Anzu Robotics Raptor RC Pro: Control Module | 5.5" Display With 10-Point Multi-Touch | For Anzu Raptor & Anzu Raptor T
Anzu Robotics Raptor RC Pro: Control Module | 5.5" Display With 10-Point Multi-Touch | For Anzu Raptor & Anzu Raptor T
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Anzu Robotics Raptor RC Pro: Control Module | 5.5" Display With 10-Point Multi-Touch | For Anzu Raptor & Anzu Raptor T
DESCRIPTION
Pilot your drone with the Anzu Robotics Raptor RC Pro Control Module and enjoy an all-in-one solution that offers customization and expandability to suit your flying style. With the RC Pro, you can leave your phone in your pocket, as it sports a built-in 5.5" 1080p 10-point touchscreen made to work perfectly with the Raptor drone. The display is optimized for outdoor viewing, and an Outdoor mode can be engaged to automatically adjust itself for use in conditions up to and including direct sunlight.
As you receive the live stream from the drone, you can use the Mini HDMI connection to output the footage to an optional monitor, allowing the rest of your crew to follow along. Additional functionality includes a 2.4/5.8 GHz dual-band Wi-Fi 6 (802.11ax) network connection with 2 x 2 MIMO for accessing the internet with the built-in browser.
Key Features
- 5.5" Display with 10-Point Multi-Touch: Offers a 1920 x 1080 resolution and optimized outdoor viewing with an adjustable Outdoor mode.
- Dual-Band Wi-Fi 6: Supports 802.11ax with 2 x 2 MIMO for fast, reliable internet access.
- Bluetooth 5.1 Support: Ensures seamless connectivity with various devices.
- Mini-HDMI Output: Allows for live streaming to an optional monitor for crew viewing.
- Internal Storage: 32GB of internal storage, expandable up to 512GB via microSD slot.
- Built-in Speaker: Enhances user experience with audio output.
- Battery Life: Up to three hours of battery life for extended use.
- Customizable Buttons: Four customizable buttons to tailor the controller to your specific needs.
- Global Positioning Systems: Integrated support for Galileo, GLONASS, and GPS for precise location tracking.
- Compatibility: Designed for Anzu Robotics Raptor and Raptor T drones, and supports other models with customization.
Detailed Specifications
| Specification | Details |
|---|---|
| Compatibility | Anzu Robotics Raptor |
| USB I/O | 1 x USB-C Female Input |
| Video I/O | 1 x Mini-HDMI Output |
| Wireless | Wi-Fi 6 (802.11ax) / Bluetooth 5.1 |
| Mobile App Compatible | Yes: Android & iOS |
| Global Positioning | Galileo, GLONASS, GPS |
| Power Source | Battery (Included) |
| DC Input Power | 15 VDC |
| Power Consumption | 12 W |
| Color | Black |
| Dimensions (Antennas Folded/Controllers Not Mounted) | 7.2 x 5.4 x 1.9" / 18.3 x 13.7 x 4.8 cm |
| Dimensions (Antennas Unfolded/Controllers Mounted) | 8 x 7.2 x 2.4" / 20.3 x 18.3 x 6 cm |
| Weight | 24 oz / 680 g |
| Display | 5.5" Display with 10-Point Multi-Touch |
| Resolution | 1920 x 1080 |
| Battery Life | Up to three hours |
| Storage | 32GB internal, expandable up to 512GB via microSD slot |
| Additional Features | Outdoor Mode, Built-in Speaker, 4 Customizable Buttons |
