Product Description
Brown Root Grapple (Extreme Duty) | Model BRGXSS Series | Width 66", 73", 78" & 84" | Oil Flow Range 18–30 GPM | For Skid Steer Loaders
DESCRIPTION
The Brown Manufacturing Root Grapple for Skid Steer Loaders (Model BRGXSS Series) is meticulously designed for extreme-duty applications, excelling in demanding tasks such as debris clearing, log handling, and managing heavy materials on challenging job sites. Available in four precision-engineered widths—66", 73", 78", and 84"—this grapple offers versatile options to match various skid steer loader sizes and operational needs. It operates efficiently within an oil flow range of 18 to 30 GPM, providing balanced hydraulic performance that enhances control and responsiveness. Each grapple includes high-quality hoses and couplers, ensuring straightforward installation and seamless integration with standard skid steer hydraulic systems. Constructed from reinforced, heavy-duty steel and components, the BRGXSS Series is built to endure harsh working conditions while maintaining structural integrity and long-term durability. This robust design minimizes downtime and maintenance, supporting sustained productivity. Additionally, the grapple’s design optimizes root and debris handling, improving cycle times and operator efficiency. Backed by a 12-month factory warranty, the Brown Root Grapple guarantees professional-grade reliability and peace of mind for contractors and heavy equipment operators dedicated to maximizing their equipment’s performance on tough projects.
Key Features
- Extreme Duty Design – Built for demanding applications such as debris clearing, log handling, and heavy material management.
- Hydraulic Integration – Includes hoses and couplers for easy connection to skid steer loaders, ensuring seamless operation.
- Wide Working Width Options – Available in 66", 73", 78", and 84" widths, providing efficient coverage and performance for various workloads.
- Durable Construction – Designed to withstand rigorous use in tough environments, ensuring long-term reliability.
- Optimized Oil Flow – Compatible with 18–30 GPM hydraulic flow range, ensuring efficient power transfer.
- Model Series: BRGXSS – Brown Xtreme Duty Root Grapple for skid steers, available in multiple widths to suit different machines and applications.
-
Warranty Coverage – Comes with a 12-month factory warranty under normal usage, guaranteeing dependability.
Detailed Specifications
Model: BRGXSS66
| Specification | Detail |
|---|---|
| Series | BRGXSS – Brown Xtreme Duty Root Grapple (Skid Steer) |
| Width | 66 in (1.68 m) |
| Overall Height | ~34 in (lid closed) |
| Weight | ~820 lbs (372 kg) |
| Tine Thickness | ¾ in (19 mm) |
| Material | Heavy‑gauge steel with reinforced gussets |
| Clamping Force | Up to 6,000 lbs @ 3,000 psi |
| Hydraulics | Self‑contained, fully covered hoses |
| Mounting | Universal skid steer quick‑attach |
| Finish | Powder‑coated, corrosion‑resistant |
| Warranty | 12 months factory warranty |
Model: BRGXSS73
| Specification | Detail |
|---|---|
| Series | BRGXSS – Brown Xtreme Duty Root Grapple (Skid Steer) |
| Width | 73 in (1.85 m) |
| Overall Height | ~34 in (lid closed) |
| Weight | ~860 lbs (390 kg) |
| Tine Thickness | ¾ in (19 mm) |
| Material | Heavy‑gauge steel with reinforced gussets |
| Clamping Force | Up to 6,000 lbs @ 3,000 psi |
| Hydraulics | Self‑contained, fully covered hoses |
| Mounting | Universal skid steer quick‑attach |
| Finish | Powder‑coated, corrosion‑resistant |
| Warranty | 12 months factory warranty |
Model: BRGXSS78
| Specification | Detail |
|---|---|
| Series | BRGXSS – Brown Xtreme Duty Root Grapple (Skid Steer) |
| Width | 78 in (1.98 m) |
| Overall Height | ~34 in (lid closed) |
| Weight | ~900 lbs (408 kg) |
| Tine Thickness | ¾ in (19 mm) |
| Material | Heavy‑gauge steel with reinforced gussets |
| Clamping Force | Up to 6,000 lbs @ 3,000 psi |
| Hydraulics | Self‑contained, fully covered hoses |
| Mounting | Universal skid steer quick‑attach |
| Finish | Powder‑coated, corrosion‑resistant |
| Warranty | 12 months factory warranty |
Model: BRGXSS84
| Specification | Detail |
|---|---|
| Series | BRGXSS – Brown Xtreme Duty Root Grapple (Skid Steer) |
| Width | 84 in (2.13 m) |
| Overall Height | ~34 in (lid closed) |
| Weight | ~940 lbs (426 kg) |
| Tine Thickness | ¾ in (19 mm) |
| Material | Heavy‑gauge steel with reinforced gussets |
| Clamping Force | Up to 6,000 lbs @ 3,000 psi |
| Hydraulics | Self‑contained, fully covered hoses |
| Mounting | Universal skid steer quick‑attach |
| Finish | Powder‑coated, corrosion‑resistant |
| Warranty | 12 months factory warranty |
HOST MACHINES
| TAKEUCHI TL8 HIGH FLOW |  |
| ASV VT70 HIGH FLOW |  |
| CATERPILLER 259 HIGH FLOW |  |
| MUSTANG 2150RT HIGH FLOW |  |
| KUBOTA SVL75 HIGH FLOW |  |
| WACKER NUESON ST28 HIGH FLOW |  |
