CID 72", 84", 96", 108" & 120 MULTI PURPOSE ANGLE BLADE FOR SKID STEER

CID 72", 84", 96", 108" & 120 MULTI PURPOSE ANGLE BLADE FOR SKID STEER

$3,424.00 USD
$3,424.00 USD
Sale Sold out
Shipping calculated at checkout.
Width

CID 72", 84", 96", 108" & 120 MULTI PURPOSE ANGLE BLADE FOR SKID STEER

DESCRIPTION

The CID Skid Steer Multi-Purpose Angle Blades offer impressive versatility for your skid steer. Let’s break down their features:

  • Snow Plow Mode: Remove the center pin to use the blade as a snow plow. When it hits an obstacle, the blade tips to prevent damage. The powerful springs retract the blade into position once the obstacle is cleared.
  • Angle Blade Mode (4-Way): Leave the center pin in place for angle blade functionality. You can move the blade up and down from your skid steer. It also moves side to side from the attachment, allowing you to handle loose gravel or soil effectively.
  • Cutting Edge: 1/2" x 6" Bolt-On
  • Mold Board Thickness: 3/16"
  • Hydraulic Cylinders: 3" bore, 6" stroke

These robust attachments are designed to tackle various tasks, from snow removal to land grading.

What's Included?

  • Skid Steer Multi Purpose Angle Blade
  • Universal Skid Steer Mounting Plate
  • Hydraulic hoses
  • Flat faced couplers
  • Owner's manual

SPECIFICATIONS

  • Operates as a snow plow or angle blade
  • Constructed with ½” thick by 6” wide replaceable AR400 bolt on cutting edges
  • 3” bore 6” stroke cylinders
  • 3/16″ mold board
  • Available Sizes: 72”, 84”, 96”, 108″, 120″
  • Powder coated
  • American made

Model 72"

  • Weight (lbs.): 810
  • Width ("): 72
  • Mold Board Thickness ("): 3.16
  • Bolt on Cut Edge: 1/2" x 6" AR400

Model 84"

  • Weight (lbs.): 855
  • Width ("): 84
  • Mold Board Thickness ("): 3.16
  • Bolt on Cut Edge: 1/2" x 6" AR400

Model 96"

  • Weight (lbs.): 863
  • Width ("): 96
  • Mold Board Thickness ("): 3.16
  • Bolt on Cut Edge: 1/2" x 6" AR400

Model 108"

  • Weight (lbs.): 908
  • Width ("): 108
  • Mold Board Thickness ("): 3.16
  • Bolt on Cut Edge: 1/2" x 6" AR400

Model 120"

  • Weight (lbs.): 953
  • Width ("): 120
  • Mold Board Thickness ("): 3.16
  • Bolt on Cut Edge: 1/2" x 6" AR400
