Product Description
Baumalight Tree Shear | Model IXV512, IXV508 & IXV715 | Limb Size 8", 12" & 15" | Machine Size 3 To 26 Tons | For Excavators
DESCRIPTION
Unlock unmatched precision and power in your forestry and land-clearing projects with the Baumalight IXV Series Vertical Incisor Tree Shear the ultimate excavator attachment for professional operators and contractors. Designed specifically for excavators ranging from 3 to 26 tons, this robust series (models IXV508, IXV512, IXV715) offers superior vertical limb shearing capabilities, effortlessly handling branches and limbs from 8 to 15 inches in diameter.
Whether you're managing forestry, clearing right-of-ways, or performing selective cutting, the Baumalight IXV Series delivers consistent, clean cuts that improve safety and productivity on the job site. Crafted from abrasion-resistant AR400 steel, these tree shears provide durable, long-lasting performance even in the toughest conditions.
The vertical cutting orientation of the IXV models allows for efficient handling of hanging limbs and precise maneuvering of fallen branches. Each unit comes with mounts and pins for secure attachment to your excavator, offering easy installation and operation. Although hydraulic hoses are not included, this allows you to customize the hydraulic setup to perfectly match your excavator’s specifications.
From heavy-duty forestry work to infrastructure maintenance, the Baumalight IXV Series Vertical Incisor Tree Shear is your trusted partner for efficiency, strength, and unmatched cutting power.
Key Features
- Heavy-Duty Vertical Limb Cutting Shear large hanging limbs and branches cleanly for effective forestry and land clearing.
- Versatile Excavator Compatibility Designed for excavators weighing 6,000 to 52,000 lbs (3 to 26 tons), fitting a wide range of machine sizes.
- Variable Limb Cutting Sizes Choose from 8", 12", or 15" limb capacity depending on your project needs.
- High-Strength AR400 Steel Construction Ensures abrasion resistance and durability for long-lasting heavy-duty use.
- Bucket-Linkage Activation (IXV715 Model) Maximizes cutting force by utilizing the excavator’s bucket cylinder and linkages without extra hydraulics.
- Greased Pivot Pins Low-maintenance design that reduces downtime and extends attachment life.
- Mount and Pins Included Secure and quick installation with compatible mounts tailored for your excavator.
- Custom Hydraulic Hose Setup Hydraulic hoses not included to allow tailored hydraulic configurations.
- Improved Worksite Productivity Efficiently cuts and moves limbs to keep your job moving swiftly.
- Selective Cutting Capability Ideal for precision forestry applications and sensitive land management.
- Heavy-Duty Stiff Brace (IXV715) Enhanced structural support for heavy-duty, high-stress operations.
- Compact & Strong Design Vertical incisor blade orientation offers precise cuts with minimal effort.
- Safe Handling of Hanging Limbs Designed to shear large hanging limbs, improving safety and control.
- Adaptable for Various Excavators Covers a wide hydraulic flow range from 5 to 100 GPM.
- Built for Demanding Conditions Rugged construction withstands tough forestry and land-clearing environments.
Detailed Specifications
| Specification | IXV508 | IXV512 | IXV715 |
|---|---|---|---|
| Model Number | IXV508 | IXV512 | IXV715 |
| Excavator Weight Range | 6,000 – 20,000 lbs (3 – 10 tons) | 16,000 – 40,000 lbs (8 – 20 tons) | 30,000 – 52,000 lbs (15 – 26 tons) |
| Limb Cutting Capacity | 8 inches | 12 inches | 15 inches |
| Cutting Orientation | Vertical | Vertical | Vertical |
| Hydraulic Flow Range | 5 – 40 GPM | 15 – 60 GPM | 20 – 100 GPM |
| Hydraulic Pressure Range | 2,500 – 4,500 PSI | 2,500 – 4,500 PSI | Not Specified |
| Activation Type | Hydraulic Cylinder | Hydraulic Cylinder | Bucket-Linkage (uses bucket cylinder & link) |
| Mounting Hardware | Mount & Pins Included | Mount & Pins Included | Mount & Pins Included |
| Hydraulic Hoses Included | No | No | No |
| Blade Material | AR400 High-Strength Steel | AR400 High-Strength Steel | AR400 High-Strength Steel |
| Greased Pivot Points | Yes | Yes | Yes |
| Additional Structural Features | Heavy-Duty Frame | Heavy-Duty Frame | Custom Stiff Brace for extra durability |
| Weight (Approx.) | 600–900 lbs | 800–1,200 lbs | 1,200–1,800 lbs |
| Ideal Applications | Forestry, land clearing, right-of-way maintenance | Forestry, land clearing, right-of-way maintenance | Heavy forestry, commercial land clearing, infrastructure maintenance |
| Compatible Excavator Classes | Compact to mid-size excavators | Mid-size to large excavators | Large excavators |
