Product Description
CID Hydraulic Breaker / Hammer | CBR Series | Energy Class 225-1000 ft-lbs | Machine Size 0.8-8.8 Tons | For Excavators
DESCRIPTION
The CBR Series Hydraulic Breakers are engineered for versatility, durability, and high-impact performance across a wide range of carriers. Designed for applications from light construction to heavy demolition, these breakers deliver consistent striking power with optimized operating pressure and oil flow.
Each model—from the compact CBR225 to the powerful CBR1000—is built with precision tooling, reliable relief settings, and efficient blow rates to maximize productivity while protecting the hydraulic system. With tool diameters ranging from 45 mm to 80 mm, the CBR Series offers solutions for carriers from 0.8 tons up to 8.8 tons, ensuring the right fit for every job site.
Key Features
- Energy Class: Ranges from 225–1000 ft‑lbs — defines striking power for different job sizes.
- Operating Weight: 122–510 kg (269–1,124 lbs) — lighter models suit compact carriers, heavier ones for larger excavators.
- Hose Length: 0.5"–0.75" × 90–100" — ensures proper hydraulic connection across models.
- Operating Pressure: 90–170 kg/cm² (1,280–2,418 psi) — higher pressure ratings deliver stronger impact force.
- Tool Diameter: 45–80 mm (1.77–3.14") — larger diameters handle tougher materials.
- Relief Setting Pressure: 175 kg/cm² (≈2,500 psi) — protects the breaker from overload.
- Oil Flow: 15–90 LPM (3.9–23.7 GPM) — ensures proper hydraulic supply for consistent performance.
- Blow Rate: 380–1,490 bpm — faster blow rates improve productivity in lighter applications, slower rates suit heavy-duty breaking.
- Accumulator Gas Pressure: 40–50 kg/cm² (570–710 psi) — stabilizes hydraulic performance in larger models.
- Suitable Carrier: 0.8–8.8 tons — matches breaker size to excavator/loader capacity.
Detailed Specifications
CBR225 Hydraulic Breaker
| Feature | Specification |
|---|---|
| Energy Class | 225 ft‑lbs |
| Operating Weight | 122 kg / 269 lbs |
| Hose Length | 0.5" × 90" |
| Operating Pressure | 90–120 kg/cm² (1,280–1,707 psi) |
| Tool Diameter | 45 mm / 1.77" |
| Relief Setting Pressure | 175 kg/cm² (≈2,500 psi) |
| Oil Flow | 15–30 LPM (3.9–7.9 GPM) |
| Blow Rate | 540–1,000 bpm |
| Accumulator Gas Pressure | – |
| Suitable Carrier | 0.8–2.5 tons |
CBR500 Hydraulic Breaker
| Feature | Specification |
|---|---|
| Energy Class | 500 ft‑lbs |
| Operating Weight | 190 kg / 419 lbs |
| Hose Length | 0.5" × 100" |
| Operating Pressure | 90–120 kg/cm² (1,280–1,707 psi) |
| Tool Diameter | 57 mm / 2.24" |
| Relief Setting Pressure | 175 kg/cm² (≈2,500 psi) |
| Oil Flow | 20–70 LPM (5.2–10.5 GPM) |
| Blow Rate | 600–1,490 bpm |
| Accumulator Gas Pressure | – |
| Suitable Carrier | 1.5–4.0 tons |
CBR650 Hydraulic Breaker
| Feature | Specification |
|---|---|
| Energy Class | 650 ft‑lbs |
| Operating Weight | 280 kg / 618 lbs |
| Hose Length | 0.5" × 100" |
| Operating Pressure | 110–165 kg/cm² (1,565–2,347 psi) |
| Tool Diameter | 70 mm / 2.75" |
| Relief Setting Pressure | 175 kg/cm² (≈2,500 psi) |
| Oil Flow | 30–65 LPM (7.9–17.1 GPM) |
| Blow Rate | 550–1,300 bpm |
| Accumulator Gas Pressure | 40–50 kg/cm² (570–710 psi) |
| Suitable Carrier | 3.0–6.0 tons |
CBR850 Hydraulic Breaker
| Feature | Specification |
|---|---|
| Energy Class | 850 ft‑lbs |
| Operating Weight | 350 kg / 772 lbs |
| Hose Length | 0.75" × 100" |
| Operating Pressure | 120–165 kg/cm² (1,707–2,347 psi) |
| Tool Diameter | 75 mm / 2.95" |
| Relief Setting Pressure | 175 kg/cm² (≈2,500 psi) |
| Oil Flow | 38–80 LPM (10–21.1 GPM) |
| Blow Rate | 380–1,100 bpm (short stroke: 490–1,100 bpm) |
| Accumulator Gas Pressure | 40–50 kg/cm² (570–710 psi) |
| Suitable Carrier | 4.5–8.0 tons |
CBR1000 Hydraulic Breaker
| Feature | Specification |
|---|---|
| Energy Class | 1,000 ft‑lbs |
| Operating Weight | 510 kg / 1,124 lbs |
| Hose Length | 0.75" × 100" |
| Operating Pressure | 140–170 kg/cm² (1,991–2,418 psi) |
| Tool Diameter | 80 mm / 3.14" |
| Relief Setting Pressure | 175 kg/cm² (≈2,500 psi) |
| Oil Flow | 38–90 LPM (10–23.7 GPM) |
| Blow Rate | 380–1,000 bpm (short stroke: 490–1,100 bpm) |
| Accumulator Gas Pressure | 40–50 kg/cm² (570–710 psi) |
| Suitable Carrier | 4.5–8.8 tons |
