Product Description
Bedrock Attachments Long Reach Arm and Boom | Model EL320C-18 | Reach 59' Ft | Machine Size 20-23 Tons | For Excavators CAT 320B/320C
DESCRIPTION
The Bedrock Attachments Long Reach Arm and Boom is designed for CAT 320B and 320C excavators, providing an extended reach of 18 meters for deep excavation, dredging, and material handling. This attachment is engineered with advanced technology and precision manufacturing, ensuring structural integrity, hydraulic efficiency, and long-term durability. The supporting structure simplifies packing and transportation, making logistics more convenient.
Key Features
- Extended Reach: 18m total reach with 9.7m boom and 8.3m stick, enhancing excavation depth.
- High-Efficiency Bucket: 0.6m³ capacity, optimized for material handling and cleanup.
- Precision Engineering: Computerized stress distribution analysis improves durability and design strength.
- Advanced Manufacturing: Large-scale milling equipment enhances welding precision.
- Premium Hydraulic System: Cold-rolled precision steel pipes, finished with phosphoric acid washing, ensuring smooth oil flow and reducing hydraulic circuit contamination.
- Top-Tier Welding: Robotic ultrasonic-tested welding guarantees maximum structural integrity.
- Pin Hole Accuracy: High-quality boring machine maintains parallelism, securing flawless pin alignment.
- Surface Treatment: Fully sandblasted finish, offering a clean and polished appearance.
- Reliable Cylinders: Equipped with CAT 320 cylinder for smooth hydraulic performance.
- Robust Linkage: 312 Linkage system with 2 x 65mm Pins for improved attachment stability.
-
CE Certified: Meets strict European safety standards, ensuring reliability and efficiency.
Detailed Specifications
| Specification | Details |
|---|---|
| SKU | EL320C-18 |
| Total Reach | 18m (59 ft) |
| Boom Length | 9.7m |
| Stick Length | 8.3m |
| Bucket Capacity | 0.6m³ |
| Pin Count | 6 |
| Pin Size | 2 x 65mm Pins |
| Hydraulic System | Cold-rolled precision steel pipes with phosphoric acid treatment |
| Welding Method | Robotic welding with ultrasonic non-destructive testing |
| Surface Treatment | Sandblasted for smooth finish |
| Transport Support | Supporting structure included for easier packing and shipment |
| Cylinder Type | CAT 320 Cylinder |
| Linkage Type | 312 Linkage |
| Certification | CE Marked |
