Bedrock Attachment

Bedrock Attachments Severe Rock Bucket | Width 42-Inch | Capacity 1.00 CU M | Machine Size 18-24 Tons | For Excavators

Bedrock Attachments Severe Rock Bucket | Width 42-Inch | Capacity 1.00 CU M | Machine Size 18-24 Tons | For Excavators

Regular price $6,523.00
Regular price Sale price $6,523.00
Sale Sold out
Customizable
Fast
24/7 Support
  • Working Width 42-Inches & Machine Size 18-24 Tons for Excavators
  • Heavy-Duty Severe Rock Design: Engineered for rock excavation, quarrying, and extreme material transport applications.
  • Optimized Capacity: 1.00 CU M (1.56 CU YD), allowing efficient excavation and material movement.
  • Reinforced Teeth: 5 toughened teeth, providing superior wear resistance and durability.
View full details

Product Description

Bedrock Attachments Severe Rock Bucket | Width 42-Inch | Capacity 1.00 CU M | Machine Size 18-24 Tons | For Excavators

DESCRIPTION

The Bedrock Attachments Severe Rock Bucket is specifically designed for CAT 320D/E, 322B/C, 323F, 324D, and 325F excavators, offering reinforced durability, enhanced rock excavation capability, and superior digging precision. Engineered with high-strength steel and optimized wear resistance, this bucket ensures exceptional reliability, structural integrity, and maximum efficiency for tough excavation environments. Featuring a 42-inch bucket width, 5 hardened teeth, and a B Linkage system, this attachment is built for heavy-duty rock handling and demanding digging tasks.

Key Features

  • Heavy-Duty Severe Rock Design: Engineered for rock excavation, quarrying, and extreme material transport applications.
  • Optimized Capacity: 1.00 CU M (1.56 CU YD), allowing efficient excavation and material movement.
  • Reinforced Teeth: 5 toughened teeth, providing superior wear resistance and durability.
  • Precision Pin System: Includes 2 x 80mm Pins, ensuring secure attachment and operational stability.
  • Reliable B Linkage: Enhances bucket strength and excavation efficiency.
  • Compact Excavation Reach: 42-inch (1050mm) bucket width, improving precision.
  • Machine Compatibility: Fits CAT 320D/E, 322B/C, 323F, 324D, 325F excavators within the 18-24 ton size range.
  • CE Certified: Meets strict European safety standards, ensuring quality and reliability.

Detailed Specifications

Specification Details
SKU EB320BSD-42-1
Bucket Width 1050mm (42 in)
Bucket Capacity 1.00 CU M (1.56 CU YD)
Pin Type 2 x 80mm Pins
Teeth Count 5
Ear-to-Ear Width 383 mm (15.07 in)
Center-to-Center Width 445.2 mm (17.53 in)
Total Weight 1070 kg (2354 lbs)
Linkage Type B Linkage
Machine Size 18-24 Tons
Certification CE Marked
