The 2024 BARKO 595MH EPIC is an advanced and powerful knuckle boom designed for efficient scrap handling. With a robust 175 HP Cummins engine, this versatile machine is available in self-propelled, truck, or trailer mount options. Built for maximum productivity, the 595MH EPIC features excellent handling and operational ease, making it an ideal choice for industrial scrap material handling.
| Specification | Details |
|---|---|
| Year | 2024 |
| Manufacturer | BARKO |
| Hours | 0 |
| Model | 595MH EPIC |
| Serial Number | 12459500000 |
| Condition | New |
| Power Unit | Details |
|---|---|
| Engine | Cummins QSB6.7 6-cylinder US EPA Tier 4 Final (EU Stage IV) |
| Rated HP | 173 hp (129 kW) at 2200 rpm |
| Peak HP | 183 hp (136 kW) at 2000 rpm |
| Peak Torque | 620 ft-lb (841 N-m) at 1500 rpm |
| Cooling Package | Side-by-side charge air cooler, radiator, oil cooler; swing-out AC condenser |
| Fan | Engine driven, fixed-pitch |
| Air Cleaner | 2-Stage |
| Fuel Filtration | Primary and secondary with water separator |
| Fuel Capacity | 120 gal (454 L) |
| DEF Capacity | 10 gal (37.8 L) |
| Throttle | Electronic; economy mode, auto-idle |
| Hydraulic System | Details |
|---|---|
| Main Pump | (1) Axial piston, load sensing |
| Swing Pump | (1) Axial piston, variable displacement hydrostatic (With Delimber and Bar Slasher hydraulic package only) |
| Reservoir | 56 gal (212 L) |
| Filtration | (1) In-tank main return, (1) spin-on drain |
| Fill Pump | Hand operated pump with included hose (electric version optional) |
| Control Valve | Sectional; pilot or electrically operated load sensing |
| Collector | 4-Port rotary manifold (6-port with Circle Slasher package) |
| Cylinder, Main Boom | (1) 7.0” (17.8 cm) bore x 4.0” (10.2 cm) rod |
| Cylinder, Stick Boom | (1) 7.0” (17.8 cm) bore x 4.0” (10.2 cm) rod |
| Cylinder, Stabilizer | (4) 7.0" (17.8 cm) bore x 4.0" (10.2 cm) rod |
| Boom Max Reach | Details |
|---|---|
| Standard Boom | 32’ (9.75 m) straight boom (33,000 lbs with std. cw. (less attachments/options) |
| Lift Capacity at 15' | 26,319 lbs (11938 kg) at 15’ (4.57 m) |
| Lift Capacity at 25' | 15,872 lbs (7199 kg) at 25’ (7.62 m) |
| Lift Capacity at Full Reach | 8,962 lbs (4065 kg) at full reach |
| Optional Boom | 36’ (10.97 m) straight boom (34,200 lbs with std. cw. (less attachments/options) |
| Lift Capacity at 15' | 25,922 lbs (11758 kg) at 15’ (4.57 m) |
| Lift Capacity at 25' | 15,188 lbs (6889 kg) at 25’ (7.62 m) |
| Lift Capacity at Full Reach | 6,955 lbs (3155 kg) at full reach |
| Live Heel Boom | 32’ (9.75 m) live heel boom (34,500 lbs with std. cw. (less attachments/options) |
| Lift Capacity at 15' | 22,763 lbs (10325 kg) at 15’ (4.57 m) |
| Lift Capacity at 25' | 15,140 lbs (6867 kg) at 25’ (7.62 m) |
| Lift Capacity at Full Reach | 6,878 lbs (3119 kg) at full reach |
| Live Heel Boom | 36’ (10.97 m) live heel boom (35,700 lbs with std. cw. (less attachments/options) |
| Lift Capacity at 15' | 24,776 lbs (11238 kg) at 15’ (4.57 m) |
| Lift Capacity at 25' | 14,393 lbs (6528 kg) at 25’ (7.62 m) |
| Lift Capacity at Full Reach | 5,815 lbs (2637 kg) at full reach |
| Dimension | Details |
|---|---|
| Maximum Reach | 32' & 36’ options (live heel boom & straight boom) |
| Tail Swing Radius | 8’10” (2.9 m) with standard counterweight 9’ 3” (2.8 m) with optional counterweight |
| Transport Width | 8' 6" (2.59 m) |
| Transport Height | 13' 6" (4.11 m) (mounted on 40” high frame) |
| Transport Height with Cab Tilted | 13' 4" (4.06 m) (mounted on 40” high frame) |
| Stabilizer Length | 14’ 1” (4.29 m) |
| Stabilizer Width at Ground Level | 18' 6” (5.64 m) |
| Stabilizer Pad Size | 23.6” x 21.2” (50 cm x 54 cm) |
| Stabilizer Ground Penetration | 13” (33 cm) |
| Trailer Frame Height | 40” (101 cm) |
| Max Trailer Frame Width | 36” (91 cm) |
| Max Trailer Frame Beam Height | 16” (41 cm) |
| Counterweight | 3000 lb (1363 kg) standard, 7000 lb (3175 kg) optional |
