Demco | Steel Hopper Bottom Trailers | Length 42' | Overall Width 98" | Horsepower 260+ HP | For Tractors

Demco | Steel Hopper Bottom Trailers | Length 42' | Overall Width 98" | Horsepower 260+ HP | For Tractors

$1.00
$1.00
Sale Sold out
Customizable
Fast
24/7 Support
  • Pricing Unavailable, Request Quote
  • 42′ Length – Maximum Capacity Configuration
  • 22.5K Tandem Axles with Wabco ABS brakes and 10-bolt hub-piloted steel rims
  • High-Capacity Build: 1,324 ft³ volume, approx. 1,060 leveled and 1,135 heaped bushels
  • Recommended Power Unit: >260 HP for optimal hauling and braking performance
  • Heavy-Duty Frame: 3″ × 6″ × ¼″ tubular steel minimizes twisting under full load
View full details

How To Request A Quote

***Online pricing not available, Please request a quote:***

How To Get A Quote:

Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!

Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!

Product Description

Demco | Steel Hopper Bottom Trailers | Length 42' | Overall Width 98" | Horsepower 260+ HP | For Tractors

DESCRIPTION

Hopper bottom trailers, such as this 42' Demco model, are a critical component in agricultural transport across the United States. Built to streamline grain hauling, the Demco Hopper Bottom Trailer combines a durable open-top design with a reliable roll tarp to securely transport grains and similar materials. Unlike standard trailers, hopper bottoms feature two bottom hoppers, each with crank-operated sliding plates for effortless unloading, enabling efficient operations with minimal labor.

Designed to connect seamlessly with harvest equipment, this hopper trailer is an integral part of moving grain from field to storage. The 66" side walls, 3” x 6” tubular steel frame, and 14-gauge hopper and wall skins provide strength, while the 35-degree floor slope facilitates quick discharge. With advanced features like a rubber-mounted LED lighting system, Shur-Co roll tarp, and color-coded brake lines, the Demco Hopper Bottom Trailer is designed to meet the demands of high-volume agricultural logistics.

Key Features

  • Dual Hopper Configuration for split-load flexibility and efficient unloading
  • 22.5K Tandem Axles with Wabco ABS brakes and 10-bolt hub-piloted steel rims
  • High-Capacity Build: 1,324 ft³ volume, approx. 1,060 leveled and 1,135 heaped bushels
  • Recommended Power Unit: >260 HP for optimal hauling and braking performance
  • Heavy-Duty Frame: 3″ × 6″ × ¼″ tubular steel minimizes twisting under full load
  • Wall & Hopper Skins: 14 ga steel with inverted horizontal ribs for reduced rock chipping
  • Structural Reinforcement: 2″ × 2″ wall stabilizers and 3″ × 4″ top rail (11 ga steel)
  • Hopper Design: 30″ × 20″ opening, 25″ clearance, 35° slope for fast, clean discharge
  • Landing Gear: Holland Atlas 55 2-speed gear (standard on 42′ model)
  • Lighting & Wiring: Rubber-mounted LED lights, sealed Truck-Lite™ 7-way system
  • Paint & Protection: Diamond Vogel polyurethane finish + XRC2001 synthetic undercoating
  • Access & Visibility: Aluminum ladders (front & rear), interior rungs, hopper sight windows
  • Standard Tarp System: Shur-Co manual roll tarp with easy-off stops and roll tube deflectors
  • DOT Compliance: Anti-sail mudflaps (Demco logo), conspicuity tape, manifest holder
  • Trailer Graphics: Factory-installed Demco vinyl branding for professional finish

Detailed Specifications

Category Specification
Trailer Length 42′
Number of Hoppers 2
Axles Two 22,500 lb Arvin Meritor axles with Wabco ABS brakes
Suspension 3-leaf heavy duty Hutch 9700 spring suspension (Air-ride optional)
Cubic Capacity 1,324 ft³
Leveled Bushels Approx. 1,060
Heaped Bushels Approx. 1,135
Weight (Spring Ride) 11,200 lbs
Weight (Air-Ride) 11,440 lbs
Horsepower Required Recommended >260 HP
King Pin Clearance 90″
King Pin Setting 24″
Floor Slope 35°
Hopper Slope 35°
Hopper Opening 30″ × 20″
Hopper Clearance 25″
Side Wall Height 66″ (full view from combine cab)
Overall Width 98″
Height to Top Rail 9′6″
Frame Construction 3″ × 6″ × ¼″ heavy wall tubular steel
Wall Skins 14 ga steel
Wall Stabilizers 2″ × 2″ upright stabilizers (11 ga steel)
Top Rail 3″ × 4″ (11 ga steel)
Lighting Rubber-mounted LED with sealed Truck-Lite™ 7-way wiring
Paint & Coating Diamond Vogel polyurethane + XRC2001 synthetic rubber undercoating
