal tractor compatibility – Versatile for any farm setup.
- Automated touchscreen controls – Simplifies operation for ease of use right from the start.
- Tracking system – Monitors the number of bales per client, ideal for custom operators.
- Electronic weighing system – Measures bales with ±2.5% accuracy and displays the total load.
- Data export – Bale data is easily exported to Excel using a USB key.
- Self-diagnostic touchscreen – Assists in troubleshooting and system monitoring.
- Rearview camera – Enhances movement during transportation and unloading.
- Rugged frame and steel bed – Suitable for wet and dry bales.
- Tandem axle – Ensures stability and optimal performance.
- Rear clamps – Support the load when stacking or retrieving bales.
- Maintenance-free design – Features lubrication-free pivot systems.
- High flotation tires – Reduce soil compaction and provide smooth field operation.
- Hydraulic unloading and stacking system – Ensures seamless functionality.
- Closed hydraulic circuit – Prevents contamination, enhancing durability.
- Variable displacement pump – Operates via PTO at 1000 RPM for consistent performance.
Detailed Specifications
| Feature/Specification | Stackpro7200 | Stackpro5400 |
|---|---|---|
| Bale Type | Square bales (Baleage/Dry Hay/Straw) | Square bales (Baleage/Dry Hay/Straw) |
| Maximum Square Bale Capacity | 27 (3 ft x 3 ft x 8 ft) / 12 (4 ft x 4 ft x 8 ft) | 18 (3 ft x 3 ft x 8 ft) / 8 (4 ft x 4 ft x 8 ft) |
| Round Bale Compatibility | Not supported | Not supported |
| Loading Arm Design | Hydraulic clamp | Hydraulic clamp |
| Loading Arm Lifting Capacity | 2400 lbs (1089 kg) | 2400 lbs (1089 kg) |
| Able to Load a Second Row of Bales | Platform | Platform |
| Tractor Power (HP) | 175 HP | 150 HP |
| Tractor Hydraulic Flow | 2800 psi (190 bar) | 2800 psi (190 bar) |
| Controls | Touchscreen automation | Touchscreen automation |
| Electronic Weighing System | Included with ±2.5% accuracy margin | Included with ±2.5% accuracy margin |
| Data Export | Via USB to Excel | Via USB to Excel |
| Camera System | Standard rear-view camera | Standard rear-view camera |
| Tires | 560-45-R22.5 | 560-45-R22.5 |
| Tandem Axle | Standard (Optional with brakes) | Standard (Optional with brakes) |
| Self-Steering Axle with Brakes | Optional | Optional |
| Safety Chain | Standard | Standard |
| Hydraulic System | Closed hydraulic circuit, no contamination | Closed hydraulic circuit, no contamination |
| PTO Speed/PTO Shaft | 1000 RPM / 1 3/4-Z20 | 1000 RPM / 1 3/4-Z20 |
| Dimensions (L x W x H) | 39 ft x 8 ft 4 in x 12 ft 8 in (11.91 m x 2.55 m x 3.86 m) | 35 ft 7 in x 8 ft 4 in x 12 ft 8 in (10.85 m x 2.55 m x 3.86 m) |
| Bed Height (E) | 6 ft (1.83 m) | 6 ft 1 in (1.85 m) |
| Overall Weight | 25,022 lbs (11,350 kg) | 22,400 lbs (10,160 kg) |
| Empty Weight on Tow Bar | 2782 lbs (1261 kg) | 3650 lbs (1655 kg) |
| Total Weight Including Load | 42,000 lbs (19,000 kg) | 42,000 lbs (19,000 kg) |
