Bedrock Attachments Hydraulic Breaker Hammer | Model EH330 | Width 34.3-Inch | Machine Size 28-35 Ton | For Excavators
DESCRIPTION
The Bedrock Attachments Hydraulic Breaker Hammer EH330 is engineered for CAT, KOMATSU, HITACHI, VOLVO, John Deere, Doosan, and SANY excavators, delivering exceptional impact energy, optimized hydraulic performance, and superior demolition efficiency. Designed for rock breaking, trench excavation, and large-scale demolition projects, this attachment guarantees maximum durability and operational precision.
Key Features
- Optimized Compatibility: Fits CAT 330-336, KOMATSU PC290-360, HITACHI EX300-350, VOLVO EC300-350, John Deere 300-350, Doosan DX300-350, SANY SY305-365 excavators.
- Powerful Hydraulic Performance: 160-180 kg/cm² (2272-2556 psi / 157-177 bar) for maximum breaking force.
- High-Impact Energy: 6300-6500J, ensuring efficient rock-breaking and demolition.
- Precision Hydraulic Flow: 180-240 L/min (47.6-63.36 gal/min) optimizing power delivery.
- Reliable Impact Frequency: 300-450 bpm, allowing consistent and precise force application.
- Heavy-Duty Tool & Components: Tool diameter 155mm (6.1 in), hose diameter 31.75mm, and tool weight is 190 kg.
- Efficient Valve System: Inward valve type with accumulator, ensuring stable hydraulic pressure and durability.
- Robust Build Quality: Body weight 1313 kg and total weight is 3410 kg, ensuring operational longevity.
- Optimized Excavator Carrier: Works with 1.1-1.4m³ capacity excavators within the 28-35 ton size range.
- Compact Yet Powerful Design: Width 34.3 in, Length 100.4 in and Height is 45.3 in, ensuring efficient transport and installation.
- CE Certified: Meets strict European safety standards, ensuring quality and reliability.
Detailed Specifications
| Specification | Details |
|---|---|
| SKU | EH330 |
| Compatible Excavators | CAT 330-336, KOMATSU PC290-360, HITACHI EX300-350, VOLVO EC300-350, John Deere 300-350, Doosan DX300-350, SANY SY305-365 |
| Operating Pressure | 160-180 kg/cm² (2272-2556 psi / 157-177 bar) |
| Hydraulic Flow Range | 180-240 L/min (47.6-63.36 gal/min) |
| Impact Frequency | 300-450 bpm |
| Impact Energy | 6300-6500J |
| Tool Diameter | 155mm (6.1 in) |
| Hose Diameter | 31.75mm |
| Tool Weight | 190 kg |
| Suitable Carrier | 1.1-1.4m³ |
| Suitable Carrier Size | 28-35 Tons |
| Valve Type | Inward |
| Accumulator | Yes |
| Body Weight | 1313 kg |
| Total Weight | 3410 kg |
| Dimensions | Width: 34.3 in, Length: 100.4 in, Height: 45.3 in |
| Certification | CE Marked |
