Bedrock Attachments Severe Service Rock Bucket | Width 24" | Capacity 0.46 CU M | Machine Size 18-24 Tons | For Excavators CAT 320
Bedrock Attachments Severe Service Rock Bucket | Width 24" | Capacity 0.46 CU M | Machine Size 18-24 Tons | For Excavators CAT 320
Regular price
$5,086.00
Regular price
Sale price
$5,086.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Bedrock Attachments Severe Service Rock Bucket | Width 24" | Capacity 0.46 CU M | Machine Size 18-24 Tons | For Excavators CAT 320
DESCRIPTION
The Bedrock Attachments Severe Service Rock Bucket is specifically engineered for CAT 320 excavators, providing reinforced durability, optimized digging power, and superior wear resistance for extreme excavation conditions. Manufactured using high-strength steel and precision reinforcement, this bucket ensures long-term reliability, efficient material transport, and structural integrity. Featuring a compact 24-inch width, 3 hardened teeth, and a B Linkage system, this attachment is built for rock excavation, trenching, and aggressive digging tasks.
Key Features
- Severe Service Rock Build: Optimized for rock excavation, quarrying, and rugged job site operations.
- Optimized Capacity: 0.46 CU M (0.61 CU YD), ensuring efficient digging and material movement.
- Reinforced Teeth: 3 toughened teeth, providing maximum durability and wear resistance.
- Precision Pin System: Includes 2 x 80mm Pins, securing the attachment firmly.
- Reliable B Linkage: Strengthens bucket stability and excavation control.
- Compact Excavation Reach: 24-inch (600mm) bucket width, improving digging precision.
- Machine Compatibility: Fits CAT 320 excavators within the 18-24 ton size range.
-
CE Certified: Meets strict European safety standards, ensuring quality and reliability.
Detailed Specifications
| Specification | Details |
|---|---|
| SKU | EB320BSD-24-0.46 |
| Bucket Width | 600mm (24 in) |
| Bucket Capacity | 0.46 CU M (0.61 CU YD) |
| Pin Type | 2 x 80mm Pins |
| Teeth Count | 3 |
| Ear-to-Ear Width | 383 mm (15.08 in) |
| Center-to-Center Width | 445.2 mm (17.53 in) |
| Total Weight | 885 kg |
| Linkage Type | B Linkage |
| Machine Size | 18-24 Tons |
| Certification | CE Marked |
