Product Description
Develon | Log Loader | Model DX300LL-5 | Reach 37' 2" | Loading Height 28' 8" | 266.5 hp | 41 Tons | For Precision Forestry & Road Building
DESCRIPTION
The Develon DX300LL-5 Log Loader is purpose-built for the toughest forestry applications, blending unshakable power with refined control and maximum protection. Whether you're loading, stacking, road building, or pioneering fresh ground, this machine is your ultimate partner in performance, comfort, and uptime.
With a rugged, fully guarded structure and high-walker undercarriage, the DX300LL-5 doesn’t flinch in the face of challenging terrain. The heavy-duty tracks, dual grouser shoes, full-length guiding guards, and reinforced upper frame give it stability where others falter.
Inside, operators enjoy a roomy, high-visibility cab that’s both quiet and intelligently designed. The side-entry forestry cab meets strict safety standards, offering a hydraulic tilt riser, polycarbonate windows, and Oregon OSHA / BC WCB compliance.
Advanced Tier 4 Final technology ensures powerful, fuel-efficient performance with reduced emissions. And with easy maintenance access and long service intervals, the DX300LL-5 keeps downtime low and productivity high.
From thick timber to steep slopes, the DX300LL-5 is ready to go to work every hour, every day.
Key Features
- Powerful Engine: 266.5 hp @ 1800 rpm for superior performance in forestry applications.
- Heavy-Duty Construction: Fully guarded undercarriage and upper structure for durability.
- Comfortable Cab: Optional side-entry forestry cab with excellent visibility and safety features.
- Fuel Efficiency: Auto-shutdown feature to conserve fuel during idle times.
- Advanced Monitoring: Standard LCD display with maintenance history and camera feeds for improved visibility.
- Reduced Maintenance: Extended intervals and easy access to service points for increased uptime.
Detailed Specifications
| Category | Specification |
|---|---|
| Model | Develon DX300LL-5 |
| Engine Make / Model | DEVELON DL08P |
| Engine Power (Net) | 266.5 hp @ 1800 rpm |
| Engine Power (Gross) | 271 hp @ 1800 rpm |
| Max Torque (Gross) | 940 lbf·ft @ 1300 rpm |
| Piston Displacement | 466 in³ (7.4 L) |
| Fuel Tank Capacity | 132 gal (500 L) |
| DEF Tank Capacity | 18.5 gal (70 L) |
| Operating Weight | 81,703 lb (37,060 kg) |
| Undercarriage Type | High-Walker, Heavy-Duty |
| Track Shoes per Side | 48 |
| Rollers (Upper/Lower) | 2 / 9 per track |
| Track Length | 16' 2" (4920 mm) |
| Swing Speed | 0 – 9.9 rpm |
| Swing Torque | 87,787 lbf·ft (12137 kgf·m) |
| Travel Speed (Low / High) | 1.7 – 2.6 mph (2.8 – 4.3 km/h) |
| Traction Force (Drawbar Pull) | 78,705 lbf (35,700 kgf) |
| Gradeability | 70% (35°) |
| Hydraulic Pump Flow (Total) | 131 gpm (2 × 65.5 gpm) |
| Pilot Pump Flow | 7.13 gpm |
| Hydraulic System Capacity | 81.9 gal (310 L) |
| Hydraulic Tank Capacity | 73.9 gal (280 L) |
| System Pressure (Normal) | 4694 psi |
| System Pressure (Boost) | 4978 psi |
| Cab Sound Level | 69 dB(A) |
| Exterior Sound Level | 104 dB(A) |
| Cylinder Specs | Boom: 5.9" × 3.9" × 46.9" Arm: 7.1" × 4.7" × 55.3" Heel: 5.9" × 3.9" × 39.8" |
| Starter / Battery / Alternator | 24V, 8.0 hp / 2 x 12V, 150AH / 24V, 80A |
| Air Cleaner | Double Element |
| Cab Access | Hydraulic tilt riser, large door, catwalks |
| Standard Display | 7” LCD with rear-view & hybrid display mode |
| Compliance | Tier 4 Final (CEGR, VGT, SCR, DOC, DEF) |
| Optional Attachments | Log Grapple, Bucket, Thumbs, Hydraulic Quick Coupler |
Manuals & Documents
Product Brochure
Road Builder Specification
Log Loader Specification
