Product Description
Bedrock Attachments Long Reach Arm and Boom | Reach 59' Ft | Machine Size 30-40 Tons | For Excavators CAT 325C-340D2L
DESCRIPTION
The Bedrock Attachments Long Reach Arm and Boom is a highly durable and efficient extension designed for CAT 325C, 330C, 330CL, 330D, 330DL, 336, 336GC, 340, 336D, 336DL, 336D2, 336D2L, 340DL, and 340D2L excavators. With an 18-meter total reach, this attachment significantly enhances deep excavation, dredging, and material handling operations. Built with high-quality materials and advanced engineering, it ensures structural integrity, hydraulic efficiency, and seamless performance in demanding job sites. Featuring a supporting structure for easier packing and transportation, this long-reach boom and arm system is an excellent addition to your fleet.
Key Features
- Extended Reach: 18m total reach with 10m boom and 8m stick, improving excavation depth.
- Cleaning Bucket: 0.8m³ capacity, designed for precision in dredging and material cleanup.
- Precision Engineering: Computerized stress distribution analysis optimizes design structure for maximum durability.
- Advanced Manufacturing: Large-scale milling equipment improves welding precision.
- Premium Hydraulic System: Cold-rolled precision steel pipes, finished with phosphoric acid washing, ensuring smooth oil flow and reducing hydraulic circuit contamination.
- Top-Tier Welding: Robotic ultrasonic-tested welding guarantees superior structural integrity.
- Pin Hole Accuracy: High-quality boring machine ensures parallelism, providing flawless pin alignment.
- Surface Treatment: Fully sandblasted finish, ensuring a clean and polished appearance.
- Reliable Cylinders: Equipped with CAT 320 cylinder, optimizing hydraulic efficiency.
- Robust Linkage: B Linkage system for improved attachment stability and functionality.
-
CE Certified: Meets strict European safety standards, guaranteeing reliability.
Detailed Specifications
| Specification | Details |
|---|---|
| SKU | EL330C-18 |
| Total Reach | 18m (59 ft) |
| Boom Length | 10m |
| Stick Length | 8m |
| Bucket Capacity | 0.8m³ (Cleaning Bucket) |
| Pin Count | 6 |
| Pin Size | 2 x 80mm Pins |
| Hydraulic System | Cold-rolled precision steel pipes with phosphoric acid treatment |
| Welding Method | Robotic welding with ultrasonic non-destructive testing |
| Surface Treatment | Sandblasted for smooth finish |
| Transport Support | Supporting structure included for easier packing and shipment |
| Cylinder Type | CAT 320 Cylinder |
| Certification | CE Marked |
