Celli Maxi P-Folding Power Harrow | Maxi-P600 Model | 19' 6" Working Width | Horsepower 200 HP | For Tractors

Product Description

Celli Maxi P-Folding Power Harrow | Maxi-P600 Model | 19' 6" Working Width | Horsepower 200 HP | For Tractors

DESCRIPTION

MAXI P Celli folding power harrow is ideal for high power tractors. It cultivates clay-type soil and heavy soil without the risk of flooding. It also works in rocky terrain and deep soil, covers large surfaces quickly, prepares seedbeds, eliminates soil compacting and varies the degree of soil finishing. The MAXI P is Celli flagship folding power harrow, used for tractors with power ranges up to 200.

Key Characteristics

• The typical Celli technical solution using a box frame in thick welded sheet metal was applied to this model: this type of frame ensures maximum rigidity, providing perfect alignment of the transmission parts in all working conditions.
• The central hitch is particularly robust to guarantee its functionality and operator safety over the years.
• Compared to other models already in the catalog, the MAXI P presents numerous innovations and improvements:
• Robust transmission parts (large diameter rotors and cemented gears held in place by strong self-locking rings);
• The lower area was completely redesigned for better wear resistance and better ground flow through the machine (double oil seals + outer labyrinth, external support in thick forged steel);
• Newly conceived bottom stone protector devices (wedges welded on the frame + removable full fairing).

Key Features

• Maximum Horsepower: 350 HP (255 KW)
• PTO: 2-speed gearbox for 1000 rpm
• No. of teeth: 17-22 = 357 rpm; 18-21 = 396 rpm
• Hitch Type: 3rd category 3-point hitch
• Lower Hitches: Swinging lower hitches
• Frame: Welded box frame
• Roller Adjustment: Rollers with adjustment using pins linked to the leveling bar
• Leveling Bar Adjustment: Rear leveling bar adjustable with threaded bar
• Tines: 100x18x320 mm, with a working depth of about 33 cm, low power absorption
• Side Plates: Mobile side plates
• Drive Shafts: Side drive shafts with automatic safety device, central drive shaft
• Lighting: Rear lights for road transport
• Safety: Equipped with safety devices
• Cooling Unit: Cooling unit for side gearboxes with tank
• Side Lifting: Side lifting with double ram

Detailed Specifications

In Package

• Celli MAXI P Folding Power Harrow.
• Side drive shafts with automatic safety devices.
• Central drive shaft.
• Rear leveling rollers with adjustable settings.
• Mobile side plates for soil control.
• Rear lights for safe road transport.
• Cooling unit for side gearboxes.
• User manual for installation and operation guidance.
