Product Description
Bedrock Attachments Long Reach Arm and Boom | Model EL336D-18 | Reach 59' Ft | Machine Size 30-40 Tons | For Excavators CAT 325C-340D2L
DESCRIPTION
The Bedrock Attachments Long Reach Arm and Boom is a highly durable extension designed for CAT 325C, 330C, 330CL, 330D, 330DL, 336, 336GC, 340, 336D, 336DL, 336D2, 336D2L, 340DL, and 340D2L excavators. With an 18-meter total reach, this attachment enhances deep excavation, dredging, and material handling operations, ensuring structural integrity and smooth hydraulic efficiency. Manufactured using advanced engineering and robotic welding, this attachment maximizes durability and performance in demanding job sites. A supporting structure is included, making packing and transportation effortless.
Key Features
- Extended Reach: 18m total reach with 10m boom and 8m stick, improving excavation depth.
- Cleaning Bucket: 1m³ capacity, optimized for dredging and material cleanup.
- Precision Engineering: Computerized stress distribution analysis ensures structural integrity.
- Advanced Manufacturing: Large-scale milling equipment enhances welding precision.
- Premium Hydraulic System: Cold-rolled precision steel pipes, finished with phosphoric acid washing, reducing hydraulic oil flow resistance and contamination.
- Top-Tier Welding: Robotic ultrasonic-tested welding ensures maximum strength.
- Pin Hole Accuracy: High-quality boring machine maintains parallelism, ensuring flawless pin alignment.
- Surface Treatment: Fully sandblasted finish, ensuring a clean and polished look.
- Reliable Cylinders: Equipped with CAT 320 cylinder, guaranteeing superior hydraulic efficiency.
- Robust Linkage: B Linkage system for enhanced attachment stability.
-
CE Certified: Meets strict European safety standards, ensuring reliability and efficiency.
Detailed Specifications
| Specification | Details |
|---|---|
| SKU | EL336D-18 |
| Total Reach | 18m (59 ft) |
| Boom Length | 10m |
| Stick Length | 8m |
| Bucket Capacity | 1m³ (Cleaning Bucket) |
| Pin Count | 6 |
| Pin Size | 2 x 80mm Pins |
| Hydraulic System | Cold-rolled precision steel pipes with phosphoric acid treatment |
| Welding Method | Robotic welding with ultrasonic non-destructive testing |
| Surface Treatment | Sandblasted for smooth finish |
| Transport Support | Supporting structure included for easier packing and shipment |
| Cylinder Type | CAT 320 Cylinder |
| Certification | CE Marked |
