Arrowhead | Rockdrill’s Hydraulic Hammers | Models R75 & R90 | Max Energy 121–123 dB | Machine Size 6.5–13 Tons | For Backhoes

Product Description

Arrowhead | Rockdrill’s Hydraulic Hammers | Models R75 & R90 | Max Energy 121–123 dB | Machine Size 6.5–13 Tons | For Backhoes

DESCRIPTION

Designed for heavy-duty excavation, demolition, and construction, the R75 & R90 hydraulic breakers deliver superior impact energy with optimized performance. These models are built to withstand rigorous conditions while ensuring maximum efficiency and durability, making them the perfect choice for excavators and heavy equipment ranging from 6.5 to 13 tonnes.

Key Features

• High Impact Energy: Ensures powerful breakthrough force for demanding applications.
• Optimized Flow Rate: Operates at 70–100 lpm (R75) and 90–120 lpm (R90), allowing precise hydraulic control.
• Adjustable Operating Pressure: R75 operates at 120 bar, while R90 functions at 130 bar, ensuring efficient power delivery.
• Variable Blow Rate: R75 offers 650–1400 blows per minute, while R90 delivers 600–1200 blows per minute, optimizing performance for different materials.
• Noise Control: R75 rated at 121 dB and R90 at 123 dB, ensuring controlled sound emissions in job sites.
• Broad Equipment Compatibility: Works with excavators and heavy machines from 6.5 to 13 tonnes, offering flexibility across various industries.
• Reliable Construction: Engineered for durability, low maintenance, and long-lasting performance under extreme conditions.

Detailed Specifications
