Product Description
Develon | Log Loader | Model DX225LL-7 | Reach 35' 5" | Loading Height 29' 3" | 162.8 hp | 34.4 Tons | For Forestry & Logging
DESCRIPTION
The DEVELON DX225LL-7 Log Loader is a purpose-built powerhouse designed to meet the relentless demands of forestry operations. Engineered from the ground up with industry-specific innovations, it combines the legendary strength and efficiency of DEVELON excavators with all-day durability, enhanced visibility, and operator-first comfort features tailored specifically for logging.
From precision log handling to high-lift operations on sloped terrain, the DX225LL-7 delivers uncompromised control, torque, and stability. Whether you’re loading trucks, sorting logs, or working in dense forest environments, this log loader is the ultimate solution for boosting productivity and operator confidence.
Key Features
- Powerful Engine: 162.8 hp @ 1800 rpm for superior performance in forestry applications.
- Impressive Reach: 35' 5" reach for efficient log handling and loading.
- Robust Guarding: Full undercarriage and upper structure protection for durability.
- Comfortable Cab: Spacious, well-ventilated cab with heating, air conditioning, and a heated air-suspension seat.
- Enhanced Visibility: Clear sightlines, LED lights, and camera systems for improved safety.
- Adaptable Power: Multiple work modes and auto shutdown feature for fuel efficiency.
Detailed Specifications
| Category | Specification |
|---|---|
| Engine | DEVELON DL06P, 6-cylinder, 162.8 hp @ 1800 rpm |
| Max Torque (Gross) | 556.9 ft·lb @ 1400 rpm |
| Displacement | 5.9 L (360 in³) |
| Hydraulic Flow | 2 x 56.4 gpm (Main Pumps) |
| Working Pressure | 4978–5262 psi (Normal / Boost) |
| Operating Weight | 68,784 lb (34.4 Tons) |
| Reach (Ground Level) | 35' 5" |
| Max Loading Height | 29' 3" |
| Travel Speed | 1.6 – 2.7 mph (2.5 – 4.4 km/h) |
| Traction Force | 72,598 lbf |
| Gradeability | 70% (35°) |
| Swing Torque | 69,623 lbf·ft |
| Swing Speed | 0 – 10.7 rpm |
| Fuel Capacity | 254.4 gal |
| DEF Tank | 7.9 gal |
| Cabin Sound Level | 69 dB(A) (ISO 6396) |
| External Sound Level | 105 dB(A) |
| Boom Cylinder | 5.5" x 3.7" x 45.0" |
| Arm Cylinder | 6.5" x 4.5" x 55.0" |
| Heel Cylinder | 4.5" x 3.0" x 36.0" |
| Battery | 2 x 12V, 150 AH |
| Alternator | 24V, 80A |
| Cooling System | 9.0 gal |
| Hydraulic System | 74.0 gal |
| Hydraulic Tank | 34.6 gal |
