Product Description
Develon | Dozer | Model DD130 XL | Width 10' 2" | Horsepower 146.1 HP | For Heavy Grading, Construction, & Site Development
DESCRIPTION
Engineered for unmatched precision, visibility, and power, the Develon DD130 XL Dozer delivers best-in-class performance and productivity. Designed to elevate job site efficiency, this crawler dozer is built for demanding grading applications and comes standard with a suite of premium features to enhance operator control, comfort, and confidence.
Whether you're cutting, pushing, or finishing, the DD130 XL offers an impressive combination of high torque, intelligent control, and modern convenience. Its standard equipment includes a rearview camera, 8-inch Smart Touch display, blade shake function, and an ECO mode that optimizes fuel efficiency without compromising grading capability. The cab is thoughtfully engineered with all-glass doors, narrow front pillars, and rear-mounted cooling systems to give you exceptional visibility to the blade and jobsite.
With electrohydraulic joystick controls, automatic blade tilt/lift, and an optional 2D blade assist system, this dozer provides powerful performance for expert operators while making grading easier for newcomers. Add in the MY DEVELON telematics system and a standard oscillating track system, and you’ve got a durable and intelligent machine ready for any terrain.
Backed by a best-in-class factory warranty and compatible with key attachments like a parallel ripper, forestry guard, and towing drawbar, the DD130 XL is purpose-built to push productivity and precision to new heights.
Key Features
- Best-in-Class Horsepower: 146.1 hp net power with superior drawbar pull and torque for demanding jobs.
- Premium Features Included: Standard rearview camera, 8" Smart Touch display, Smart Key, ECO mode, and automatic blade control.
- Enhanced Operator Visibility: Rear cooling system, minimized cab pillars, all-glass doors, and LED work lights provide a full, clear view of the blade and jobsite.
- Oscillating Track System: Delivers better ground contact, operator comfort, and machine stability over uneven surfaces.
- Optional 2D Blade Assist System: Increases grading precision and ease of operation no GPS or lasers required.
- Smart Hydraulic System: Electrohydraulic controls and ergonomic joystick reduce fatigue and increase fine control.
- MY DEVELON Telematics: Monitor equipment health, location, and performance remotely with real-time data and insights.
- Durable Hydraulic Cylinders: Built from high-strength steel with shock-absorbing mechanisms for longevity and smooth operation.
- Robust Warranty: Industry-leading 36-month/5,000-hour factory-backed warranty ensures peace of mind and investment protection.
Detailed Specifications
| Category | Specification |
|---|---|
| Engine | Perkins 1204J, 4-cylinder |
| Rated Power (Net) | 146.1 hp (108.9 kW) @ 2200 rpm |
| Rated Power (Gross) | 156.9 hp (117.0 kW) @ 2200 rpm |
| Max Torque (Net) | 523.7 lbf·ft. (710.0 Nm) @ 1400 rpm |
| Displacement | 268.5 in³ (4.4 L) |
| Undercarriage | Oscillating track with 2 upper & 8 lower rollers |
| Travel Speed | 0 – 5.6 mph (0 – 9.0 km/h) |
| Drive System | Hydrostatic |
| Blade Width | 10' 2" (3.1 m) |
| Hydraulic Flow | 34.9 gpm (132.0 L/min.) |
| Hydraulic Pressure | 3843.5 psi (265.0 bar) |
| Max. Traction Force | 49,279.5 lbf. (22,353.0 kgf) |
| Gradeability | 70% (35°) |
| Operating Weight | 30,865 lbs (14,009 kg) |
| Fuel Tank Capacity | 58.6 gal (222.0 L) |
| DEF Tank | 5.0 gal (19.0 L) |
| Cab Sound Level | 76 dB(A) |
| External Sound Level | 106 dB(A) |
| Cooling System | 11.8 gal (44.6 L) |
| Hydraulic Tank | 24.6 gal (93.0 L) |
| Cylinder – Blade Lift | 3.9" x 2.2" x 14.3" (100 x 55 x 362 mm) |
| Cylinder – Blade Angle | 3.5" x 2.0" x 18.2" (90 x 50 x 461 mm) |
| Cylinder – Blade Tilt | 4.3" x 2.6" x 5.5" (110 x 65 x 140 mm) |
| Cylinder – Ripper Lift | 4.9" x 2.8" x 14.3" (125 x 70 x 362 mm) |
| Battery | 2 x 12V, 100 AH |
| Starter | 24 V, 10.5 hp (7.8 kW) |
| Alternator | 24 V, 100 A |
| Air Cleaner | Dual Element |
