Product Description
Dirt Dog Double Arm AG Grapple | Overall Width 60" & 72" inches | Maximum Horsepower 70 HP | For Tractors
Included Options:
Description
Dirt Dog’s double arm AG grapple is the ultimate tool for cleaning up brush and debris with your tractor’s loader. The DAGGR’s double arm design allows you to grab uneven piles with ease, plus each arm is positioned on the outside of the frame, giving you more control and stability. An optional middle arm connector can be bolted in place, locking the two arms together where a single arm is needed. Each grapple arm is reinforced with square tubing and has greasable pivot points for added longevity and durability. The 2”x 6” welded cylinders which provide up to 6,000 pounds per square inch of clamping force are located on the back of the frame keeping them protected. The square tube frame is reinforced with solid backing plates to prevent debris from coming through and the DAGGR’s 5/8” shanks have replaceable teeth. Grapples are the most versatile tool you can add to your tractor’s AG loader, and Dirt Dog’s DAGGR is the best AG grapple in its class. Contact your Dirt Dog dealer or visit us at www.Dirt Dogmfg.com to see the AGGRD and all of our equipment today.
Key Features
- Double Arm Design for Superior Control: Each arm is positioned on the outside of the frame, allowing for easy handling of uneven piles. Add the optional middle connector to lock the two arms together when needed.
- Ultimate Clamping Force: Equipped with 2”x 6” welded cylinders that provide up to 6,000 PSI of clamping force, ensuring robust and secure grasping.
- Durable and Long-Lasting: Reinforced with square tubing and solid backing plates to prevent debris from coming through. Greasable pivot points add longevity and durability to each grapple arm.
- Replaceable Teeth and Plow Points: Weld-on replaceable plow points and teeth ensure the grapple stays sharp and functional.
- Versatile and Compatible: Fits standard skid steer Quick Attach, with the 72” model available in John Deere 300/400/500 Quick Attach and Euro Quick Attach.
- Wide Grapple Opening: Features a 39.5” grapple opening, providing ample space for grabbing large loads.
- Ideal for AG Loaders: Designed for use on AG tractors up to 70 HP, making it a powerful tool for heavy-duty tasks.
- Comprehensive Specs and Options: Available in multiple models (DAGGR60 and DAGGR72) to suit your specific needs.
Detailed Specifications
| Specification | DAGGR60 | DAGGR72 |
|---|---|---|
| Overall Height Closed | 33 3/16” | 33 3/16” |
| Overall Width | 60 7/8” | 72 7/8” |
| Overall Depth Closed | 23 3/8” | 23 3/8” |
| Max Grapple Opening | 39 1/2” | 39 1/2” |
| Greasable Pivot Points | Yes | Yes |
| Shank Size | 5/8” | 5/8” |
| Weight | 435 lbs | 462 lbs |
| Weight w/ Middle Connector Installed | 488 lbs | 527 lbs |
| Number of Shanks | 5 | 5 |
| Hoses Included | Included | Included |
| Quick Couplers | Not Included | Not Included |
| Max Horse Power | 70 HP | 70 HP |
Manual & Documents
General Warranty Info:
-
Ripping It Outdoors works closely with our manufacturers to supply and support your products warranty needs as best as possible!
- The majority of products come with a manufacturer represented warranty against manufacturing defects for at least a 12 month period after the date of sale.
- Expendable components and "wear parts" including but not limited to blades, knives, teeth, oil, chain sprockets, skid shoes, knife mounting discs, and similar components are usually excluded from manufacturer warranties.
- Please reach out to us for any specific warranty information needed about products and parts you can’t find!
