Product Description
Dirt Dog Heavy Duty High Capacity Bucket | Model HDHC Series | Widths 72", 76", 80" & 88" | 8–30+ GPM | Up to 120 HP | For Skid Steer & Tractor
DESCRIPTION
The Dirt Dog Heavy Duty High Capacity Bucket (HDHC Series) is engineered for maximum performance, durability, and efficiency in demanding applications. Designed for tractors, skid steers, and loaders, this bucket delivers superior strength with its reinforced cutting edges, side braces, and solid quick‑attach plate. Available in multiple widths (72", 76", 80", and 88"), it supports machines up to 120 horsepower and hydraulic flow from 8 to 30+ GPM, making it ideal for heavy‑duty digging, grading, and material handling. Whether you choose the smooth edge or bolt‑on teeth option, the HDHC bucket ensures reliable operation and long service life. Built tough with precision engineering, this bucket is the ultimate attachment for contractors, landscapers, and farmers who demand power, versatility, and durability in every job.
Key Features
- Heavy Duty Construction Built with reinforced steel for maximum durability in tough working conditions.
- Multiple Width Options Available in 72", 76", 80", and 88" sizes to match different machine requirements.
- High Capacity Design Large volume capacity (up to 23 ft³) for efficient material handling.
- Hydraulic Flow Compatibility Operates seamlessly with 8–30+ GPM hydraulic systems.
- Horsepower Support Handles up to 120 HP for rubber tire machines and 100 HP for rubber track machines.
- Bolt-On Teeth Option Choose with or without teeth for digging or smooth grading applications.
- Reinforced Cutting Edge 1" x 8" cutting edge ensures long-lasting wear resistance.
- Side Cutting Edges 3/4" x 6" side edges provide added strength and protection.
- Solid Quick Attach Plate Ensures secure and easy attachment to skid steers and tractors.
- Side Braces for Stability 1/2" side braces enhance structural integrity under heavy loads.
- Optimized Roll Back Angle 20° rollback angle improves material retention and efficiency.
- Black Powder-Coated Finish Durable coating resists rust and maintains professional appearance.
- Versatile Applications Perfect for excavation, grading, landscaping, and construction projects.
- Smooth or Tooth Edge Options Adaptable to different jobsite needs for maximum versatility.
- Engineered for Longevity Designed to withstand demanding use with minimal maintenance.
Detailed Specifications
| Specification | HDHC72T (72") | HDHC76T (76") |
|---|---|---|
| Model Type | With Teeth | With Teeth |
| Overall Width | 72.88" | 76.88" |
| Overall Depth | 37-5/8" | 37-5/8" |
| Overall Height | 25-7/8" | 25-7/8" |
| Volume (Not Heaped) | 18.5 ft³ | 19.5 ft³ |
| Roll Back Angle | 20° | 20° |
| Weight | 775 lbs | 811 lbs |
| Teeth Count | 8 | 8 |
| Cutting Edge | 1" x 8" | 1" x 8" |
| Side Cutting Edges | 3/4" x 6" | 3/4" x 6" |
| Side Braces | 1/2" | 1/2" |
| Hydraulic Flow Range | 8–30+ GPM | 8–30+ GPM |
| Horsepower Capacity | Up to 120 HP (Rubber Tire) / 100 HP (Rubber Track) | Up to 120 HP (Rubber Tire) / 100 HP (Rubber Track) |
| Color | Black | Black |
| Attachment Type | Quick Attach | Quick Attach |
| Specification | HDHC80T (80") | HDHC88T (88") |
|---|---|---|
| Model Type | With Teeth | With Teeth |
| Overall Width | 82" | 90" |
| Overall Depth | 37-5/8" | 37-5/8" |
| Overall Height | 25-7/8" | 25-7/8" |
| Volume (Not Heaped) | 21 ft³ | 23 ft³ |
| Roll Back Angle | 20° | 20° |
| Weight | 830 lbs | 900 lbs |
| Teeth Count | 9 | 9 |
| Cutting Edge | 1" x 8" | 1" x 8" |
| Side Cutting Edges | 3/4" x 6" | 3/4" x 6" |
| Side Braces | 1/2" | 1/2" |
| Hydraulic Flow Range | 8–30+ GPM | 8–30+ GPM |
| Horsepower Capacity | Up to 120 HP (Rubber Tire) / 100 HP (Rubber Track) | Up to 120 HP (Rubber Tire) / 100 HP (Rubber Track) |
| Color | Black | Black |
| Attachment Type | Quick Attach | Quick Attach |
| Specification | HDHC72S (72") | HDHC76S (76") |
|---|---|---|
| Model Type | Smooth Edge | Smooth Edge |
| Overall Width | 72.88" | 76.88" |
| Overall Depth | 37-5/8" | 37-5/8" |
| Overall Height | 25-7/8" | 25-7/8" |
| Volume (Not Heaped) | 18.5 ft³ | 19.5 ft³ |
| Roll Back Angle | 20° | 20° |
| Weight | 720 lbs | 755 lbs |
| Cutting Edge | 1" x 8" | 1" x 8" |
| Side Cutting Edges | 3/4" x 6" | 3/4" x 6" |
| Side Braces | 1/2" | 1/2" |
| Hydraulic Flow Range | 8–30+ GPM | 8–30+ GPM |
| Horsepower Capacity | Up to 120 HP (Rubber Tire) / 100 HP (Rubber Track) | Up to 120 HP (Rubber Tire) / 100 HP (Rubber Track) |
| Color | Black | Black |
| Attachment Type | Quick Attach | Quick Attach |
| Specification | HDHC80S (80") | HDHC88S (88") |
|---|---|---|
| Model Type | Smooth Edge | Smooth Edge |
| Overall Width | 82" | 90" |
| Overall Depth | 37-5/8" | 37-5/8" |
| Overall Height | 25-7/8" | 25-7/8" |
| Volume (Not Heaped) | 21 ft³ | 23 ft³ |
| Roll Back Angle | 20° | 20° |
| Weight | 775 lbs | 870 lbs |
| Cutting Edge | 1" x 8" | 1" x 8" |
| Side Cutting Edges | 3/4" x 6" | 3/4" x 6" |
| Side Braces | 1/2" | 1/2" |
| Hydraulic Flow Range | 8–30+ GPM | 8–30+ GPM |
| Horsepower Capacity | Up to 120 HP (Rubber Tire) / 100 HP (Rubber Track) | Up to 120 HP (Rubber Tire) / 100 HP (Rubber Track) |
| Color | Black | Black |
| Attachment Type | Quick Attach | Quick Attach |
