Bedrock Attachment

Bedrock Attachments Skeleton Bucket | Model EB320BS | Width 63-Inch | Capacity 1.32 CU M | Machine Size 18-24 Tons | For Excavators CAT 320

Bedrock Attachments Skeleton Bucket | Model EB320BS | Width 63-Inch | Capacity 1.32 CU M | Machine Size 18-24 Tons | For Excavators CAT 320

Regular price $7,610.00
Regular price Sale price $7,610.00
Sale Sold out
Customizable
Fast
24/7 Support
  • Working Width 63-Inches & Machine Size 18-24 Tons for Excavators CAT 320
  • Optimized Sorting & Sifting: Designed for handling rock, debris, and aggregate materials.
  • Heavy-Duty Build: Manufactured for high-strength applications, ensuring reliability.
  • Efficient Capacity: 1.32 CU M, enabling rapid material separation and transport.
View full details

Product Description

Bedrock Attachments Skeleton Bucket | Model EB320BS | Width 63-Inch | Capacity 1.32 CU M | Machine Size 18-24 Tons | For Excavators CAT 320

DESCRIPTION

The Bedrock Attachments Skeleton Bucket is designed for CAT 320 excavators, providing efficient sorting, sifting, and material separation in quarrying, demolition, and earthmoving applications. Manufactured with reinforced steel and precision engineering, this bucket ensures maximum durability and operational reliability, enhancing productivity on demanding job sites. Featuring a 63-inch width, 6 reinforced teeth, and precise ear-to-ear and center-to-center spacing, this attachment optimizes excavation performance.

Key Features

  • Optimized Sorting & Sifting: Designed for handling rock, debris, and aggregate materials.
  • Heavy-Duty Build: Manufactured for high-strength applications, ensuring reliability.
  • Efficient Capacity: 1.32 CU M, enabling rapid material separation and transport.
  • Reinforced Teeth: 6 toughened teeth, enhancing digging performance.
  • Accurate Fitment: Ear-to-Ear width: 290mm (11.42 in) and Center-to-Center spacing: 407.3mm (16.04 in).
  • Machine Compatibility: Fits CAT 320 excavators within the 18-24 ton size range.
  • CE Certified: Meets strict European safety standards, ensuring operational safety.

Detailed Specifications

Specification Details
SKU EB320BS-63-1.32
Bucket Width 63 in (1600 mm)
Bucket Capacity 1.32 CU M
Teeth Count 6
Ear-to-Ear Width 290 mm (11.42 in)
Center-to-Center Width 407.3 mm (16.04 in)
Total Weight 1020 kg (2249 lbs)
Machine Size 18-24 Tons
Certification CE Marked
