Bedrock Attachment

Bedrock Attachments Severe Rock Bucket | Width 48-Inch | Capacity 1.19 CU M | Machine Size 18-24 Tons | For Excavators CAT 320E, 323F, 325F

Bedrock Attachments Severe Rock Bucket | Width 48-Inch | Capacity 1.19 CU M | Machine Size 18-24 Tons | For Excavators CAT 320E, 323F, 325F

Regular price $7,069.00
Regular price Sale price $7,069.00
Sale Sold out
Customizable
Fast
24/7 Support
  • Working Width 48-Inches & Machine Size 18-24 Tons for Excavators CAT 320E, 323F, 325F
  • Heavy-Duty Severe Rock Design: Optimized for rock excavation, material transport, and rugged worksite applications.
  • Optimized Capacity: 1.19 CU M (1.56 CU YD) ensures efficient material handling.
  • Reinforced Teeth: 6 hardened teeth, providing superior durability and wear resistance.
View full details

Product Description

Bedrock Attachments Severe Rock Bucket | Width 48-Inch | Capacity 1.19 CU M | Machine Size 18-24 Tons | For Excavators CAT 320E, 323F, 325F

DESCRIPTION

The Bedrock Attachments Severe Rock Bucket is engineered for CAT 320E, 323F, and 325F excavators, offering maximum durability, reinforced strength, and optimized digging precision for rock excavation and heavy-duty material handling. Built using high-strength steel and advanced engineering, this bucket ensures exceptional wear resistance, structural reliability, and enhanced digging power in extreme excavation conditions. Featuring a 48-inch bucket width, 6 toughened teeth, and a B Linkage system, this attachment delivers superior excavation efficiency for demanding projects.

Key Features

  • Heavy-Duty Severe Rock Design: Optimized for rock excavation, material transport, and rugged worksite applications.
  • Optimized Capacity: 1.19 CU M (1.56 CU YD) ensures efficient material handling.
  • Reinforced Teeth: 6 hardened teeth, providing superior durability and wear resistance.
  • Precision Pin System: Includes 2 x 80mm Pins, ensuring secure attachment and stability.
  • Reliable B Linkage: Enhances bucket strength and operational efficiency.
  • Compact Excavation Reach: 48-inch (1200mm) bucket width, improving digging accuracy.
  • Machine Compatibility: Fits CAT 320E, 323F, 325F excavators within the 18-24 ton size range.
  • CE Certified: Meets strict European safety standards, ensuring quality and reliability.

Detailed Specifications

Specification Details
SKU EB320BSD-48-1.19
Bucket Width 1200mm (48 in)
Bucket Capacity 1.19 CU M (1.56 CU YD)
Pin Type 2 x 80mm Pins
Teeth Count 6
Ear-to-Ear Width 383 mm (15.07 in)
Center-to-Center Width 445.2 mm (17.53 in)
Total Weight 1170 kg (2574 lbs)
Linkage Type B Linkage
Machine Size 18-24 Tons
Certification CE Marked
