Product Description
Auger Torque | Earth Drill | Model 26000-60 | Auger Diameter 60 Inches | Unit Diameter 16 Inches | Unit Height 56 Inches | Machine Size 20 To 45 Ton | For Excavators
DESCRIPTION
Unleash industrial-strength performance with the Auger Torque Earth Drill 26000-60, purpose-built for excavators from 20 to 45 tons. This heavy-duty hydraulic earth drill delivers outstanding torque and unmatched reliability, making it the perfect tool for demanding drilling tasks in construction, utility work, agriculture, and mining.
Engineered with a robust 6K hydraulic motor and a 4.33-inch square output shaft, the 26000-60 thrives under pressure. Whether you’re installing deep foundation piles, boring large-diameter holes, or setting utility poles, this drill provides the strength, safety, and efficiency professionals count on.
Its precision-built epicyclic planetary gearbox multiplies torque while minimizing stress on internal components. Safety is enhanced by the non-dislodgement shaft design unique to Auger Torque which guarantees the shaft cannot detach during operation. Forged hood ears and oversized output shaft bearings further increase durability in extreme conditions.
Compatible with PA augers up to 60" diameter, and optional extensions for deeper drilling, the 26000-60 is a go-to solution for versatile, heavy-duty applications.
Key Features
- Torque Range: 15,126 To 26,051 ft-lb for demanding drilling tasks.
- Hydraulic Flow: 21 To 59 GPM for optimal performance.
- Excavator Compatibility: 20 To 45 Ton machines.
- Auger Diameter: 12" To 60" for versatile hole sizes.
- Drilling Depth: Up to 35 ft depending on ground conditions.
- Non-Dislodgement Shaft: Prevents shaft separation for enhanced safety.
- Planetary Gearbox: Amplifies torque with high mechanical efficiency.
- Forged Hood Ears: Reinforced for high-strain applications.
- Heavy-Duty Steel Construction: Built to withstand rugged job sites.
- Output Shaft: 3.94" square (adaptors available).
- Hitch Options: Single Pin, Double Pin, Cradle.
- Optional 2-Way Valve: Converts single-acting hammer circuits to 2-way flow.
- Warranty: Backed by Auger Torque’s industry-leading coverage.
- Applications: Foundation piles, mast installations, screw piles, rail work, deep hole boring, well drilling.
Detailed Specifications
General Specifications
| Parameter | Specification |
|---|---|
| Model | 26000-60 |
| Carrier Weight | 20–45 Ton (44,093–99,208 lb) |
| Torque Range | 15,442–24,708 ft-lb (20,937–33,500 Nm) |
| Oil Pressure | 2,175–3,480 psi (150–240 bar) |
| Oil Flow | 26–59 gpm (100–225 lpm) |
| Speed Range | 11–26 rpm |
| Unit Height | 56 in (1,411 mm) |
| Unit Diameter | 16 in (406 mm) |
| Unit Weight | 974 lb (442 kg) |
| Output Shaft Size | 4.33" Square (Adaptors available) |
| Color | AT Black |
| Construction | Steel Stillage |
| Region | USA |
| Hoses & QRCs | Not Included |
| Hitch Options | Single Pin, Double Pin, Cradle |
Drilling Performance
| Attribute | Specification |
|---|---|
| Auger Series | PA Series |
| Compatible Auger Diameter | 12–60 in (300–1500 mm) |
| Drilling Depth* | 19–35 ft (5.7–10.5 m) |
| Hub Options | 4.33" (std), 3.94", 5.125" square |
| Available Lengths | 7 ft. 6 in. and 11 ft. (Fully Flighted) |
