Product Description
Bedrock Attachments Hydraulic Breaker Hammer | Model EH313 | Width 23.6" | Machine Size 10-15 Ton | For Excavators
DESCRIPTION
The Bedrock Attachments Hydraulic Breaker Hammer EH313 is engineered for high-impact rock breaking, trench excavation, and demolition applications, ensuring optimal efficiency, durability, and hydraulic performance. Designed to fit CAT, KOMATSU, HITACHI, VOLVO, John Deere, Doosan, and SANY excavators, this hammer is equipped with auto grease functionality, dual chisels, seal kits, a toolbox, hoses, and couplings to support maximum operational efficiency.
Key Features
- High-Performance Hydraulic System: Operates at 150-170 kg/cm² (2130-2414 psi / 147-166 bar) for strong impact delivery.
- Optimized Impact Frequency: 350-700 bpm, ensuring consistent force application for effective rock breaking.
- Superior Impact Energy: 1690-1720J, maximizing excavation efficiency and demolition power.
- Wide Excavator Compatibility: Fits CAT 312-315, KOMATSU PC130-160, HITACHI EX130-160, VOLVO EC140-160, John Deere 130-160, Doosan DX140-160, SANY SY135-155 excavators.
- Precision Hydraulic Flow: 80-110 L/min (21.1-29.1 gal/min) optimizing machine functionality.
- Reinforced Tool Build: Tool diameter 100mm (3.94 in) and hose diameter 19.05mm (3/4 in), ensuring long-term durability.
- Stable Valve System: Inward valve type, guaranteeing consistent pressure regulation.
- Optimized Excavator Carrier Size: Works with 0.4-0.6m³ capacity excavators within the 10-15 ton size range.
- Durable Construction: Body weight: 479 kg, total weight: 1030 kg, ensuring operational longevity.
- Compact & Efficient Design: Width: 23.6 in, Length: 73.6 in, Height: 33.5 in, optimizing transport and installation.
- Comprehensive Accessories: Comes with auto grease system, 2 x chisel, seal kits, toolbox, hoses & couplings.
-
CE Certified: Meets strict European safety standards, ensuring quality and reliability.
Detailed Specifications
| Specification | Details |
|---|---|
| SKU | EH313 |
| Compatible Excavators | CAT 312-315, KOMATSU PC130-160, HITACHI EX130-160, VOLVO EC140-160, John Deere 130-160, Doosan DX140-160, SANY SY135-155 |
| Operating Pressure | 150-170 kg/cm² (2130-2414 psi / 147-166 bar) |
| Hydraulic Flow Range | 80-110 L/min (21.1-29.1 gal/min) |
| Impact Frequency | 350-700 bpm |
| Impact Energy | 1690-1720J |
| Tool Diameter | 100mm (3.94 in) |
| Hose Diameter | 19.05mm (3/4 in) |
| Tool Weight | 57 kg |
| Suitable Carrier | 0.4-0.6m³ |
| Suitable Carrier Size | 10-15 Tons |
| Valve Type | Inward |
| Accumulator | No |
| Body Weight | 479 kg |
| Total Weight | 1030 kg |
| Dimensions | Width: 23.6 in, Length: 73.6 in, Height: 33.5 in |
| Accessories Included | Auto grease, 2 x chisel, seal kits, toolbox, hoses & couplings |
| Certification | CE Marked |
